Precautions:
1. Polaris accept no responsibility for any consequences caused by drivers' illegal operations while
driving! Do not install or disassemble the mirror DVR by an unprofessional technician！
2. Polaris recommend installation or maintenance of the mirror DVR to be by persons who are
trained in electronic equipment and auto parts.
3. Polaris accept no responsibility for any consequences caused by non-licensed and unqualified
technicians installing or disassembling the mirror DVR by themselves!
4. It is prohibited to use power cords and rear lens extension cords other than those that come
standard with the mirror DVR as this may void warranty.
5. It is prohibited to forcefully bend or use heavy objects to squeeze the power cords and rear lens
extension cords as this may void warranty.
6. Please do not use the memory card for storage purposes other than the mirror DVR to avoid
causing abnormalities in the storage system.
7. When exposed to strong sunlight, the camera may overexpose causing the image to be unclear -
This is a normal phenomenon based on optical principles.
8. Polaris recommend cleaning the lens once a week to ensure clear viewing.
Reminder:
1. The mirror DVR will have a notice message if there are too many locked videos.
2. It is recommended to regularly format the SD card in the mirror DVR system to extend the service
life of the memory card.
3. Please use real Class10 U3 high-speed SD cards - The SD card writing speed must not be lower
than 30MB/S.
4. If the "Sentinel Mode" function is turned on, when the mirror DVR detects that the car battery
voltage is lower than 11.7V, the mirror DVR will stop working to prevent the car from being unable
to start due to excessive consumption of the car battery.
5. When the screen brightness is automatically adjusted, if you feel that the screen is too bright, you
can enter the settings page to change the backlight adjustment from automatic to manual
adjustment and press and hold the right 1/3 of the screen to slide up and down to adjust the
screen brightness.
Advertisement
Table of Contents
Summary of Contents for Polaris RVM966
- Page 1 1. Polaris accept no responsibility for any consequences caused by drivers' illegal operations while driving! Do not install or disassemble the mirror DVR by an unprofessional technician！ 2. Polaris recommend installation or maintenance of the mirror DVR to be by persons who are trained in electronic equipment and auto parts.
- Page 2 1. RVM966 Product Overview: Speaker Bracket & back plate Replacement mounting arm Power button System hardware reset hole SD card slot Main harness Adjustable front camera Power Button Usage Instructions: Function 1: Screen rest function When the mirror DVR is on, short press the [Power Button] to put the screen into sleep mode. At this time, the mirror DVR’s recording function is still running in the background.
- Page 3 2. Video Recording Interface Screen Gesture Operation: Function 1: On the right side of the screen, slide up or down to adjust the screen brightness. (Need to set in the menu: automatic brightness is off) Function 2: In the middle of the screen, slide from left to right to enter the playback interface. Item Item Recording status indication and recording...
-
Page 4: Video Playback
3. Video Playback In the video recording interface, slide from left to right in the middle of the screen to enter the video playback interface. Front Cam Image data recorded by the front camera Rear Cam Image data recorded by the rear camera Ratio Play video files proportionally. - Page 5 Click on the file thumbnail to enter the file playback interface. Item File name, Normal: normal video; Front: video recorded by the front lens; REC20191009-121536-0001.MP4 is parsed as: the first file recorded at 12:15:36 on October 9, 2019. Volume adjustment when playing files File playback progress bar, you can drag the button directly to change the playback position Previous file...
- Page 6 Picture playback interface. Item File name, Normal: normal video; Front: picture taken by the front lens; REC20191009-121536-0001.Jpg is parsed as: the first file taken at 12:15:36 on October 9, 2019. Previous picture Next picture Return to the previous interface View the memory card in PC: Read the file in the computer through the card reader and open the SD card drive letter to get: Item Event...
-
Page 7: System Settings
4. System settings Click the "System Settings" button at the bottom of the recording interface to enter the system setting interface. Back Return to the previous interface Loop Time The length of each recorded video file can be set: 1 minute, 2 minutes, 3 minutes Gsensitivity For the collision sensor (G-sensor) to sense acceleration, set it to [High] sensitivity. -
Page 8: Wifi Function
Info Mirror DVR software version information Check GPS satellite status and the current positioning latitude and longitude. (After positioning is completed, the current direction of the vehicle and its current speed will appear on the right side of the screen.) Timezone Change timezone Calibration... -
Page 9: Hardware Specifications
6. Hardware specifications Name Specification Model N7（manufacturer） ARM Cortex-A7 single Core 800MHz System (0S) Linux Deep Customized Car System Expand storage Max 256GB Class10 U3 Micro SD card Display 9.66” IPS 1920*480 Full viewing panel Touch operation Full screen multi-touch Image resolution Front cam: HDR 1920*1080P Rear cam: HDR 1920*1080P... - Page 10 7. RVM966 Installation and Wiring Attaching the mirror DVR: 1. Attach the installation bracket for your vehicle to the rear of the mirror monitor. 2. Remove the original mirror 3. Different cars have different brackets, it depends on your vehicle maker and manufacturer - There are many methods to remove the original rearview mirror, however please don’t force the mirror off the...
