Page 1 User Guide HD Radio™ Portable Player with Belt Clip NS-HD01A...
Page 2: Table Of Contents
90-day limited warranty ......27 Introduction Congratulations on your purchase of a high-quality Insignia product. Your NS-HD01A represents the state of the art in HD Radio™ design and is designed for reliable and trouble-free performance. Important safety instructions Read these instructions.
Page 3: Additional Safety Information
HD Radio™ Portable Player with Belt Clip Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
Page 4: Features
Ten (10) station presets • 3.5 mm output jack • Full-color screen • Built-in lithium-ion rechargeable battery Package contents • HD Radio portable player • Belt Clip • Earphones • USB cable for charging the battery • User Guide •...
Page 5 HD Radio™ Portable Player with Belt Clip Front Item Description Press to tune to the next higher frequency. Press and hold to fast-foward through frequencies. For more information, see “Manually tuning to a frequency” on page 17. Press to tune to the next lower frequency.
Page 6 For more information, see “Automatically tuning to a station” on page 15. Enter In HD Radio mode, press to switch between the normal display and guide display. For more information, see “Viewing the guide in HD Radio mode”...
Page 7 HD Radio™ Portable Player with Belt Clip Item Description Earphone jack Plug the included earphones into this jack. Sides Item Description CHARGE Connect the included USB cable into this port and into a USB port on a computer to charge the built-in battery or to power your radio.
Page 8: Lcd Information
NS-HD01A Item Description HOLD Push this control in the direction of the arrow to lock the buttons to prevent accidental button presses. Push in the opposite direction to unlock the buttons. For more information, see “Locking the buttons” on page 19. VOLUME+/–...
Page 9: Hd Radio Mode
HD Radio™ Portable Player with Belt Clip Radio band Preset number Hold (lock) Battery charge Frequency Seek mode Volume level Sound state HD Radio mode HD Radio logo Preset number Hold (Lock) Battery charge Station name Channel number www.insigniaproducts.com...
Page 10: Using Your Radio
NS-HD01A Seek mode Volume level Sound state Frequency Song Title Artist Signal strength Using your radio Checking the battery level If the battery indicator on the LCD looks like this: , the battery level is low. Charge the battery by following the instructions below.
Page 11: Using The Belt Clip
HD Radio™ Portable Player with Belt Clip When charging is complete, the following screen appears: The display automatically turns off after five minutes. You can disconnect your radio from the computer. Note If you press a button while the battery is charging, the normal display appears.
Page 12 When receiving an FM signal, the “FM” icon appears on the display. HD Radio mode HD Radio mode is the new digital mode for FM. Many HD Radio stations have several sub-channels called “multicast channels. ” When receiving an HD Radio signal, the “HD” icon and the channel number appear on the display.
Page 13: Turning Your Radio On Or Off
HD Radio™ Portable Player with Belt Clip RBDS mode RBDS (Radio Broadcast Data System) mode provides additional functionality to FM radio reception by transmitting encoded analog information with the FM radio signal. This signal is decoded by an RBDS receiver and can provide a range of informational features including the station’s name.
Page 14: Adjusting The Volume
NS-HD01A Then one of the following screens appears: Analog (FM) mode HD Radio mode RBDS mode • To turn off your radio, press for about two seconds. The following message appears on the display: Adjusting the volume Caution Listening to your radio with the volume set too loud or using earphones for extended periods of time can damage your hearing.
Page 15 HD Radio™ Portable Player with Belt Clip To adjust the volume: • Turn the VOLUME+/– control to increase the volume or down to decrease the volume. The volume indicator on the display shows the new volume level. RBDS mode HD Radio mode...
Page 16 In HD SEEK mode, each time you press , your radio goes to the next higher sub-channel. When your radio reaches the highest sub-channel, it goes to the first sub-channel of the next higher HD Radio station. • Press to automatically tune to the next lower HD Radio station.
Page 17 0.2 MHz. • Press and hold to fast-forward or fast-reverse through frequencies. To manually tune to a frequency in HD Radio mode: for less than one second. Your radio goes • Press to the next higher sub-channel for the current station.
Page 18 NS-HD01A Press and hold PS+ or PS–. The preset number blinks. Analog (FM) mode HD Radio mode RBDS mode Press PS+ or PS– to increase or decrease the preset number. Analog (FM) mode HD Radio mode RBDS mode When you find the preset number you want to use, press and hold PS+ or PS–.
Page 19: Locking The Buttons
The lock icon disappears from the display. Viewing the guide in HD Radio mode To view the guide in HD Radio mode: When tuned to an HD Radio station, press Enter. The guide opens. Press Enter again to close the guide and return to the normal display.
Page 20: Using The Menu
NS-HD01A Using the menu Your radio has a menu that lets you adjust radio options. To use the menu: Press MENU. The menu opens. LCD Off Time Press to highlight an option, then press Enter. You can select: • LCD Off Time—Lets you set the LCD off time. •...
Page 21 HD Radio™ Portable Player with Belt Clip Selecting the LCD time off mode To select the LCD time off mode: Press MENU to open the menu. LCD Off Time Press to highlight LCD Off Time, then press Enter. Press to highlight 10, 20, 30, 45, 60, ON (always on), then press Enter.
Page 22: Viewing Software Version Numbers
Enter. If you select ALL, your radio searches through all stations when you tune to frequencies or stations. If you select HD, your radio only searches through HD Radio stations when you tune to frequencies or stations. Press MENU to close the menu.
Page 23: Troubleshooting
HD Radio™ Portable Player with Belt Clip Resetting options to factory defaults To reset options to factory defaults: Press MENU to open the menu. Press to highlight Factory Default, then press Enter. to select YES or NO, then press Enter.
Page 24 (you may need to insert the end of a bent paper clip into the reset hole on the side of your radio to do this). The HD Radio™ You may be out of range of the HD Radio stations in sound keeps your area. switching...
Page 25: Specifications
HD Radio™ Portable Player with Belt Clip Specifications Frequency range 87.5 MHz - 107.9 MHz (200 KHz steps) Station presets FM: 10 External 3.5 mm stereo connection Volume 15 levels Display Fullcolor (128 × 128 pixels) Audio output 200mV RMS Input 5V DC 500mA battery 3.7V 750mAh Li-ion...
Page 26: Fcc Warning
Cet appareil numérique de la Classe B est conforme à la norme NMB-003 du Canada. Trademark statement HD Radio Technology manufactured under license from iBiquity Digital Corporation. U.S. and Foreign Patents. HD Radio™ and the HD, HD Radio, and “Arc” logos are proprietary trademarks of iBiquity Digital Corp. www.insigniaproducts.com...
Page 27: 90-Day Limited Warranty
HD Radio™ Portable Player with Belt Clip 90-day limited warranty Insignia Products (“Insignia”) warrants to you, the original purchaser of this new NS-HD01A (“Product”), that the Product shall be free of defects in the original manufacture of the material or workmanship for a period of 90 days from the date of your purchase of the Product (“Warranty Period”).
Page 28: Where Is The Warranty Valid
NS-HD01A To obtain in-home warranty service for a television with a screen 25 inches or larger, call 1-888-BESTBUY. Call agents will diagnose and correct the issue over the phone or will have an Insignia-approved repair person dispatched to your home. Where is the warranty valid? This warranty is valid only to the original purchaser of the product in the United States, Canada, and Mexico.
Page 29 HD Radio™ Portable Player with Belt Clip PERIOD. SOME STATES, PROVINCES AND JURISDICTIONS DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE OR PROVINCE TO PROVINCE.
Page 30 www.insigniaproducts.com (877) 467-4289 Distributed by Best Buy Purchasing, LLC 7601 Penn Avenue South, Richfield, MN USA 55423-3645 © 2012 BBY Solutions, Inc. All rights reserved. INSIGNIA is a trademark of BBY Solutions, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners. ENGLISH 12-0121...
