Rocker SolarVac 600 - MS Instruction Manual

Rotary manifold and filtration system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTRUCTION MANUAL
Rotary Manifold and Filtration System
Model No.
SolarVac 600 - MS
SolarVac 600 / 601 - MB
SolarVac 1200 / 1201 - MB
SolarVac 601 / 1201 - MB - A
SolarVac 610 / 1201 - MB - T
Please read this instruction manual before using this product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SolarVac 600 - MS and is the answer not in the manual?

Questions and answers

Related Manuals for Rocker SolarVac 600 - MS

Summary of Contents for Rocker SolarVac 600 - MS

  • Page 1 INSTRUCTION MANUAL Rotary Manifold and Filtration System Model No. SolarVac 600 - MS SolarVac 600 / 601 - MB SolarVac 1200 / 1201 - MB SolarVac 601 / 1201 - MB - A SolarVac 610 / 1201 - MB - T...

  • Page 3: Table Of Contents

    (1) Rotary Manifold (2) Vacuum Pump (3) Parts Material List Installation and Operation (1) Preparation and Installation of Manifold (2) Vacuum Filtration System 2.1 System with Alligator 200 Diaphragm Liquid Pump 2.2 System with Rocker 400 Vacuum Pump Maintenance Troubleshooting...

  • Page 4: Important Notice

    Never use the attached pump with any chemical, corrosive, flammable or toxic material. Please use Alligator 200 liquid pump with manifold and membrane to prevent clogging. The protection device of Rocker 400 vacuum pump: - To ensure proper function of the Prote protection device, the pump must be installing on a flat level surface and should not be moved when operation.

  • Page 5: Unpacking

    11. Operating condition (a) Ambient temperature: 5~40 °C (b) Relative humidity: 80% RH Max. (c) Power supply: (Alligator 200) 100-240V~, 50/60Hz (Rocker 400) 100-120V~, 50/60Hz or 200-240V~, 50/60Hz (d) Altitude: up to 2000 m (e) Pollution degree: II (f ) Indoor use 2.

  • Page 6: Vacuum Filtration System

    SolarVac 601 - MB SolarVac 1201 - MB Standard Package Includes: Model Stainless Steel Branches / Material Adaptor Funnel SolarVac 601 - MB 6 Places Rotary Manifold 100 mL x 6 SolarVac 1201 - MB 12 Places Rotary Manifold 100 mL x 12 ...
  • Page 7 • Manifold with Rocker 400 Vacuum Pump SolarVac 601 - MB - T SolarVac 1201 - MB - T Model Standard Package Includes: SolarVac 601 / 1201 - MB, 6 / 12 Places Rotary Manifold Rocker 400, Oil Free Vacuum Pump...

  • Page 8: Main Part Diagram

    Adjustable Vent Valve Control Valve (Knob) Hose Barb (Outlet) Funnel Adaptor  To rotate the manifold, simply swipe on the knobs (2). (2). Vacuum Pump Rocker 400 Oil Free Vacuum Pump Alligator 200 Diaphragm Liquid Pump Position Designation Position Designation...

  • Page 9: Parts Material List

    Knob Aluminum alloys • Alligator 200, Diaphragm Liquid Pump Part Material contacts with filtrates Wetted parts SS316, FKM, Silicone, PP, PPS • Rocker 400, Oil Free Vacuum Pump Part Material Part Material Pump Head Aluminum alloys Piston Seal PTFE complex...

  • Page 10: Installation And Operation

    4. Installation and Operation (1). Preparation and Installation of Manifold Make sure all control valves are off before use, rotate the control valves counterclockwise to vertical position for filtration. Change the funnel adaptor to fit the desired funnel or filter holder if necessary. ...
  • Page 11 2. Rocker SF Funnel Adaptor - Fitting to (left) ROCKER SF 100 / 300 / 500 ml funnel* and (right) Pall, Sentino® 4870 (100 mL), 4871 (250 mL) disposable plastic funnel.

  • Page 12: Vacuum Filtration System

    After finishing filtration, close the control valve and retrieve the membrane. ROCKER SF stainless steel funnel can be fast flame-sterilized by Dragon 100 torch burner or autoclaved before proceeding next filtration. * Warning: (1) Do NOT use cable tie or any similar items to secure the pump’s outlet and silicone tube together to prevent any bursting and potential damage to the pump.

  • Page 13: System With Rocker 400 Vacuum Pump

    After finishing filtration, close the control valve and retrieve the membrane. ROCKER SF stainless steel funnel can be fast flame-sterilized by Dragon 100 torch burner or autoclaved before proceeding next filtration. * Warning: Please ensure the liquid level of moisture trap and vacuum bottle do not exceed safety level.

  • Page 14: Maintenance

    3. While doing filtration with Rocker 400 vacuum pump, please remove the liquid in the moisture trap and keep pumping the air for at least 2 minutes to withdraw the residual steam.  Please refer to manual of Rocker Oil free Vacuum Pump to see how to reset the Prote protection device and replace cartridge.

  • Page 15: Troubleshooting

     Outlet is blocked  Clean or stretch the outlet tube.  Improperly vacuum setting  Adjust the vacuum regulator. Poor vacuum  Clogged muffler of Rocker 400 pump  Replace a new muffler.  Air leakage  Replace or tighten the tubing and accessories that possible leaks.

  • Page 16: Ordering Information

    Ordering Information 186600-01 SolarVac 600 - MS, 6 Places Rotary Manifold with No.8 stopper funnel adaptor 186600-02 SolarVac 600 - MB, 6 Places Rotary Manifold with ROCKER SF funnel adaptor 1861200-02 SolarVac 1200 - MB, 12 Places Rotary Manifold with ROCKER SF funnel adaptor...
  • Page 17 197200-48 4000 mL Heavy Duty PP Vacuum Bottle with drain 200300-01(-P) MF 3 (Pro), Magnetic Filter Holder (300 mL) 200500-01(-P) MF 5 (Pro), Magnetic Filter Holder (500 mL) 180300-68 Silicone tube, Ø 8 x 14 mm, 200 cm 167200-38 Silicone tube, Ø 6 x 12 mm, 100 cm 177100-00 Dragon 100, Torch Burner 167100-20...
  • Page 20 Rocker Scientific Co., Ltd. Tel: +886-2-26033311 Fax: +886-2-26036622 E-mail: export@rocker.com.tw https://www.rocker.com.tw...
