- Page 1 INSTRUCTION MANUAL Outdoor Fabric Storage Shed SKY9206 + SKY9207 + SKY9208 + SKY9209 + SKY9210 Ver. 1...
- Page 2 This product is di cult to move once assembled, build this product in its intended location on your property. bestchoiceproducts.com...
-
Page 3: Tools Required
NOTICE Please retain these instructions for future reference. • Do not stand on or use any part of this item as a step ladder. • Firmly secure all bolts, screws, and knobs before use. • Reconfirm that all rods, knobs, or clips are secure every 90 days. •... - Page 4 PARTS LOWER LEG SUPPORT BOTTOM SUPPORT FRONT/BACK ROOF BEAMS RECEIVER 6 PCS 4 PCS 2 PCS CENTRAL ROOF CORNER RECEIVER CENTRAL SIDE RECEIVER RECEIVER 1 PC 4 PCS 2 PCS FOOT CAP GROUND STAKE ELASTIC LOOPS 6 PCS 50 PCS 12 PCS CANOPY ACCESSORY HOOKS...
- Page 5 PRODUCT ASSEMBLY Attach two part F front/back roof receivers to two part B frame supports. Connect the free end of the two part B frame supports to the part G central roof receiver. Insert two part A roof supports each into the part F front/back roof receiver, two supports per receiver.
- Page 6 PRODUCT ASSEMBLY Attach four part B frame supports to the part H and part I receivers. Insert one part C upper leg support into each part H and part I receiver, six leg supports total. Insert one part C upper leg support into each part H and part I receiver, six leg supports total.
- Page 7 PRODUCT ASSEMBLY Drape the part M canopy over the roof assembly. Attach one part D lower leg support to each part C upper leg support, six leg supports total. Attach one part D lower leg support to each part C upper leg support, six leg supports total.
- Page 8 PRODUCT ASSEMBLY Attach four part E bottom support beams to the four part D lower leg supports in the corners of the assembly with four part 2 bolts and four part 3 nuts. Secure the part E bottom support beams in to the part D lower leg supports in the center of the assembly with two part 2 bolts and two part 3 nuts.
- Page 9 PRODUCT ASSEMBLY Place on part J foot cap onto the bottom of each part D lower leg support, six foot caps total. Attach each foot cap to the part D lower leg supports with one part 1 bolt and one part 3 nut, six nuts and six bolts total.
- Page 10 PRODUCT ASSEMBLY Draw the canopy over the frame assembly until it sits evenly on all sides, then use twelve part L elastic loops to attach the part M canopy to the part E bottom support beams.
- Page 11 PRODUCT ASSEMBLY Drive the remaining twenty part K ground stakes into the pre-fabricated holes on the bottom of the part M canopy to complete assembly. Hang the part N accessory hooks on the part B frame supports as desired.
-
Page 12: Help Center
HELP CENTER Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com CHAT Chat Support Product Inquiry Orders FAQ Product Assembly Returns & Refunds PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
