RadiSys PM4264S Quick Start Manual

GPON Home Gateway
PM4264S
1. Product Overview
The GPON Home Gateway Unit (HGU) is an ITU-T G.984 ONT designed for delivery of telephone services,
IP-base data services, and IPTV video services to single-family homes and small office/home office (SOHO)
users. It is designed for indoor installa�on and can be desktop or wall-mounted. A single op�cal fiber
carries upstream and downstream traffic over GPON between the OLT and the ONT and it is fully
provisioned and managed from the OLT using PLOAM/OMCI and TR069.
2. Package contents
• PM4264S • Power Adapter • QIG (Quick Guide)
3. Speci ca on
3.1 Device Parameters
SPI FLASH 128MB Power Supply
Power
DDRIII 256MB (2Gbit)
Con n
2.4GHz 2x2 802.11ax Dimensions
WiFi
5GHz 2x2 802.11ax ( W* D * H)
1 * SC/APC, Class B+ GPON Port
Port 4 * 10/100/1000Mbps (RJ45) LAN Weight
2 * (RJ11) FXS port
Downstream up to 2.488Gbps Opera g
Bandwidth
Upstream up to 1.244Gbps Max requirement
3.2 Rear View
Item
LAN1~4
Supply: 110V AC to 240V AC
Adapter: DC 12V/1.5A
RESET
< 18 Wa s (Max)
ON/OFF
WPS/Wi-Fi bu on
190mm* 154mm* 40mm
516g
Temperature :0ºC to +40ºC
Humidity: 5% to 85% Non-condensing
Descrip
Use Ethernet cables (with RJ45 connectors) to connect home network devices
Press 1~4 seconds The device will reboot (restart).
Press >4 seconds Factory reset is performed by long press
Click to turn the device on or
Press 0~5 seconds, execute WPS for both WiFi.
Press >5 seconds, turn on/o Main and Guest WiFi
