Energy Star Floor Fryers
Models:
177FFES40L, 177FFES40N, 177FFES50L,177FFES50N, 177FFES70L, 177FFES70N
Warning:
Improper installation, adjustment, alteration, service, or maintenance can
cause property damage, injury, or death. Read the installation, operating,
and maintenance instructions thoroughly before installing or servicing this
equipment. If installing the fryer with propane (LP) gas, a commercially
approved regulator MUST be installed on the fryer in addition to the tank
regulator. Units installed without an external appliance regulator will cause
damage to parts and will void the warranty.
www.AvantcoEquipment.com
User Manual
For Your Safety:
Do not store or use gasoline or other flammable vapors or
liquids in the vicinity of this or any other appliance.
Note:
Please read instructions thoroughly. Indoor use only.
06/2024
Advertisement
Table of Contents
Related Manuals for Avantco Equipment 177FFES40L
Summary of Contents for Avantco Equipment 177FFES40L
- Page 1 User Manual 06/2024 Energy Star Floor Fryers Models: 177FFES40L, 177FFES40N, 177FFES50L,177FFES50N, 177FFES70L, 177FFES70N Warning: For Your Safety: Improper installation, adjustment, alteration, service, or maintenance can Do not store or use gasoline or other flammable vapors or cause property damage, injury, or death. Read the installation, operating, liquids in the vicinity of this or any other appliance.
-
Page 2: Safety Precautions
User Manual Energy Star Floor Fryers Safety Precautions Before installing and operating this equipment, be sure everyone involved in its operation is fully trained and aware of precautions. Accidents and problems can be caused by failure to follow fundamental rules and precautions. -
Page 3: Table Of Contents
Models Your new equipment, like all Avantco equipment, has been designed and manufactured to meet the toughest standards in the industry. Each piece of Avantco Equipment is carefully engineered and designs are verified through laboratory tests and field installations. -
Page 4: Product Overview
Energy Star Floor Fryers Product Overview You will find that your new equipment, like all Avantco Equipment, has been designed and manufactured to meet the toughest standards in the industry. Each piece of Avantco Equipment is carefully engineered and designs are verified through laboratory tests and field installation. With proper care and field maintenance, you will experience years of reliable, trouble-free operation. -
Page 5: Specifications
User Manual Energy Star Floor Fryers Specifications Gas Suppy and Burner Information Supply pressure should be minimum of 5" W.C. for natural gas or 10" W.C. for propane. The fryer comes with 3/4" NPT male connector on a 1/2" pipe. 5"... -
Page 6: Installation Instructions
User Manual Energy Star Floor Fryers Installation Instructions Failure to comply with the following guide may cause damage and injury (sometimes fatal) and forfeits the warranty, relieving the Manufacturer of any liability. Before installation, use, and maintenance of the equipment, please read this manual carefully and keep it for any future consultation by the various operators. - Page 7 User Manual Energy Star Floor Fryers • Do not install in an environment lower than 41°F, higher than 113°F, or with humidity below 70%. The fryer is only intended to be used indoors in a proper ventilated and regulated space. •...
- Page 8 User Manual Energy Star Floor Fryers Step 2: Install the Legs (or optional casters) and Restraints A set of legs or casters is packed with the fryer. Mounting fasteners are pre-mounted on the baseplates. Raise fryer sufficiently to allow legs or casters to be screwed into the baseplate. For safety, “shore up” and support the fryer with an adequate blocking arrangement strong enough to support the load.
- Page 9 User Manual Energy Star Floor Fryers Step 3: Flue Installation NOTE: The flue must be assembled and installed onto the fryer prior to installation and use of the fryer. Unpack the flue box, flue wrap, and back panel FLUE WRAP AND PANEL HERE FLUE BOX HERE 2.
- Page 10 User Manual Energy Star Floor Fryers Step 4: Check Clearances and Ventilation Clearances Allow space for servicing and operation for technician. Installation must conform to all applicable codes. From Combustable Surfaces: • Minimum clearance of 6” (15 cm) from the sides of the fryer. •...
-
Page 11: Step 5: Gas Connection
User Manual Energy Star Floor Fryers Step 5: Gas Connection • The gas inlet is located on the lower rear of the fryer. Codes require that a gas shutoff valve be installed in the gas line ahead of the fryer. •... -
Page 12: Operation Instructions
User Manual Energy Star Floor Fryers Operation Instructions Failure to comply with the following operation instructions may cause damage and injury (sometimes fatal), and forfeits the warranty and relieves the Manufacturer of any liability. Before operation of the equipment, please read this booklet carefully and keep it for any future consultation by the various operators. -
Page 13: Lighting The Pilot
User Manual Energy Star Floor Fryers Lighting the Pilot (A) - Gas Valve (B) - Pilot Access Hole (C) - Thermostat Knob 1. Open the door. 2. Turn the thermostat (C) OFF. The thermostat is located behind the door. 3. Push the gas control valve knob and turn to OFF (see figure below, view A). Wait 5 minutes for unburned gas to vent. -
Page 14: First Use
User Manual Energy Star Floor Fryers First Use Before first use, remove all packing material and protective plastic from the surfaces of the unit. Fryers should be cleaned before operation (see “Cleaning” section). Make sure to clean the fryer vat, fryer baskets, and any additional accessories before installing. -
Page 15: Cooking Instructions & Tips
User Manual Energy Star Floor Fryers Extended Shutdown: 1. Turn the thermostat knob to OFF. 2. Push in the pilot knob and turn to OFF. 3. Remove all food product and fryer baskets from the oil vat. 4. Thoroughly drain the fryer. Refer to the “Draining the Fryer” section. 5. - Page 16 Add fresh shortening as needed. • Do not overfill baskets. Carefully lower basket into oil. • Recommended food product per basket for 177FFES40L/N & 177FFES50L/N models are 1.5 lb. • Recommended food product per basket for 177FFES70L/N model is 2.5 lb. •...
-
Page 17: Cleaning
Energy Star Floor Fryers Cleaning Avantco Equipment is constructed with the best quality materials and is designed to provide durable service when properly maintained. To expect the best performance, your equipment must be maintained in good condition and cleaned daily. Naturally, the frequency and extent of cleaning depends on the amount and degree of usage. -
Page 18: Cleaning Stainless Steel Surfaces
User Manual Energy Star Floor Fryers Cleaning Stainless Steel Surfaces WARNING: NEVER RUB WITH A CIRCULAR MOTION. NEVER USE A WIRE BRUSH, STEEL SCOURING PADS (EXCEPT STAINLESS), SCRAPER, FILE, OR OTHER STEEL TOOLS. DO NOT USE ORDINARY STEEL WOOL, as any particles left on the surface will rust and further spoil the appearance of the finish. -
Page 19: Troubleshooting
User Manual Energy Star Floor Fryers Troubleshooting Problem Reason Solution Thermostat dial not turned on. Turn on thermostat. Pilot is not lit. Light pilot. Gas supply is not turned on. Turn on gas supply. No Heat. Wire connections are loose. Contact warranty servicer.
