smartmicro DRVEGRD 169 UMRR-9F User Manual

Type 169
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Test report no. 23012695
EUT: DRVEGRD 169
Date: 2019-11-20
TÜV NORD Hochfrequenztechnik GmbH & Co. KG
LESKANPARK, Gebäude 10, Waltherstr. 49-51, 51069 Köln, Germany
FCC ID: W34UMRR9FA9
Annex acc. to FCC Title 47 CFR Part 15
s.m.s, smart microwave sensors GmbH
Annex no. 5
User Manual
Functional Description
Title 47 - Telecommunication
Part 15 - Radio Frequency Devices
Subpart C – Intentional Radiators
ANSI C63.4-2014
ANSI C63.10-2013
Created: Trepper
Page 1 of 23
FCC Title 47 CFR Part 15
relating to
DRVEGRD 169
Reviewed: Ftouhi
Date of issue: 2022-08-09
Released: Hittig-Rademacher
Tel.: +49 221 8888950
Vers. No. 3.19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DRVEGRD 169 UMRR-9F and is the answer not in the manual?

Questions and answers

Related Manuals for smartmicro DRVEGRD 169 UMRR-9F

Summary of Contents for smartmicro DRVEGRD 169 UMRR-9F

  • Page 1 Test report no. 23012695 Page 1 of 23 EUT: DRVEGRD 169 FCC ID: W34UMRR9FA9 FCC Title 47 CFR Part 15 Date of issue: 2022-08-09 Annex acc. to FCC Title 47 CFR Part 15 relating to s.m.s, smart microwave sensors GmbH DRVEGRD 169 Annex no.
  • Page 2 Test report no. 23012695 Page 2 of 23 EUT: DRVEGRD 169 FCC ID: W34UMRR9FA9 FCC Title 47 CFR Part 15 Date of issue: 2022-08-09 User Manual / Functional Description of the test equipment (EUT) Date: 2019-11-20 Created: Trepper Reviewed: Ftouhi Released: Hittig-Rademacher Vers.

  • Page 3: Project Title

    USER MANUAL DRVEGRD 169 UMRR-9F TYPE PROJECT TITLE: USER MANUAL DRVEGRD 169 UMRR-9F TYPE 169 PROJECT NO.: KEYWORD(S): DRVEGRD 169 UMRR-9F TYPE 169 RADAR SENSOR DATE: 24. AUGUST 2022 STATUS: IN PROGRESS s.m.s, smart microwave sensors GmbH Phone: +49 531 39023-0...

  • Page 4: Table Of Contents

    USER MANUAL DRVEGRD 169 UMRR-9F TYPE 169 1 CONTENTS Contents ......................2 Abbreviations ..................... 3 Introduction ......................4 General description ....................5 SENSOR SPECIFICATIONS ..................5 MEASUREMENT PRINCIPLE ................5 Transmit Signal .................... 7 General Performance Data ................7 Hardware ......................9 UMRR sensor ....................

  • Page 5: Abbreviations

    USER MANUAL DRVEGRD 169 UMRR-9F TYPE 169 2 ABBREVIATIONS Analog-to-digital converter Controller area network Digital signal processing; digital signal processor FMCW Frequency modulated continuous wave MMIC Monolithic microwave integrated circuit UMRR Universal medium-range radar Page 3 of 21 | 24. August 2022 Proprietary - This document may be subject to change without notice.

  • Page 6: Introduction

    USER MANUAL DRVEGRD 169 UMRR-9F TYPE 169 3 INTRODUCTION This document is a short documentation of the general purpose universal medium range radar (UMRR) UMRR-9F Type 169 radar sensor with type 169 antenna. Page 4 of 21 | 24. August 2022 Proprietary - This document may be subject to change without notice.

  • Page 7: General Description

    USER MANUAL DRVEGRD 169 UMRR-9F TYPE 169 4 GENERAL DESCRIPTION 1. SENSOR SPECIFICATIONS DRVEGRD 169 is a 79GHz radar sensor for multiple automotive applications that features 4D/PxHD technology. The sensor’s antenna aims at ultra-short, short and medium range and very wide horizontal angular coverage.
  • Page 8 USER MANUAL DRVEGRD 169 UMRR-9F TYPE 169 The result of tracking is an object list with the following parameters: X-position Heading angle Y-position Length Absolute velocity Object ID and more In addition, status and diagnose data from the sensor are reported. The sensor optionally reports such a list of all tracked objects in every measurement cycle of typically ~55ms length.

  • Page 9: Transmit Signal

    USER MANUAL DRVEGRD 169 UMRR-9F TYPE 169 TRANSMIT SIGNAL The UMRR transmit frequency is in the band from 77 GHz to 81 GHz, the used bandwidth is less than 4 GHz. The maximum transmit power is +26 dBm. Antenna type 169 consists of three transmit and four receive antennas, which are linear polarized.
  • Page 10 USER MANUAL DRVEGRD 169 UMRR-9F TYPE 169 Table 4-1: General performance data Environmental Ambient Temperature -40 ... +85 degree C Shock Vibration Pressure / Transport Altitude 0…10.000 Mechanical Weight ≤186 Dimensions 79 x 97 x 22,45 Housing Identification Antenna Identification...

  • Page 11: Hardware

    USER MANUAL DRVEGRD 169 UMRR-9F TYPE 169 5 HARDWARE UMRR SENSOR An example picture of a DRVEGRD 169 UMRR-9F Type 169 sensor is shown in the figures below, see Figure 5-1 and Fehler! Verweisquelle konnte nicht gefunden werden.. Figure 5-1: Front view of DRVEGRD 169 Figure 5-2: Rear View of DRVEGRD 169 Page 9 of 21 | 24.

  • Page 12: Sensor Dimensions

    USER MANUAL DRVEGRD 169 UMRR-9F TYPE 169 SENSOR DIMENSIONS The dimensions of DRVEGRD 169 UMRR-9F Type 169 are given in mm, see Figure 5-3. Figure 5-3: Dimensions of sensor DRVEGRD 169 Sensor Rear Side Left Side Sensor Front Side Top Side Page 10 of 21 | 24.

  • Page 13: Cables And Connectors

    USER MANUAL DRVEGRD 169 UMRR-9F TYPE 169 6 CABLES AND CONNECTORS SENSOR CONNECTOR The sensor connector mates with an 8-pin female connector for automotive interconnections (TE 1411001-1: water proof IP67, manufacturer TE). The pin numbering of the female connector is shown in Figure 6-1 and Figure 6-2.
  • Page 14 USER MANUAL DRVEGRD 169 UMRR-9F TYPE 169 Figure 6-1: The pin out of the connector Figure 6-2: Diagram of cable-FF0035 and rear view of female counterpart Table 6-1: Sensor connector pin-out Pair Label DSUB-9-w DSUB-9-w Banana 1411001-1 CAN1 CAN2 plug...
  • Page 15 Please note that in the standard configuration the sensor has 120 Ohms resistor on board (CAN bus termination between CAN_L and CAN_H). A number of cable sets for initial operation and test purposes are offered by Smartmicro, to deliver a fast set-up of a sensor system. Page 13 of 21 | 24. August 2022 Proprietary - This document may be subject to change without notice.

  • Page 16: Data Interfaces

    USER MANUAL DRVEGRD 169 UMRR-9F TYPE 169 7 DATA INTERFACES CAN DATA INTERFACE This specification gives a detailed description of the CAN data communication used in the UMRR based systems on the sensor CAN. The UMRR is compliant with CAN 2.0B standard.
  • Page 17 USER MANUAL DRVEGRD 169 UMRR-9F TYPE 169 Figure 7-1: CAN bit timing for UMRR sensor Figure 7-2: CAN bit timing as defined by the CAN protocol Page 15 of 21 | 24. August 2022 Proprietary - This document may be subject to change without notice. The...

  • Page 18: Application-Specific Characteristics

    FUNCTIONAL SAFETY The sensor can optionally be made compliant to ASIL Level B in customer-specific projects. Requirements and safety concepts need to be agreed between an OEM and smartmicro. AUTOSAR The sensor is offered with AUTOSAR compliant software in customer-specific projects.

  • Page 19: Compliance For Europe

    USER MANUAL DRVEGRD 169 UMRR-9F TYPE 169 9 COMPLIANCE FOR EUROPE SIMPLIFIED DECLARATION OF CONFORMITY Hereby, s.m.s, smart microwave sensors GmbH declares that the radio equipment type UMRR-9F Type 169 is in compliance with the Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: http://www.smartmicro.de/company/quality-certificates/.

  • Page 20: Declaration Of Conformity

    Modifying the device without smartmicro’s authorization may result in the device being no longer compliant with FCC requirements. In that event, your right to use the device may be limited by FCC regulations, and you may be required to correct any interference to radio or television communications at your own expense.

  • Page 21: Label

    USER MANUAL DRVEGRD 169 UMRR-9F TYPE 169 10.2 LABEL Figure 10-1: FCC Label Sample of DRVEGRD 169 EU Label Sample of DRVEGRD 169 Page 19 of 21 | 24. August 2022 Proprietary - This document may be subject to change without notice. The...

  • Page 22: Declaration Of Conformity For Canada

    USER MANUAL DRVEGRD 169 UMRR-9F TYPE 169 10.3 DECLARATION OF CONFORMITY FOR CANADA 10.3.1 DECLARATION OF CONFORMITY IN ENGLISH This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

  • Page 23: Industry Canada (Ic) Label

    USER MANUAL DRVEGRD 169 UMRR-9F TYPE 169 10.3.3 INDUSTRY CANADA (IC) LABEL Figure 4: Example Label of Canada Page 21 of 21 | 24. August 2022 Proprietary - This document may be subject to change without notice. The information shall remain the exclusive property of s.m.s, smart microwave sensors GmbH.
