  • Page 1 User Guide Network Ticket Generator (SDS100 and POS Printer) V1.00...

  • Page 2: Copyright Notice

    4IPNET, INC. You may not alter or remove any copyright or other notice from copies of the content. All other brand and product names are claimed or registered marks of their respective companies or organizations.
  • Page 3 Pre-integrated with 4ipnet Controller/Gateway so that account generation becomes quick and easy to the operator, simply by a push of buttons on the device. 4ipnet provides SDS100 and a POS printer as a combo set called Network Ticket Generator. The followings are typical application scenarios: A small business who wishes to quickly set up a wireless service hotspot for charged internet service may purchase a HSG200 Gateway, and a Network Ticket Generators set.
  • Page 4 User Guide Network Ticket Generator (SDS100 and POS Printer) ENGLISH Below are two network diagrams examples using Network Ticket Generator combo set. (1) One HSG Gateway with one Network Ticket Generator set (2) One HSG Gateway with multiple Network Ticket-Generator sets - 3 - Copyright ©...
  • Page 5 RS232 devices to an Ethernet network for remote operation. If you will be deploying SDS100 independently to manage other serial devices, please carefully set the Serial Settings in SDS100 to match the operating needs of your serial device.

  • Page 6: Device Overview

    User Guide Network Ticket Generator (SDS100 and POS Printer) ENGLISH 2. Device Overview Panel Overview Top Panel Adapter Socket The power socket for connecting to an external power source (12V/1A) through the power adapter provided in the package. DC Socket...

  • Page 7: Bottom Panel

    When COM 1 and COM 2 are blinking simultaneously, this means that Terminal Server configuration is not set correctly. Please check the settings in Terminal Server of your 4ipnet Gateway/Controller. When COM 1 and COM 2 are turned on simultaneously, this means that the system is in safe mode.
  • Page 8 Press this button followed by selecting a number and press Enter will perform a specific action. The available combinations are as follows: FUNTION + 1 + ENTER: Print out the IP address of SDS100. FUNTION + 8 + ENTER: Enter panel test mode.

  • Page 9: Hardware Setup

    2. Attach POS printer to a power source, through adaptors provided in the package and turn on the power switch situated on the left side of the device. 3. Connect POS printer to the COM1 port of SDS100 by a RS-232 cable provided within POS printer package.
  • Page 10 User Guide Network Ticket Generator (SDS100 and POS Printer) ENGLISH If you are unable to get a reply from pinging SDS100, please refer to System Configuration and check that the network settings of Note: SDS100 and Gateway/Controller interface connected to are under the same subnet.

  • Page 11: System Configuration

    SDS100 is designed specifically to operate in conjunction with all 4ipnet Gateways/Controllers, including both HSG and WHG series. If you are not using default settings, before connecting SDS100 to your Gateway/Controller, some configurations steps are required. The configuration instructions for 4ipnet Gateways/Controllers and SDS100 are covered in the following sections.
  • Page 12 Attach SDS100 to a power supply using the adapter provided in the package. Connect the administrator PC to the Ethernet Port of SDS100 via an Ethernet cable. Launch a web browser and type in the default IP address of SDS100 in the address field (http://192.168.1.10), the web interface of SDS100 should appear.
  • Page 13 Connect administrator PC to your Gateway/Controller and access the WMI (web management interface). Step2: Enter the configuration page of the Service Zone which SDS100 will be connected to. Check to make sure that the network settings of SDS100 are under the same subnet as this service zone.
  • Page 14 Network Ticket Generator (SDS100 and POS Printer) ENGLISH Step3: Go to the configuration page for On-demand authentication; click Configure to edit Terminal Server settings. Enter the IP address (192.168.1.10) and Port (5000) of SDS100. Step4: Edit and enable desired billing plans. - 13 - Copyright ©...
  • Page 15 After completing the Hardware Setup and the devices are physically connected, the system is ready for operation. This section will describe how to operate SDS100 to printout tickets for enabled billing plans. 1. Select an enabled billing plan number on SDS100 by button.

  • Page 16: Appendix A. Sds100 Web Interface Summary

    User Guide Network Ticket Generator (SDS100 and POS Printer) ENGLISH Appendix A. SDS100 Web Interface Summary The attribute setting in this web interface is for COM 1 only. COM 2 uses default settings that are unchangeable. Serial Settings (corresponding to POS printer) Data Baud Rate Select the desired baud rate.
  • Page 17 This attribute is the integer between 0 ~ 9 that will be set as the password for unlocking the main panel. Utilities Firmware Upgrade Firmware of SDS100 can be upgraded by clicking the Apply button. Note: Upgrade preparations are required before upgrade, please refer to Appendix B. Firmware Upgrade Restart Click Apply to restart SDS100 device.

  • Page 18: Appendix B. Firmware Upgrade

    For technical support please contact support@4ipnet.com Step1: Place the new firmware of SDS100 on a local location (for example desktop) in the PC that is accessing SDS100’s web interface and performing the upgrade. Step2: Configure the TCP/IP settings of your PC with an IP address under the same subnet mask as SDS100.
  • Page 19 Network Ticket Generator (SDS100 and POS Printer) ENGLISH Step4: Click Apply of Firmware Upgrade in SDS100’s web interface. SDS100 will automatically restart and connect to tftpd32 server set in Step3 as a DHCP client, download the firmware and perform the upgrade.
  • Page 20 User Guide Network Ticket Generator (SDS100 and POS Printer) ENGLISH - 19 - Copyright © 4IPNET, INC. All rights reserved. 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
