GENERAL PUMP
FEATURES / BENEFITS
•
Direct hand-crank rewind with locking pin
•
Solid stainless steel construction
DIMENSIONS (in/mm)
D30001SS
D30002SS
General Pump
is a member of
the Interpump Group
A member of the Interpump Group
SPECIFICATIONS
PART NUMBER
3/8" Hose Capacity
Pressure Rating
Max. Temp
D30001SS & D30002SS
D30001SS
50 ft.
Inlet
Outlet
•
Stainless steel swivel with internal ball bearings
Hose Reels
D30002SS
100 ft.
4000 PSI
3/8" NPT-F
3/8" NPT-F
250° F
Ref 301174 Rev A
03-25
Advertisement
Related Manuals for Interpump GENERAL PUMP D30001SS
Summary of Contents for Interpump GENERAL PUMP D30001SS
- Page 1 D30001SS & D30002SS GENERAL PUMP A member of the Interpump Group Hose Reels SPECIFICATIONS PART NUMBER D30001SS D30002SS 3/8" Hose Capacity 50 ft. 100 ft. Pressure Rating 4000 PSI Inlet 3/8" NPT-F Outlet 3/8" NPT-F Max. Temp 250° F FEATURES / BENEFITS •...
- Page 2 D30001SS & D30002SS GENERAL PUMP A member of the Interpump Group Hose Reels PARTS LIST Part No. Description Qty. Part No. Description Qty. 2103352S Base Assy., Mounting, 50' 2200134S Bolt, HHCS, M6x118, SS, 50' 2103353S Base Assy., Mounting, 100' 2200136S...
