Mobile Support for DAHUA DHI-PKC-MS2E Interactive Screen

1. Introduction

Thank you for purchasing the DAHUA DHI-PKC-MS2E mobile stand! This product has

been designed exclusively for theDahua WhiteBoard interactive displays,

providing mobility, stability and ease of use. Please read this manual before using

the stand to ensure an optimal and safe experience.

2. Technical Specifications

Model:DHI-PKC-MS2E

Material:Heavy duty steel with anti-corrosion coating

Weight supported:Up to 100 kg Adjustable height:120 cm

to 180 cm

Compatibility:Only compatible with Dahua WhiteBoard displays

Wheels:4 wheels with integrated lock for greater stability

Adjustable tilt:15° back Color:Matte black

3. Product Components

Package Included:

1 mobile base with wheels.

2 adjustable vertical supports. 1 rear support

for the screen. Hardware (includes necessary

tools). Quick assembly manual.

4. Assembly Instructions

Tools needed:

Included in the package (hex key and screwdriver).

Steps:

Base assembly:

User Manual

Attach the wheels to the base using the screws provided. Make sure

either

the wheels are firmly installed and functional.

Need help?

Do you have a question about the DHI-PKC-MS2E and is the answer not in the manual?

Page 1 Mobile Support for DAHUA DHI-PKC-MS2E Interactive Screen 1. Introduction Thank you for purchasing the DAHUA DHI-PKC-MS2E mobile stand! This product has been designed exclusively for theDahua WhiteBoard interactive displays, providing mobility, stability and ease of use. Please read this manual before using the stand to ensure an optimal and safe experience.
Page 2 Attach the rear bracket to the vertical supports. Adjust the screws either according to the screen size. Mounting the interactive screen: Carefully place the Dahua WhiteBoard display onto the rear bracket. either Make sure to align the mounting points and use the provided hardware to secure it.
Page 3 7. Maintenance and Care Clean regularly with a soft, dry cloth. Avoid using abrasive chemicals. Periodically inspect bolts and wheels to ensure they are secure.
