- Page 1 THERMO PRODUCTS USER MANUAL GUENDA IDRO 5.0 MADE ITALY design & production 004330021 - REV.000...
- Page 2 APPLY TECHNICAL DATA LABEL...
-
Page 3: Table Of Contents
FLUE DISCHARGE ........................................8 HYDRAULIC SYSTEM ................................10 INSTALLATION AND SAFETY DEVICES ................................10 ANTI-CONDENSATION DEVICE (MANDATORY) ......................11 GUENDA IDRO 5.0 DETAILS .............................. 12 ON/OFF ............................................12 FEATURES ................................... 13 CHECKS AND MEASURES FOR COMMISSIONING ......................13 THE PELLET LOAD MOTOR DOES NOT FUNCTION: ..........................13 BULB THERMOSTATS - REARM .................................. -
Page 4: English
We thank you for having chosen our company; our product is a great heating solution developed from the most advanced technology with top quality machining and modern design, aimed at making you enjoy the fantastic sensation that the heat of a flame gives, in complete safety. WARNINGS This instructions manual is an integral part of the product: make sure that it always accompanies the appliance, even if transferred to another owner... - Page 5 RECEIVED INSTRUCTIONS ON SAFE USE OF THE APPLIANCE AND THAT THEY UNDERSTAND THE INHERENT DANGERS. Š THE GENERATOR MUST NOT BE USED BY PERSONS (INCLUDING CHILDREN) WITH REDUCED PHYSICAL, SENSORY AND MENTAL CAPACITIES OR WHO ARE UNSKILLED PERSONS, UNLESS THEY ARE SUPERVISED AND TRAINED REGARDING USE OF THE APPLIANCE BY A PERSON RESPONSIBLE FOR THEIR SAFETY.
-
Page 6: Routine Maintenance
THAT SWITCH THE GENERATOR OFF. IF THIS OCCURS, CONTACT THE TECHNICAL AFTER-SALES SERVICE AND ALWAYS DISABLE THE SAFETY SYSTEMS. Š IN THE EVENT THE FLUE CATCHES FIRE, USE SUITABLE SYSTEMS FOR SUFFOCATING THE FLAMES OR REQUEST HELP FROM THE FIRE BRIGADE. -
Page 7: Installation
INSTALLATION GENERAL The support surfaces and/or points must have a suitable load-bearing capacity to support the weight of the appliance, of the accessories and coatings. The generator must be on the level for correct operation. The flue extraction and hydraulic connections must be carried out by qualified personnel who must issue documentation of conformity according to the regulations of the country of installation. -
Page 8: Ventilation And Aeration Of The Installation Premises
VENTILATION AND AERATION OF THE INSTALLATION PREMISES Ventilation, in the case of a non-watertight generator and/or non-watertight installation, must be carried out respecting the minimum area indicated below (considering the largest of the values suggested: Percentage of the Minimum net opening value of the Appliance categories Reference standard net opening section with respect to the... - Page 9 SHARED CHIMNEY FLUE Check on the CE Technical Data Sheet whether the product is suitable for installation in a shared chimney flue (i.e. with multiple connection). Suitable devices can be installed in shared flue systems provided that: Š installation in a shared chimney flue (i.e. with multiple connection) is allowed in the place of installation; Š...
-
Page 10: Hydraulic System
Standards in force, national, regional and municipal, as well as these instructions. For Italy, installation must be carried out by professionally qualified staff (Ministerial Decree dated 22.01.08 n°37). Extraflame S.p.A. declines all responsibility for damage to objects and/or persons caused by the system. TYPE OF SYSTEM Š... -
Page 11: Distances Of Safety Devices According To The Standard
DISTANCES OF SAFETY DEVICES ACCORDING TO THE STANDARD The temperature safety sensors must be in place on the machine at a distance no greater than 30 cm from the flow connection. Whenever the generators lack a device, those missing can be installed on the generator flow pipe, within a distance no greater than 1 m from the machine. COMMISSIONING CHECKS Before connecting the boiler: a) wash all system piping thoroughly in order to remove any residues which might compromise the correct functioning of certain system... -
Page 12: Guenda Idro 5.0 Details
GUENDA IDRO 5.0 DETAILS Room air outlet Heat exchanger scrapers Door handle Heat exchanger scrapers Access to the ash drawer Pellet hopper Room air outlet Not used Fumes exhaust ON/OFF Fuse Power supply 230V Combustive air input HYDRAULIC INSTALLATION 3 bar safety drain... -
Page 13: Features
FEATURES Water content of the thermo-product heat exchanger (l) Volume of expansion vessel integrated into thermo-product (l) 3 bar safety valve integrated into the thermo-product Minimum and maximum pressure switch integrated into the thermo-product Pump integrated into the thermo-product Pump max. head (m) * ENVISION ANY INTEGRATIVE EXPANSION VESSEL ON THE BASIS OF THE SYSTEM WATER CONTENT. -
Page 14: Stove Positioning
STOVE POSITIONING For correct product functioning, it is recommended to position it in a way that it is perfectly level, with the aid of a spirit level. NOTE FOR CORRECT OPERATION ENSURE THE HOPPER IS PROPERLY CLOSED BEFORE TURNING ON THE DEVICE! Pellet hopper lid DURING START-UP: The generator performs a check on the combustion air flow during the START phase. -
Page 15: Pellets And Loading
PELLETS AND LOADING Pellets are made by subjecting wood shavings i.e. the rejects of pure unpainted wood from sawmills, carpentry products and products from other activities connected to wood working and transformation, to very high pressures. This type of fuel is fully ecological as no glues are used for its compaction. In fact, pellet compactness is guaranteed over time by a natural substance found in wood: lignin. -
Page 16: Remote Control
REMOTE CONTROL The remote control can be used to adjust the main stove functions. Transmitter Select air mode* Display Lock keyboard On/off stove (hold for 3 seconds) Degrees Celsius / Fahrenheit Set power Press the button once to enable or disable the chrono Set switch-off delay: The button allows to set the switch- off delay. -
Page 17: Remote Control Icons
REMOTE CONTROL ICONS Air mode selected: * Enable chrono Flashing COMFORT Light on = activated On AUTO Light off = deactivated Indicates the transmission of the radio signal Set switch-off delay * On = during all radio communication Off = radio communication absent Battery low Keys locked Set power level. -
Page 18: Control Board
CONTROL BOARD VIEWING OF VARIOUS TO ACCESS ON/OFF TEXT MESSAGES THE MENU BUTTON OPERATING POWER TEMPERATURE ICON KEY Indicates the presence of an alarm. Indicates the status of the weekly programming Off: indicates that there are no alarms Off: deactivated. On: indicates the presence of an alarm On: activated. -
Page 19: General Menu
GENERAL MENU Go back - exit Scroll parameters: next (3); previous (2) Change settings data: increase (4); decrease (5) Confirm - access menu VENTILATION ENABLING SPEED EASY SETUP SET THERMOSTAT CHRONO ENABLING PRG1 PRG2 SETTINGS DATE-TIME PRG3 LANGUAGE PRG4 DISPLAY STAND BY FIRST LOAD OUTLET AIR... -
Page 20: First Ignition Settings
FIRST IGNITION SETTINGS After connecting the power cord at the back of the generator, turn the switch (if any) to position (I). The switch is used to power the heat generator board. DATE-TIME This menu allows the date and time to be set. CONTROLS PROCEDURE Š... -
Page 21: Operation And Logic
OPERATION AND LOGIC IGNITION Once the points listed previously have been checked, press key 1 for three seconds to ignite the stove. 15 minutes are available for the ignition phase. After ignition and having reached the control temperature, the stove interrupts the ignition phase and switches to STARTING. PREPARATION During the preparation phase, the stove stabilises combustion, increasing it progressively, then switches to WORK. -
Page 22: Additional Thermostat
ADDITIONAL THERMOSTAT N.B. : INSTALLATION MUST BE PERFORMED BY AN AUTHORISED TECHNICIAN It is possible to control the temperature of a room adjacent to the room where the stove is positioned; simply connect a thermostat following the procedure described in the following section (it is advisable to place the optional mechanical thermostat at a height off the ground equal to 1.50 m). -
Page 23: Ventilation
VENTILATION This menu allows to enable or disable the operation of the tangential motor and to adjust the speed (-2, -1, 0, +1, +2) of the front fan. The SET THERMOSTAT allows to set the room temperature to be reached (front ventilation must be active). Once the temperature set in SET TEMPERATURE has been reached, the ventilation will turn OFF and then it will turn back on when required. -
Page 24: Chrono
CHRONO This function allows stove ignition and switch-off to be automatically programmed. The factory setting for CHRONO is off. The chrono allows the programming of 4 time slots per day, which can be used every day of the week. For each time slot, it is possible to set ignition and switch-off times, specific days of application, desired temperature and set power. Current day and time settings are essential for the correct operation of the Chrono. - Page 25 EXAMPLE OF CHRONO OVERLAPPING TIMES/SLOTS TIME SLOT 02:00 08:00 16:30 23:00 SET POWER 02:00 08:00 16:30 23:00 SET H2O 72° 68° 02:00 08:00 16:30 23:00 Start 02:00 Time slot 1 Power 3 - SET H2O 72°C Stop 23:00 Start 08:00 Time slot 2 Power 1 - SET H2O 68°C Stop 16:30...
-
Page 26: Settings
SETTINGS Š DATE-TIME Š LANGUAGE SEE CHAPTER: FIRST IGNITION SETTINGS Š SET DEGREES DISPLAY This menu allows you to adjust the brightness of the display. The values range from OFF, 1 to 20. If set to OFF, the display backlighting is set to maximum brightness and turns off after a 60 second delay. -
Page 27: Outlet Air
OUTLET AIR This function allows any air in the stove to be discharged. By activating the pump function, it will be powered alternatively with 30 second work phases and 30" stop for 15 minutes. With the stove cold and "OFF", activate the OUTLET AIR function and press 6 to confirm. To interrupt, press and hold key 1 for 3 seconds. -
Page 28: Additional Functions
ADDITIONAL FUNCTIONS KEYS LOCKED This function allows you to lock the display keys (similar to mobile phones). With the function active, each time a key is pressed, the message “KEYS LOCKED" will appear To lock the keypad, press keys 1 and 5 simultaneously until the following message appears: "KEYS LOCKED" To unlock the keypad, press keys 1 and 5 simultaneously until the following message appears: "KEYS UNLOCKED"... -
Page 29: Cleaning And Maintenance
TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR GO TO THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM CLEANING AND MAINTENANCE ALWAYS FOLLOW THE INSTRUCTIONS IN COMPLETE SAFETY! Š Make sure that the power cord is unplugged because the generator may have been programmed to switch on. -
Page 30: Combustion Chamber
COMBUSTION CHAMBER By means of a mechanical system, the burn pot is cleaned automatically at preset intervals. It is however advisable to remove any residues by using a vacuum cleaner. Š Suck the ash deposited between the partition and the fire holder (1). Š... -
Page 31: Ash Drawer
PERSON, SO AS TO AVOID ALL RISKS. TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR GO TO THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM ROUTINE MAINTENANCE PERFORMED BY QUALIFIED TECHNICIANS Routine maintenance must be performed at least once a year. - Page 32 TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR VISIT THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM THE IMAGES ARE FOR ILLUSTRATIVE PURPOSES. Fumes motor (disassembly and cleaning and fumes pipe and "T"), new silicone in the provided points Gaskets, pellet hopper, inspections, ash drawer and door (replace and apply silicone where indicated) Combustion chamber and heat exchanger (full cleaning) including ignition plug pipe Hopper (complete emptying and cleaning).
-
Page 33: Displays
DISPLAYS DISPLAY REASON Generator off START The start-up phase is in progress PELLET LOADING Continuous pellet feeding is in progress during the ignition phase IGNITION The ignition phase is in progress PREPARATION The PREPARATION phase is in progress WORK The normal work phase is in progress MODULATION The generator is working at minimum **BURN POT CLEANING... -
Page 34: Alarms
ALARMS DISPLAY EXPLANATION SOLUTION On: indicates the presence of an alarm Flashing: indicates the deactivation of the depression sensor. The alarm can be reset only if the fumes motor has stopped and 15 minutes Indicates the presence of an alarm. have passed since the alarm was displayed, by pressing the key ON/OFF for 3 seconds. - Page 35 The automatic cleaning of the burn pot is Check that the door closes correctly. Check that the burn pot is clear and blocked. **TRAPDOOR BLOCKED clean. The automatic cleaning of the burn pot is blocked. Burn pot dirty/clogged If the problem persists, contact the service centre. The door is not closed correctly.
-
Page 36: Disposal
DISPOSAL INFORMATION FOR MANAGEMENT OF ELECTRIC AND ELECTRONIC APPLIANCE WASTE CONTAINING BATTERIES OR ACCUMULATORS This symbol, which is used on the product, batteries, accumulators or on the packaging or documents, means that at the end of its useful life, this product, the batteries and the accumulators included must not be collected, recycled or disposed of together with domestic waste. Improper management of electric or electronic waste or batteries or accumulators can lead to the leakage of hazardous substances contained in the product. -
Page 37: Symbol En 16510-1
Symbol EN 16510-1 EN 16510-1 EXPLANATION Symbol Nominal heat output part Part load heat output CON / INT Appliance operation, Continuos (CON) or Intermittent (INT) / CO Carbon dioxide emission 2 nom 2 part / CO Carbon monoxide emission part Minimum distances to combustible materials - bottom Minimum distances to combustible materials - ceiling Minimum distances to combustible materials - floor in front... - Page 38 ENGLISH...
- Page 39 ENGLISH...
- Page 40 EXTRAFLAME S.p.A. Via Dell’Artigianato, 12 36030 - MONTECCHIO PRECALCINO (VI) - ITALY +39.0445.865911 - +39.0445.865912 - info@extraflame.it - www.lanordica-extraflame.com MADE ITALY design & production TO FIND THE SERVICE CENTRE NEAREST TO YOU CONTACT YOUR DEALER OR CONSULT THE SITE WWW.LANORDICA-EXTRAFLAME.COM...
