- Page 1 INSTRUCTION MANUAL 8-Person Round Picnic Table SKY9684 + SKY9685 + SKY9686 + SKY9687 Ver. 1...
-
Page 2: Tools Required
NOTICE Please retain these instructions for future reference. • Please do not exceed the weight limitations of this item. • Do not stand on or use any part of this item as a step ladder. • Firmly secure all bolts, screws, or knobs before use. •... - Page 3 PARTS TABLETOP BENCH SEAT SEAT SUPPORT I 2 PCS 4 PCS 4 PCS SEAT SUPPORT II SEAT SUPPORT III CROSSBAR 2 PCS 2 PCS 1 PC TABLE FRAME 1 PC...
-
Page 4: Product Assembly
BEFORE ASSEMBLY Locate and remove the protective covers from the mounting plates on the part C, D, and E seat supports. PRODUCT ASSEMBLY Locate and interlock the two part A tabletops, then place the assembly top-side-down on a covered, level surface. Attach the part G table frame to the part A tabletop assembly with eight part 1 screws. - Page 5 PRODUCT ASSEMBLY Locate one part C seat support and loosely attach it to the part G table frame with two part 2 screws. Repeat to attach three more part C seat supports. Locate the part F crossbar and attach it to the part C seat supports with four part 3 screws and four part 5 nuts, taking care to match the smaller angle of the crossbar with the gap between the seat supports.
- Page 6 PRODUCT ASSEMBLY Attach one part B bench seat to two part C seat supports with four part 2 screws, two screws per support. Repeat to attach a second part B bench seat to the remaining part C seat supports. Locate one part D seat support and one part E seat support, then attach them to one part B bench seat with four part 2 screws, taking care to attach the supports so the fastener holes on each support face away from each other.
- Page 7 PRODUCT ASSEMBLY Attach the part D & E seat supports to the part C seat supports with eight part 4 screws, and eight part 5 nuts, two screws and nuts per support. Attach the part 7 umbrella fastening knob to the part F crossbar. With a second person, care flip the assembly upright, then insert the part 6 umbrella hole cap in the opening in the center of the table.
-
Page 8: Help Center
HELP CENTER Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com CHAT Chat Support Product Inquiry Orders FAQ Product Assembly Returns & Refunds PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
