Summary of Contents for B810 digicom Look BOX
- Page 1 8D5899 _ Look@BOX User’ Guide rev. 1.1 03/2021 ENGLISH ITALIANO...
-
Page 3: Table Of Contents
8D5899 _ Look@BOX Index - Preface INDEX PREFACE ................................. II ENVIRONMENTAL CONDITIONS ........................II CLEANING INFORMATION..........................II SHOCKS OR VIBRATIONS ..........................II BACKUP BATTERY ............................II EVALUATION BOARD/KIT IMPORTANT NOTICE AND DISCLAIMER ............II ASSISTANCE AND CONTACTS ........................II SAFETY WARNINGS ............................III INTRODUCTION ............................ -
Page 4: Preface
8D5899 _ Look@BOX Index - Preface All rights reserved; no part of this publication may be reproduced, stored in a retrieval system, or trasmitted in any form or by any means, electronic, otherwise, without the prior written permission of Digicom. The contents of this booklet may be modified without notice. Every possible care has been taken in testing and putting together all the documentation contained in this booklet, however Digicom can not take any responsability brought by the use of this booklet. -
Page 5: Safety Warnings
8D5899 _ Look@BOX Index - Preface SAFETY WARNINGS Read these instructions and norms carefully before powering the device. Violation of such norms may be illegal and cause hazard situations. For any of the described situations please refer to the specific instructions and norms. The device is a low power radio transmitter and receiver. - Page 6 8D5899 _ Look@BOX Index - Preface INFORMATION TO USERS according to Art. 26 "Information to Users" - Legislative Decree 14 March 2014, n. 49 "Actuation of the Directive 2012/19/ UE on the waste of electrical and electronic devices (RAEE)." The symbol of a crossed waste container marked on the apparatus or on its package indicates that at the end of its useful life the product must be collected separately from other waste materials.
-
Page 7: Introduction
8D5899 _ Look@BOX Introduzione INTRODUCTION Dear Customer, thanks for purchasing Look@BOX. Look@BOX is an IoT sensor for elevator designed to be installed on the car top and it has the task of “capturing” accelerometric tracks. Through specific algorithms it is able to identify for each elevator trip: up or down, travelling Time, Speed, traveled Distance, Blocks and unknown and abnormal Vibrations. -
Page 8: Mechanical Features
8D5899 _ Look@BOX Introduzione 1.3. MECHANICAL FEATURES • 17 pins terminal block • Plug-in SIM card (1,8V - 3V compatible) • External GSM antenna on SMA/f connector • Bracket for wall mounting • Dimensions: 115 x 80 x 45 mm •... -
Page 9: Installation
8D5899 _ Look@BOX Installation INSTALLATION 2.1. MECHANICAL INSTALLATION Look@BOX must be fixed on the cabin roof in order to detect the vibrations of the cabin during the trips. For a correct installation is necessary to use the bracket fixing. 1. Place temporarily the bracket on the wall where you want to install the device and mark the mounting points. -
Page 10: Interfaces Connection
8D5899 _ Look@BOX Installation 2.2. INTERFACES CONNECTION Antenna Power supply 1. Connect the GSM antenna found in the package to the SMA connector. ATTENTION: Apply the magnetic base of the antenna only on metal zone, without connection to earth. Please use eventually the metal support, find in the package, fixed it to the wall. 2. -
Page 11: Check After The Power On
8D5899 _ Look@BOX Installation 2.3. CHECK AFTER THE POWER ON After fixing of Look@BOX on the car roof and after connecting the interfaces (antenna, SIM card, power supply) it is possible to switch ON the device. Check that the status LED is initially RED on steady, then after a few minutes: •... - Page 13 NOTE...
- Page 14 NOTE...
- Page 16 Digicom S.r.l. ITALY • Viale Luigi Cadorna 95 20025 Legnano -MI- Tel. +39.0331.702611 www.digicom.it...
