Meteo Control WEB'LOG COMFORT Quick Start Manual

WEB'LOG WEB'LOG
WEB'LOG WEB'LOG
COMFORT COMFORT
COMFORT COMFORT
Quick Start Guide
English | GENERAL
As at 10.12.2013
SAFETY INSTRUCTIONS FOR
INSTALLATION AND SYSTEM
START-UP
DANGER DANGER
DANGER DANGER
Electric shock hazard! Danger to life
and limb!
Touching any of the live components
can lead to an electric shock which
may result in burns or even death.
Installation work should be carried
out by a qualified electrician only.
Check the installation site on the
wall for any electrical cables.
Take care not to drill through any
cables.
ATTENTION ATTENTION ATTENTION ATTENTION
Overvoltages and incorrectly
connected cables can result in damage
to property!
Overvoltages and voltage peaks can
damage or destroy the device.
Protect the power supply against
overvoltages.
Connect cables only to the
respectively allocated sockets.
Observe the polarity while
connecting cables.
meteocontrol GmbH | Spicherer Straße 48 | 86157 Augsburg | Telephone +49 (0)821 34666 - 88 (Support)
Fax +49 (0)821 34666 - 11 | E-mail info@meteocontrol.de | Web www.meteocontrol.de
WALL INSTALLATION WALL INSTALLATION
(1) Remove cover (4) Unhang device (4) Unhang device
(2) Device (5) Wall (5) Wall
(3) Hang device (6) Fastening screws (6) Fastening
Take note of the HW no. on the Take note of the HW no. on the
identification label on the back for identification label on the back for
configuration later on configuration later on
Remove the connector cover (1) Remove the connector cover (1)
Insert two screws (6) 164 mm apart Insert two screws (6) 164 mm apart
on the wall
Mount the device so that the screw Mount the device so that the screw
heads lie in the slots. heads lie in the slots.
Push the device dow Push the device down a short way
and check that it is positioned and check that it is positioned
correctly
Turn the screws until the device is Turn the screws until the device is
fixed in position
88 (Support) 1/4
