6-SHELF LUMBER STORAGE RACK

WOODR6_TA

840138

Operator's Manual

Read the Operator's Manual entirely. When you see this

symbol, the subsequent instructions and warnings are

serious follow without exception. Your life and the lives

of others depend on it!

Need help?

Do you have a question about the 840138 and is the answer not in the manual?

Questions and answers

Summary of Contents for Titan Attachments 840138

Page 1 6-SHELF LUMBER STORAGE RACK WOODR6_TA 840138 Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception. Your life and the lives of others depend on it!
Page 2 PARTS DIAGRAM / EXPLODED VIEW DESCRIPTION SCREWS HORIZONTAL BARS SPACERS VERTICAL BARS • The Wood Rack Provides 6 levels with a capacity of 110lb. (50kg.) per level. It is easy to install and easy to customize. • Due to product improvements, actual product may vary slightly. Made in China 1 year warranty.
Page 3 ASSEMBLY INSTRUCTIONS Warning: Ensure your mounting location can withstand the additional load. Never overload your rack. Note: Vertical bars can be used as templates to mark your drilling locations before assembly. NOTICE: Assembly hardware located in tubes at end of package. 1.
Page 4 RECOMMENDED INSTRUCTIONS 1. See Step 3 of assembly instructions for drywall or another paneled wall sheeting. 2. Installing on masonry walls: Use ¼” (6mm) masonry anchors. The assembled wood rack is 5/8” (41mm) thick so a suitable length of anchor is 3” (76mm) minimum. Use the proper drill bits and fasteners to create a solid, strong hold of your wood rack.
Page 5 CUSTOMIZE YOUR WOOD RACK 1. For Outdoor Use: Weather protection of your materials is achieved by creating a custom cover. Anchor a horizontal board the length of your material above the wood rack. Take a sheet of vinyl of thick plastic and attach several thin wood battens to the inside with staples to keep it from flapping around.
Page 6 ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABIILITY The use of any equipment, including this one, involves the potential risk of injury. Apart from any warranty claim that might be presented for a claimed defect in material or workmanship of the product, you accept and assume full responsibility for any and all injuries, damages (both economic and non-economic), and losses of any type, which may occur, and you fully and forever release and discharge Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims, demands, damages, rights...
