EBONY FASCIA FITTING GUIDE

This guide should be read in conjunction with the installer and owner guide

supplied with the fire.

This guide is intended to help you install your Ebony fascia. Please read carefully

before installing. However, if further information is required, our

Wonderfire Premier Technical Helpline will be pleased to help.

Telephone 0844 8711 565 (National call rates apply in the United Kingdom)

In the Republic of Ireland call 0044 844 8711 565.

Important: Please keep your guide in a safe place for future reference.

Baxi Heating U.K. Limited 2009.

Need help?

Do you have a question about the Wonderfire PREMIER EBONY FASCIA and is the answer not in the manual?

Page 1 Telephone 0844 8711 565 (National call rates apply in the United Kingdom) In the Republic of Ireland call 0044 844 8711 565. Important: Please keep your guide in a safe place for future reference. © Baxi Heating U.K. Limited 2009.
Page 2 Applications for the copyright owner's permission to reproduce any part of this publication should be made, giving details of the proposed use, to the following address: The Company Secretary, Baxi Heating UK Limited, The Wyvern Business Park, Stanier Way, Derby, DE21 6BF.
Page 3: Handling And Unpacking
Always keep the surround as close to the body as possible. This will minimise the cantilever action. Use gloves to provide additional grip. Always use assistance if required. CONTENTS Figure 1. Contents. Page 3 © Baxi Heating U.K. Limited 2009.
Page 4: Fitting The Fascia
Locate and secure the lower fascia brackets using four M4 x 7 screws supplied (See figure 3). The screws only need to be finger tight as this will help to align the bracket with the convection box. Figure 3. Page 4 © Baxi Heating U.K. Limited 2009.
Page 5 At least one hole on each side of the fire must be used (See figure 5). Figure 5. Page 5 © Baxi Heating U.K. Limited 2009.
Page 6 Locate the ash pan at the base of the fascia and check its alignment to the fascia sides. The base of the ash pan has three adjustable feet that can be screwed in and out should any adjustment be necessary (See figure 6). Figure 6. Page 6 © Baxi Heating U.K. Limited 2009.
