FORE SHOT CO-8 Manual

Carbon Monoxide Detector
(CO-8, CO-8-F1)
The CO-8-P2 is a wireless Carbon Monoxide Detector that is capable of detecting the dangerous presence of
CO in your surroundings and immediately raising alarm according to the different levels of CO concentration
detected. The Carbon Monoxide Detector also features long battery life, self-diagnostics function, and loud
siren for audio alert.

Parts Identification
1. Dual Color LED (Amber & Red)

When the battery voltage is low, the Amber LED will flash every
45 seconds.

When any fault condition is detected by self-diagnostics test, the
Amber LED will flash every 5 seconds.

While the Carbon Monoxide Detector is transmitting signal, the
RED LED will flash

While Carbon Monoxide is alarming, the Red LED will flash
quickly.

During Alarm Silence, the Red LED will flash once every
second.

When battery is exhausted, both the Red LED and the Amber
LED will flash once every 4 seconds.

The LED indicator will flash twice when receivng acknowledgement
from the Control Panel.
2. Learn/Test Button
Press the button to:

Transmit a learn/test signal for device learning or radio range
test.

To silence alarm temporarily after alarm activation.
Press and hold the button for 10 seconds to:

Perform self-diagnostics function.
3. Battery Compartment Cover
4. Mounting Holes
5. Mounting Bracket

Battery
 3 "AA" 1.5V alkaline batteries are used to supply power.
 The Carbon Monoxide Detector has a battery life of approximately 9 years.
 When Carbon Monoxide Detector detects low battery voltage, a low battery signal will be
transmitted along with regular signal transmissions. The Amber LED will flash and the Carbon
Monoxide Detector will emit a beep every 30 seconds.
When the battery is exhausted, remove the battery compartment cover and replace with new

batteries.

Supervision
 After installation, the Carbon Monoxide Detector will automatically transmit Supervisory Signals
to the Control Panel at random intervals of 15 to 18 minutes.
