Congratulations on your CASTLECREEK purchase.
We're proud to help you furnish and enhance the place you call home.
Whether indoors or outside, CASTLECREEK is the perfect choice for comfortable living
at an exceptional value.
Item #712754 CASTLECREEK 47" Fire Pit with BBQ Grate
For assistance with your product, please contact the Sportsman's Guide customer service at
1-800-888-3006 or go to sportsmansguide.com/customerservice/contactus
Save these instructions for future reference for anyone that is assembling or operating this product.
Read and understand all warnings, cautions, and assembly instructions prior to assembling or using
this product. Failure to do so may result in property damage, serious injury, or death.
Confirm all parts are present and undamaged before assembly. Please contact Sportsman's Guide
Customer Service for any replacement parts before assembly and use.
sportsmansguide.com
712754-CC Fire Pit with BBQ Grate
1 of 8
Advertisement
Table of Contents
Related Manuals for Sportsman's Guide CASTLECREEK 712754
Summary of Contents for Sportsman's Guide CASTLECREEK 712754
- Page 1 Read and understand all warnings, cautions, and assembly instructions prior to assembling or using this product. Failure to do so may result in property damage, serious injury, or death. Confirm all parts are present and undamaged before assembly. Please contact Sportsman's Guide Customer Service for any replacement parts before assembly and use.
-
Page 2: Warnings And Cautions
WARNINGS AND CAUTIONS WARNING: NEVER attempt to modify this product or subject it to an installation or use for which it was not designed. Doing so may result in property damage, serious injury or death. WARNING: For outdoor use only. NEVER use in any building, garage, other enclosures or under any structure. -
Page 3: Tools Required
TOOLS REQUIRED Phillips Head Screwdriver Adjustable open end wrench PARTS LIST Swing Handle Lift Handle Cooking Grate Cooking Grate Pole L-Pin Table Pane Fire Bowl Support Ring Section-A Support Ring Section-B HARDWARE M6 x 14 Bolt M6 x 20 Bolt M6 Nut Wing Bolt sportsmansguide.com... - Page 4 ASSEMBLY INSTRUCTIONS Step 1: Attach (4) legs (H) to fire bowl (F) with (12) M6 x 14 bolts (J) Step 2: Insert one support ring section (G1) into （G2） and attach the support ring assembly to leg (H) with M6 x 14 Bolt（J） (4) M6 x 14 bolts (J) as illustrated.
- Page 5 ASSEMBLY INSTRUCTIONS Step 3: Secure (4) support ring sections (G) with (4) M6 x 14 bolts (J). Step 4: Insert (2) the pins on table panels (E) into the fixed brackets on the fire bowl (F) as illustrated .Connect table panels (E) with (8) M6 x 20 bolts (L) and (8) M6 nuts (M).
- Page 6 ASSEMBLY INSTRUCTIONS Step 5: Insert the Grate(C1) and Pole(C2) were connected by M6 x 14 Bolt(J) Attach the lift handle (B) to cooking grid(C) with (2) M6*14bolts (J) as illustrated . Attach the swing handle (A) to cooking grid (C) with (2) M6 x 14 (J) and (2) M6 nuts (M) as illustrated.
-
Page 7: Use And Maintenance
USE AND MAINTENANCE • Before attempting to start a new fire, remove accumulated ash so that the log supports on the bottom of the fire bowl are fully exposed. Placing your kindling and logs on top of these supports will allow air to get underneath for easier fire starting and more efficient burning. •... - Page 8 SG12.24EB sportsmansguide.com 712754-CC Fire Pit with BBQ Grate 8 of 8...
