ATRIUM PROSTO LOFT
instrukcja montażu
assembly guide
Montageanleitung
Maksymalne obciążenie całych
schodów wynosi 600kg.
Maximum load of stairs is 600 kg.
Die maximale Belastung der
gesamten Treppe beträgt 600 kg
150
kg
Środki ostrożności / Precautions
/ Vorsichtsmaßnahmen:
14 elem.
ZA-233
MQ-218
(SQ-214/6)
BG-242
PP-90
PP-88
ZA-84
ZA-220
BS-245
BD-241
50
800
(900, 1000)
www.atriumsystem.eu
+48 32 609 00 00
www.facebook.com/atriumsystem
PS-247N
PQ-219
DR-188
RT-249
+RT-250
PK-246
RT-249
+RT-250
PS-247N
3070 - 3350
!
MO-77p
Advertisement
Summary of Contents for Atrium PROSTO LOFT
- Page 1 ATRIUM PROSTO LOFT 14 elem. www.atriumsystem.eu +48 32 609 00 00 instrukcja montażu www.facebook.com/atriumsystem assembly guide ZA-233 Montageanleitung PS-247N MQ-218 Maksymalne obciążenie całych PQ-219 schodów wynosi 600kg. Maximum load of stairs is 600 kg. Die maximale Belastung der gesamten Treppe beträgt 600 kg...
- Page 2 The instruction shows the typical set of ATRIUM PROSTO LOFT assembly: For atypical set the composition may differ from the one shown in the instruction Ø3, Ø5, Ø10, Ø12 für die...
- Page 3 (900, 1000) hst=165 hm=15,5 hst=H/(n+1) hst=170 hm=17 n=14 (typowy zestaw) hst=175 hm=19 (typical set) (typischer Set) hst=180 hm=21 hst=185 hm=22,5 hst=190 hm=24...
- Page 4 max. 5 mm 18 Nm...
