Summary of Contents for Bogen DRZ120
- Page 1 DRZ120 6-Zone Music & Paging System © 2016 Bogen Communications, Inc. All rights reserved. Specifications subject to change without notice. 54-2233-01B 1606...
-
Page 2: Important Safety Instructions
NOTICE: Every effort was made to ensure that the information in this guide was complete and accurate at the time of printing. However, information is subject to change. WARNING: To reduce the risk of Fire or Electric Shock, Do Not Expose this apparatus to rain or moisture. The apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases shall be placed on the apparatus. -
Page 3: Table Of Contents
Contents DRZ120 6-Zone Music & Paging System Page DRZ120 FRONT PANEL ........................2 DRZ120 REAR PANEL ..........................3 INFRARED REMOTE CONTROLLER........…………………………………………...4 INSTALLATION ..........…………………………………………………………………...5 CONNECTIONS..........…………………………………………………………………...6 OPERATION ..........…………………………………………………….………………...7 TECHNICAL SPECIFICATIONS....…………………………………………………………………..8 LIMITED WARRANTY; EXCLUSION OF CERTAIN DAMAGES ............9... -
Page 4: Drz120 Front Panel
Input Level Output Level 1. Master POWER Switch 11. SD Card Slot Turns Power to DRZ120 unit ON or OFF. Slot for SD Card connection for MP3 files. 2. Power ON Indicator 12. MP3/TUNER Button Indicates when Power is on. -
Page 5: Drz120 Rear Panel
DRZ120 Rear Panel MIC 3 VOL MIC 4 VOL MIC 3 IN MIC 4 IN FM ANTENNA SPEAKER OUTPUT DRZ 120 4-16Ω BAL./UNBAL. — BAL./UNBAL. — + — + www.bogen.com FM (75Ω) F4AL250V ZONE OUTPUTS MIC 2 LINE1 LINE 2... -
Page 6: Infrared Remote Controller
TUNER Mode: Selects FM Tuner frequency. *Note: The source selection for "USB" or "SD" is only displayed if a USB drive or SD card is plugged into the DRZ120. Also, although the source selection will display an "AUX" mode, this mode is not supported by this particular model. -
Page 7: Package Contents
Provide at least 1 RU (Rack Unit) of space above and below the DRZ120 so that cool air is available to the unit. Rack mounting brackets are attached to the unit. -
Page 8: Connections
Connections Without Multi-Zone Outputs MIC 4 MIC 3 To MIC1 Input Jack on Front Panel MIC 1 MIC 2 with Priority Input RECORDER OR OTHER AMP MUSIC SOURCE With Multi-Zone Outputs MIC 4 MIC 3 To MIC1 Input Jack on Front Panel MIC 1 MIC 2... -
Page 9: Operation
Two repeat modes can be selected when playing MP3 audio. Using the remote control, press the “RPT” button to toggle between the two options. When “ONE” is appears on the display of the DRZ120, the current track will be con- tinuously repeated. -
Page 10: Technical Specifications
Technical Specifications Amplifier Power Rating (RMS): ............120 Watts into 8-ohms ≤ Distortion: ................ 1% THD (Rated output power@1 kHz) ≤ Signal to Noise Ratio: ............ -74 dB Audio Frequency Response: ........80 Hz - 16 kHz @ 4Ω (+/-3 dB) Zone Outputs:..............120 Watts @70V max. for any single zone, or 20 Watts @70V max. -
Page 11: Limited Warranty; Exclusion Of Certain Damages
Limited Warranty; Exclusion of Certain Damages The Bogen DRZ120 is warranted to be free from defects in material and workmanship for 2 (two) years from the date of sale to the original purchaser. Any part of the product covered by this warranty that, with normal installation and use, becomes defective (as confirmed by Bogen upon inspection) during the applicable warranty period, will be repaired or replaced by Bogen, at Bogen’s option, provided the product is shipped insured and... - Page 12 www.bogen.com...
