ASSEMBLY INSTRUCTIONS / INSTRUCTIONS DE MONTAGE / INSTRUCCIONES DE MONTAJE / MONTERING INSTRUKTIONER
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
IMPORTANT, À CONSERVER POUR DE FUTURS BESOINS DE RÉFÉRENCE : À LIRE SOIGNEUSEMENT
IMPORTANTE: CONSERVE PARA FUTURA REFERENCIA. LEA CUIDADOSAMENTE
VIKTIGT, BEHÅLL FÖR FRAMTIDA REFERENS: LÄS NOGGRANT
CAUTION: ALWAYS UNPLUG BEFORE ASSEMBLING, CHANGING THE BULB, OR CLEANING.
ATTENTION : BRANCHER SEULEMENT APRÈS LE MONTAGE ET DÉBRANCHER LORS DUREMPLACEMENT DE L'AMPOULE.
PRECAUCIÓN: DESENCHUFAR ANTES DE ARMAR, DESENCHUFAR AL CAMBIAR LA LÁMPARA O AL LIMPIAR.
VARNING: KOPPLA ALLTID UR KONTAKTEN INNAN DU MONTERAR, BYTER GLÖDLAMPA ELLER RENGÖR.
Do not discard any packaging contents until after assembly is completed. Be sure to check the entire box for all parts that are listed in the assembly instructions.
Ne jetez pas le contenu de l'emballage avant la fin de l'assemblage. Assurez-vous de cocher la case entière pour toutes les pièces répertoriées dans les instructions de montage.
No deseche ningún contenido del embalaje hasta que se haya completado el montaje. Asegúrese de revisar todo el embalaje para comprobar todas las piezas que se enumeran
en las instrucciones de montaje.
Kassera inte något förpackningsinnehåll förrän efter att monteringen är klar.Var noga med att markera hela rutan för alla delar som anges i monteringsanvisningarna.
Carefully unpack and place all parts on a smooth surface and line up the parts as illustrated.
Déballez avec soin et placez toutes les pièces sur une surface lisse en les disposant tel qu'illustré.
Desempaque con cuidado y colocar todas las piezas en una superficie lisa y alinear las piezas como se ilustra.
Packa försiktigt upp och placera alla delar på en slät yta och rada upp delarna enligt bilden.
A
B
1
Floor Lamp / Lampadaire / Lámpara de pie / Gólf lampi
1. Connect the power cord (A) and base (B).
2. Install UK (C) or EU (D) interchangeable plugs on the adaptor.
1. Connectez le cordon d'alimentation (A) et la base (B).
2. Installez les fiches interchangeables UK (C) ou EU (D) sur l'adaptateur.
1. Conecte el cable de alimentación (A) y la base (B).
2. Instale enchufes intercambiables UK (C) o EU (D) en el adaptador.
1. Tengdu rafmagnssnúruna (A) og grunninn (B).
2. Installez les fiches interchangeables UK (C) ou EU (D) sur l'adaptateur.
Foot Switch
1. Step on the pedal for the first time, turn on the warm white light.
2. Step on the pedal for 1 second again, the red light is on.
3. Step on the pedal for 1 second again, the green light is on.
4. Step on the pedal for 1 second again, the blue light is on.
5. Step on the pedal for 1 second again, RGBW four-color running.
6. Step on the pedal for 2 seconds again, turn off .
7. In any mode, step on the pedal for more than 2 seconds to turn off.
8. When powered on for the first time, the default light is warm white.
Interrupteur au pied
1. Appuyez sur la pédale pour la première fois, allumez la lumière blanche chaude.
2. Appuyez à nouveau sur la pédale pendant 1 seconde, le voyant rouge s'allume.
3. Appuyez à nouveau sur la pédale pendant 1 seconde, le voyant vert s'allume.
4. Appuyez à nouveau sur la pédale pendant 1 seconde, le voyant bleu s'allume.
5. Appuyez à nouveau sur la pédale pendant 1 seconde, RGBW quatre couleurs en cours d'exécution.
6. Appuyez à nouveau sur la pédale pendant 2 secondes, éteignez .
7. Dans n'importe quel mode, appuyez sur la pédale pendant plus de 2 secondes pour éteindre.
8. Lors de la première mise sous tension, la lumière par défaut est blanc chaud.
Interruptor de pie
1. Pise el pedal por primera vez, encienda la luz blanca cálida.
2. Pise el pedal durante 1 segundo nuevamente, la luz roja está encendida.
3. Pise el pedal durante 1 segundo nuevamente, la luz verde está encendida.
4. Pise el pedal durante 1 segundo nuevamente, la luz azul está encendida.
5. Pise el pedal durante 1 segundo nuevamente, Funcionamiento de cuatro colores RGBW.
6. Vuelva a pisar el pedal durante 2 segundos, apague.
7. En cualquier modo, pise el pedal durante más de 2 segundos para apagar.
8. Cuando se enciende por primera vez, la luz predeterminada es blanca cálida.
Fótrofi
1. Stígðu á pedalann í fyrsta skipti, kveiktu á heithvíta ljósinu.
2. Stígðu aftur á pedalinn í 1 sekúndu, rauða ljósið logar.
3. Stígðu aftur á pedalann í 1 sekúndu, græna ljósið logar.
4. Stígðu aftur á pedalann í 1 sekúndu, bláa ljósið logar.
5. Stígðu aftur á pedalinn í 1 sekúndu, RGBW fjögurra lita í gangi.
6. Stígðu aftur á pedalann í 2 sekúndur, slökktu á .
7. Í hvaða stillingu sem er skaltu stíga á pedalann í meira en 2 sekúndur til að slökkva á honum.
8. Þegar kveikt er á því í fyrsta skipti er sjálfgefið ljós heitt hvítt.
For use with model AED24-2401000VWMW0
mfd. Dongguan Guanqing Electronics Co., Ltd
Power supply
Pour une utilisation avec le modèle AED24-2401000VWMW0
mfd. Dongguan Guanqing Electronics Co., Ltd
Alimentation électrique
ITM. / ART. 453604
M# L22
1
Input of Adaptor / Entrée d'adaptateur / Entrada de adaptador /
Inntak á millistykki:220-240V~, 50/60Hz,
Input of Light / Entrée de lumière / Entrada de luz /
Inntak ljóss:DC24V, 1A, 24W
LOCK
SERRURE
BLOQUEADA
LÁS
C
Para usar con el modelo AED24-2401000VWMW0
mfd. Dongguan Guanqing Electronics Co., Ltd
Fuente de alimentación
Til notkunar með gerð AED24-2401000VWMW0
framleiðanda. Dongguan Guanqing Electronics Co., Ltd
Aflgjafa
OPEN
OUVRIR
ABRIR
OPNA
D

Advertisement

loading
Need help?

Need help?

Do you have a question about the L22 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Costco L22

  • Page 1 Floor Lamp / Lampadaire / Lámpara de pie / Gólf lampi ITM. / ART. 453604 M# L22 ASSEMBLY INSTRUCTIONS / INSTRUCTIONS DE MONTAGE / INSTRUCCIONES DE MONTAJE / MONTERING INSTRUKTIONER IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY IMPORTANT, À CONSERVER POUR DE FUTURS BESOINS DE RÉFÉRENCE : À LIRE SOIGNEUSEMENT IMPORTANTE: CONSERVE PARA FUTURA REFERENCIA.
  • Page 2 LOCK / SERRURE / BLOQUEAR / LÁS 1. Identify the install position direction. 2. Align the install position. 3. Turn the plug clockwise to lock the adapter and plug. 1. Identifiez le sens de la position d'installation. 2. Alignez la position d'installation. 3.
  • Page 3 Included : Inclus : Incluido : Innifalið : Lamp x1 Lampe x1 Lámpara x1 Lampi x1 Adaptor x1 Adaptateur x1 Adaptador x1 Millistykki x1 UK plug x1 Prise britannique x1 Enchufe del Reino Unido x1 UK tengi x1 EU plug x1 Prise UE x1 Enchufe de la UE x1 ESB stinga x1...
  • Page 4 Switch Speed - (Adjustable speed (-) in all dynamic modes) 9 modes (RGB colors running in 8 different modes and 1 RGBW four-color running), each mode after running for a period of time automatically switched to another mode, cyclic switching. Brightness + (Adjustable brightness (+) for all static lights) Brightness - (Adjustable brightness (-) for all static lights) Dynamic Start/Pause...
  • Page 5: Care Instructions

    CAUTION: Do not allow children to replace batteries. Do not recharge. Insert correctly(+/-). Do not heat or throw in fire, battery may explode, leak and cause damage. Do not mix old, new or different brands. Store in a cool dry place and out of direct sunlight. ATTENTION : Ne laissez pas les enfants remplacer les piles.
  • Page 6 This device complies with Part 15 of the FCC Rules. CAN ICES-005(B) / NMB-005(B) Compliance. Operations are subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. CAUTION: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 7 También tiene derecho a la reparación o reemplazo de los bienes, si éstos no cumplen con una calidad aceptable y el fallo no constituye un fallo importante. Costco Wholesale UK Ltd / Costco Wholesale Iceland ehf. Costco Wholesale Sweden AB Costco Online UK Ltd Kauptún 3-7, 210 Gardabaer...
