1.0 INTRODUCTION TO THE REMOTE
POWER CONTROL SWITCH (RPC)
The BayTech RPC-Series is a full-featured AC power management
solution that provides an easy way to control power of remote equipment.
From your office or from anywhere, the RPC will TURN ON, TURN
OFF, OR REBOOT remote equipment.
There are six different RPC models. Four models operate at 115 VAC, 15
Amp. Two models operate at 230 VAC, 10 Amp.
115 VAC, 50/60 Hz, 15 Amp
RPC-2: Six receptacles and an EIA-232 connection.
RPC-2 MD01: Six receptacles, EIA-232 connection, and a
RPC-2 RDR: Six receptacles, EIA-232 connection, and Ring
RPC-3: Eight receptacles, Ethernet and EIA-232 connections.
RPC-5: (15amps per receptacle) Four receptacles, Ethernet and
230 VAC, 50/60 Hz, 10 Amp
RPC-2A: Six receptacles and an EIA-232 connection.
RPC-3A: Eight receptacles, Ethernet, and EIA-232
1.1 ABOUT THIS USERS MANUAL
The RPC Owner's Manual is a user's guide for all models of the RPC
Series. To find the appropriate operating instructions, please identify the
particular RPC model you are using.
2400 bps Modem.
Detect Reset.
EIA-232 connections.
connections.
