MODEL : # GD4231-B2
Distributor's: Vanston Inc.
WARNING
Improper installation,
adjustment, alteration, service
or maintenance can cause
injury or property damage.
Read
this instruction manual
thoroughly before installing or
servicing this equipment.
WARNING
1. Do not store or use
gasoline or other
flammable
vapors
liquids in the vicinity of
this or any other appliance.
2 . An LP tank not connected
for use should not be
stored in the vicinity of
this
or
any
appliance.
DANGER
If you smell gas:
1.
Shut off gas to the
appliance.
2.
Extinguish any open flames.
3. Open the lid.
4. If the odor continues，keep
away from the appliance and
immediately call your gas
supplier or fire department.
WARNING
For Outdoor Use Only
and
other
1
Advertisement
Table of Contents
Related Manuals for Savor Pro GD4231-B2
Summary of Contents for Savor Pro GD4231-B2
- Page 1 MODEL : # GD4231-B2 Distributor’s: Vanston Inc. WARNING Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read this instruction manual thoroughly before installing or servicing this equipment. WARNING 1. Do not store or use gasoline or other...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Information Package Contents Hardware Contents Preparation Assembly Instructions Installation Instructions Operating Instructions Care and Maintenance Troubleshooting Warranty... -
Page 3: Safety Information
SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. If you have any questions regarding the product, please call customer service at 888-509-1721, 8 a.m-5 p.m., EST, Monday-Friday, or contact us by email, savorpro grill customer service@vanston-inc.com. - Page 4 SAFETY INFORMATION DANGER: If the information in above is not followed exactly, a fire causing death or serious injury may occur. The outdoor cooking gas appliance must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure testing of the gas supply system at test pressures equal to or less than 1/2 PSI (3.5 KPa).
-
Page 5: Package Contents
Package Contents... -
Page 6: Hardware Contents
Part Part Description Description Right side table Right front leg Gas cylinder safety stop Main burner assy (side) Left side table Leg insert Front panel of side table Cart front panel Warming rack Wheel axle Cooking grate 7" wheel Heat tent Left front leg Drip tray Left rear leg... - Page 7 X 16...
- Page 15 INCORRECT REGULATOR ASSEMBLY The regulator and hose should not be routed through the gap between the bottom of firebox and the top of cart. Incorrect assembly will result in loss of warranty. Incorrect assembly may cause gas leakage, fire and severe bodily harm. The regulator and hose assembly must be routed through the hole of the left side panel into the cart.
- Page 16 WARNING: The Type I connective coupling (see Fig.24) supplied with your grill must not be replaced with a different type of grill/tank connection system. Removal will result in loss of warranty, gas leakage, fire and severe bodily harm. The propane tank valve connection supplied with this grill incorporates four important safe guards: Hand Assembly, Hand Disassembly, Excess Flow Control and Temperature-Activated Shut-Off.
- Page 17 c. Excess Flow Control The propane regulator assembly incorporates an excess flow device designed to supply the grill with sufficient gas flow under normal conditions yet control excess gas flow. Rapid changes in pressure can trigger the excess flow device providing a low flame and low temperature.
-
Page 18: Locating The Grill
LP GAS System Contact your gas supplier for a special regulator for bulk gas that fuels other appliances. Gas Consumption Total gas consumption of this grill with the burner(s) on “MAX” Table 1 below. Table 1 Burner Type BTU/HR Main Burners 10,000 Locating the Grill This gas appliance is designed and certified for outdoor use only. -
Page 19: Assembly Instructions
Grill Lighting Instructions To Light the Main Burners 1 .Make sure the control knobs are in the “OFF” position. 2 .Open the grill hood. 3 .Check the ignition pin position and distance between the pin and the burner. 4 .Make sure the drip tray is installed. 5 .Open the LPG tank. - Page 20 Checking the Flame Refer to Fig.26 below (side view of grill) for where to check the flame after the grill is lit. Make sure you have a stable, mostly blue flame. Fig.26 Match Lighting Instructions IMPORTANT: The hood must be open when match lighting any burner. 1.
- Page 21 5. The center burner (if needed) can be lit from center grid by inserting the match clip into the front side of heat tent. Light this burner before igniting both outside burners. 6. Depress burner valve for that burner and turn to “MAX.” 7.
- Page 22 Checking Gas Leaks Before operating your grill, after refueling, check carefully to be certain that all connections are tight and there are no gas leaks. 1: Make 2-3 ounces of leak solution by mixing liquid dishwashing soap with water. 2: Make certain all control knobs are in the “OFF” position. 3: Brush small amounts of the leak solution on all the fittings and turn the gas on.
- Page 23 WARNING: Do not attempt to turn off the LP tank valve without first covering your hand with a protective mitt or allowing the grill to cool down. Failure to follow this warning could result in a severe burn. LP Gas Safety Requirement For LP gas grills, the LP gas supply tank to be used must be: Constructed and marked in accordance with the Specifications for LP Gas Tanks of the US.
- Page 24 Handling the Liquid Propane Tank Safely Remember to handle your portable liquid propane tank carefully when you take it to your dealer for a refill. Avoid dropping it or bumping it against sharp objects. Liquid propane tanks are sturdily constructed, but a series of hard jolts could damage the container.
- Page 25 WARNING: When not connected to your grill, the LP gas tank must be stored in an upright position in a cool, shady, well-ventilated, outdoor location away from your grill or any other heat source. Failure to follow this warning could lead to tank valve damage, fire hazard and personal injury. Refilling a Propane Tank It is extremely important that your LP tank be filled properly when you take it to be refilled.
- Page 26 Do not use abrasive cleaners on the polished surface. Use caution when cleaning. Metal polish or mild chrome cleaner can be used to bring back luster and highlights. Naval jelly can be used to remove rust stains that occur from outside sources. Follow the naval jelly instructions carefully.
-
Page 27: Care And Maintenance
Hood up when grilling meats, especially chicken. Hood down when indirect or rotisserie cooking. NEVER leave your grill unattended while cooking. After use, close hood, turn burners to “MAX” for 15 min. for self-cleaning, grease burn off. Care and Maintenance Time Table Chart Frequency Based on Normal Use Cleaning Method Grill Item... - Page 28 Many solutions given here can make your grilling experience safer and more enjoyable. You can also call customer service department at 888-509-1721, 8 a.m. - 5 p.m., EST, Monday-Friday, or contact us by email, savorprogrill customerservice@vanston-inc.com. Problem Possible Cause Corrective Action 1.
- Page 29 Problem Possible Cause Corrective Action 1. Refill the LP Tank. LP tank is empty. Excessive flare-up. 2. Install the burner correctly. Burner is not aligned with the control valve. 3. Check the gas supply hose Gas supply is not sufficient. and make sure there are no leaks and no knots.
-
Page 30: Warranty
If you have any questions or problems, you can call our customer service department at 888-509-1721, 8 a.m. - 5 p.m., EST, Monday-Friday, or contact us by email, savor pro grill customer service@vanston-inc.com. Limited Warranty 5-Year Warranty on stainless steel burners...
