- Page 1 Conferencing Terminal Android-based Video Conferencing Terminal User Manual （V1.0）...
-
Page 2: Graphic Symbols
UT680 Integrated intelligent terminal User Manual Preface This manual is to ensure that the user can use the product properly and avoid danger while operating. Before using this product, please read the user manual carefully and keep it properly for future reference Overview: This manual is about UT680 camera operation. -
Page 3: Electrical Safety
UT680 Integrated intelligent terminal User Manual Attention This manual introduces functions, installations and operations for this product in details. Please read this manual carefully before installation and use. Precautions: This product can only be used in the specified conditions in order to avoid any damage to the camera: 1）... -
Page 4: Table Of Contents
UT680 Integrated intelligent terminal User Manual Contents 1. Quick installation instructions ......................4 1.1 Product panel ........................4 1.2Equipment Use ........................5 1.3 video Output ........................5 1.4 Audio Input .........................5 1.5 Audio Onput ........................5 1.6 system Interface ......................... 5 2.Product Overview ..........................6... -
Page 5: Quick Installation Instructions
UT680 Integrated intelligent terminal User Manual 1. Quick installation instructions 1.1 Product panel Serial Port Describe number Camera 1x 200M Camera Microphone 2x Electret Microphone, used for sound pickup. Infrared 1x Infrared Receiver 1x Micro-USB Interface for device debugging... -
Page 6: Equipment Use
1.6 system Interface UT680 comes with Android 12, which is the native version of Android, and the overall interface can be controlled by the customer through the USB port to access the mouse or... -
Page 7: Product Overview
UT680 Integrated intelligent terminal User Manual 2.Product Overview 2.1Product Introduction Android video conference terminal UT680 adopts 12x optical zoom lens, 78° large Angle of view, built-in intelligent echo cancellation, noise suppression audio algorithm, to provide users with high-quality conference audio-visual experience; Integrated design, integrated Android platform, camera, mechanical head, Wi-Fi, Bluetooth, support dual screen display, support wired/wireless screen projection, wiring installation is easy and fast;... -
Page 8: Product Features
3-pin Phoenix terminal ● 2.2 Product Features Android video conference terminal UT680 adopts 12x optical zoom lens, 78° large Angle of view, built-in intelligent echo cancellation, noise suppression audio algorithm, to provide users with high-quality conference audio-visual experience; Integrated design, integrated Android platform, camera, mechanical head, Wi-Fi, Bluetooth, support dual screen display, support wired/wireless screen projection, wiring installation is easy and fast;... -
Page 9: Technical Specification
UT680 Integrated intelligent terminal User Manual 2.3 Technical Specification Android Android 12 RK3588 System :8K@30Hz Video Encoding :8K@60Hz Video Decoding Image Sensor 2.07 Million High Quality CMOS Image Sensor D：7.5° - 78.3° H：6.6° - 70.2° Camera V：3.7° - 42°... -
Page 10: Use Of Remote Control
UT680 Integrated intelligent terminal User Manual Wireless 2.4G / 5G dual module Wi-Fi, Bluetooth 5.0 Interface 1x 3.5mmLinear output Audio 1x LINE IN input, 3-pin Phoenix terminal Interface 1x MIC IN input, 3-pin Phoenix terminal（with phantom power） Network 1x 10/100M RJ45 Network port... - Page 11 UT680 Integrated intelligent terminal User Manual Item Port Description Power Ke Standby / Wake up volume key Volume up/down/Zoom in/out Mute key Mute Mode switch key Switch to camera mode (in this mode you can control the camera's head, etc.)
-
Page 12: Maintenance And Troubleshooting
UT680 Integrated intelligent terminal User Manual 4.Maintenance and Troubleshooting 4.1Maintenance 1）If the camera will not be used for a long time, please turn off the power switch. 2）Use a soft cloth or lotion-free tissue to clean the camera body. -
Page 13: Copyright Notice
UT680 Integrated intelligent terminal User Manual Copyright Notice The entire contents of this manual, whose copyright belongs to Minrray Industry Co.,Ltd, may not be cloned, copied or translated in any way without the explicit permission of the company. Product specifications and information referred to in this document are for reference only and as such are subject to updating at any time without prior notice.
