PERFORMANCE ADVANTAGE COMPANY K5029 Installation Instructions

P
ERFORMANCE
www.pactoolmounts.com
HOOKMOUNT KIT
For additional assistance call 888-514-0083 between 8AM-5PM EST or email: info@pactoolmounts.com
To avoid the risk of personal injury, property damage or product damage, please use the included
fasteners for mounting.
* The bracket must be securely mounted to a stable surface and material.
* When mounting bracket to PAC TRAC aluminum products P/N 7000, P/N 7020, P/N 7040,
P/N 7050 with the included Trac Lok inserts P/N 7016, torque the screws to a maximum 15 in-lbs.
* PAC recommends regular and frequent inspections to be certain of proper operation and installation.
MTG. HARDWARE
PAC Fastener Packet P/N 7022 (PARTIAL)
#10-24 x 1-1/4 S.S.
P/N 2047
Pan Head Screw
P/N 2049LN #10-24 S.S. Locking Hex Nut
P/N 2069LN
¼-20 S.S. Locking Hex Nut
¼-20 x 1 S.S.
P/N 2031
Flat Head Screw
P/N 2054 #10 S.S. Flat Washer
MTG. HARDWARE
PAC Fastener Packet P/N 2035
#10-24 x 1-1/4 S.S.
P/N 2038
Flat Head Screw
P/N 2069LN ¼-20 S.S. Locking Hex Nut
A C
DVANTAGE OMPANY
P/N K5029
CAUTION
QTY
(2)
P/N 2069LN
4
4
P/N 2049LN
2
2
4
QTY
2
2
INSTALLATION INSTRUCTIONS
7/32" DIA. (2)
HOOKMOUNT ATTACHMENT
(See INS-1029 for more installation information)
P/N 2069LN(2)
17/64" DIA. (2)
10"
ADJUSTAMOUNT ATTACHMENT
(See INS-1006 for more installation information)
FIGURE 1
(Thru Mounting Method)
10-2013
INS-K5029
17/64" DIA.
P/N 2031
P/N 2054(2)
P/N 2047(2)
P/N 2038(2)
