Summary of Contents for Forney ADF
- Page 1 ADF WELDING MASK WITH HOOD OWNER’S MANUAL ENGLISH WWW.FORNEYIND.COM...
-
Page 2: Table Of Contents
Table of Contents WELDING HELMET AND WELDING GOGGLE SAFETY PRECAUTIONS -READ BEFORE USING ....3 1-1. SYMBOL USAGE ........................3 1-2. ARC WELDING HAZARDS ....................4 1-3. PROPOSITION 65 WARNINGS .....................5 1-4. LENS SHADE SELECTION TABLE ...................5 1-5. PRINCIPAL SAFETY STANDARDS ...................6 SPECIFICATIONS ..........................6 OPERATING INSTRUCTIONS ......................7 3-1. -
Page 3: Symbols Legend
WELDING HELMET AND WELDING MASK SAFETY PRECAUTIONS - READ BEFORE USING Protect yourself and others from injury — read, follow, and save these important safety precautions and operating instructions Symbols Legend MEANING SYMBOL SYMBOL MEANING DANGER! - Indicates a hazardous situation which, if not avoided, will result in death or serious injury. -
Page 4: Read Instructions
WELDING MASKS do not provide unlimited eye, ear and face protection. Arc rays from the welding process produce intense visible and invisible (ultraviolet and infrared) rays that can burn eyes and skin. Sparks fly off from the weld. • Use impact resistant safety spectacles or goggles and ear protection at all times when using the welding helmet. -
Page 5: Proposition 65 Warnings
California Proposition 65 Warning WARNING: Welding or cutting equipment produces fumes or gases which contain chemicals known to the State of California to cause birth defects and, in some cases, cancer. (California Health & Safety Code Section 25249.5 et seq.) WARNING: This product can expose you to chemicals, including lead, which are known to the state of California to cause cancer and birth defects or other reproductive harm. -
Page 6: Principal Safety Standards
Principal Safety Standards Safety in Welding, Cutting, and Allied Processes, ANSI Standard Z49.1, is available as a free down load from the American Welding Society at http://www.aws.org or purchased from Global Engineering Documents (phone: 1-877-413-5184, website: www.global.ihs.com). Safe Practice For Occupational And Educational Eye And Face Protection, ANSI Standard Z87.1, from American National Standards Institute, 25 West 43rd Street, New York, NY 10036 (phone: 212-642-4900, website: www.ansi.org). -
Page 7: Operating Instructions
OPERATING INSTRUCTIONS Auto-Darkening Mask Components The auto-darkening mask provide eye protection only. Use additional personal protection equipment (arc shield, face shield, balaclava, hard hat, etc.) To shield exposed skin and protect head. Use auto-darkening mask only for welding and cutting applications. Remove goggles when work is finished. -
Page 8: Lcd Screen And Controls
LCD Screen & Controls - Sensitivity & Grind Button - Shade & A/M Button - Delay & Auto Button + Sensitivity & Anti-light Interference Function Button + Shade & Cut/Weld Button + Delay Button Sensitivity Control - Sensitivity & Grind Button + Sensitivity &... -
Page 9: Variable Shade Control
Variable Shade Control - Shade & A/M Button + Shade & Cut/Weld Button • Press Button 1 for 0.1S to reduce the shade level; Press Button 1 for 1.5S to turn on or off auto shade function. Press Button 2 for 0.1S to increase the shade level;... -
Page 10: Replacing The Protection Plate
REPLACING THE PROTECTION PLATE Replacing The Front Protection Plate Head Lamp Face Shield Front Protection Plate Auto Darkening Mask • Take off the head lamp take off the face shield • Take off the front protection plate • Remove protective film on both sides of new protection plate •... -
Page 11: Replacing The Battery
REPLACING THE BATTERY Phillips Screw Battery Cover CR2032 Lithium Battery • Loosen screws securing battery cover. • Open battery cover. Replace with new CR2032 lithium battery REPLACING THE RUBBER CUSHION Rubber Cushion Auto-darkening Mask • Unlock the four clasps A, B, C and D. •... -
Page 12: Replacing The Head Lamp Protection Plate
REPLACING THE ADJUST HEADBAND Adjust Headband Hinge Assembly • Separate adjust headband from mask at hinges • Snap new adjust headband into hinges REPLACING THE HEAD LAMP PROTECTION PLATE Head Lamp Head Lamp Protection Plate • Remove the protection plate directly from the front of the head lamp and replace it WWW.FORNEYIND.COM... -
Page 13: Separating Face Shield
SEPARATING FACE SHIELD Head Lamp Face Shield Auto-Darkening Lens • Pull the head lamp away from the lens • Release A, B and C three clasps • Separate the face shield MAINTENANCE NOTICE - Never use solvents or abrasive cleaning detergents. NOTICE - Do not immerse the lens assembly in water. -
Page 14: Troubleshooting
MAINTENANCE Problem Possible Solution Press the button, the lens LCD Check batteries and verify they are in good condition and installed properly check battery screen does not display. surfaces and contacts, and clean if necessary. Check battery for proper contact and gently adjust contact points if necessary. This is particularly important if the mask have been dropped. -
Page 15: User Notes
USER NOTES ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ WWW.FORNEYIND.COM... - Page 16 Forney Industries, Inc. 2057 Vermont Drive Fort Collins, CO 80525 800-521-6038 www.forneyind.com...
