Smart-Bus SB-DN-R0816 Instruction Manual

High power relay 8ch 16a

Advertisement

Quick Links

SB-DN-R0816
High Power Relay 8Ch 16A
Instruction Manual
Features
8 x 16A Feed Throw outputs
Latching free voltage Relay Suitable for
use with ON/OFF lights, water heater,
Pumps, heavy machine and Industry
Use.
Manual override switch
8 switch manual override for each
channel work even when no supply
Surge Protection
Each module has capacitors and
voltage-sensitive resistors for surge
protection power line
Simple Installation
Din Rail Mount, Standard 35mm guide
rail mounting, with Elegant Plastic for
Module Name
Areas and Scenes
Up to 8 independent areas, each with
up to 12 scenes, with Fade time of 0
seconds to 60 minutes
ON Delay Protection
To use for industry use and have load
machine , Window AC that needs On
Delay Protection Time
Green Product
Bus enabled , Powered by 15-32 VDC,
Powered by Bus Low Voltage
Consumption 12mA/24VDC
Broadcast Address Button
To broadcast the Module Address to the
Programming software
Data line Short Protection
Protection
for
Change, or connect to data terminal
Life statues LED
LED Indicator, blinking to indicate that
Module powered and bus connected
Sequence Feature
2 Sequences of 8 steps each 1.0 second
to 60 minutes With Optional steps times,
and Running modes.
Restore Function
Device restored to previous scene or
Specific scene after Power Restore to
the Module
1
Bus
Power
Polarity

Advertisement

loading
Need help?

Need help?

Do you have a question about the SB-DN-R0816 and is the answer not in the manual?

Questions and answers

Summary of Contents for Smart-Bus SB-DN-R0816

  • Page 1 SB-DN-R0816 High Power Relay 8Ch 16A Instruction Manual Features 8 x 16A Feed Throw outputs Green Product Latching free voltage Relay Suitable for Bus enabled , Powered by 15-32 VDC, use with ON/OFF lights, water heater, Powered by Bus Low Voltage...
  • Page 2 Layout description 1- A-H: 8 channel output terminal to connect to the Load 2- 4 switch manual override for each 1-4 channels 3- Module broadcast address keystroke and Life statues LED. 4- Com, Data-, Data +, DC 24 V 485 S-bus connection terminal. 5- Labeling Plastic place.
  • Page 3 Installation Steps 1. Mount the device on a DIN rail inside an approved enclosure. 2. Calculate loads to ensure any channels are not overloaded, and then connect loads to the output channels. The maximum loading of this device is as follows: - Maximum channel load: 16Amps - Maximum device load: 8*16 Amps 3.
  • Page 4 Load Connection Product specifications Feed throw output Relay : Latching relay up to 16A per channel Power consumption: (without operation): 12mA/24V, (with operation Relay ON/OFF) 35mA/24V Control Inputs: 1 x RS485 S-Bus, Module Powered by Bus connection Working Ambient Temperature: -10° to 45°C, Ambient Humidity, 20% to 85% RH Storage Temperature: -20°...
