SiTime SiT95210 Manual

Ultra low jitter, programmable frequency, 4 outputs quad pll clock generator
Hide thumbs Also See for SiT95210:
Table of Contents

Advertisement

Quick Links

Download this manual
SiT95210
Ultra Low Jitter, Programmable Frequency, 4 Outputs
Quad PLL Clock Generator

Description

SiT95210
offers programmable Quad Fractional Frequency
translation-based jitter cleaning clock generator parts with
flexible input to output frequency translation options. Ultra-
high performance PLL supports up to 4 Diff/8 Single Ended
input clocks that are common for all the 4 fractional
translations and provides 4 clock outputs. The clock outputs
can be derived from any of the 4 PLLs in a fully flexible
manner.
It is fully programmable with the I2C/SPI interface or an
on chip one-time programmable non-volatile memory for
factory pre-programmed devices.

Applications

Carrier Ethernet,
◼
OTN Equipment,
◼
Microwave Backhaul,
◼
Gigabit Ethernet,
◼
Wireless Infrastructure,
◼
Network Line Cards,
◼
Small Cells,
◼
Data Center/Storage,
◼
SONET/SDH,
◼
Test / Instrumentation,
◼
Broadcast Video
◼
Product
Inputs / Outputs
Family
SiT95210
4 Diff / 8 SE Inputs
Rev 0.51

Features

◼
◼
◼
◼
◼
◼
◼
◼
◼
◼
◼
◼
◼
Input Freq
Output Frequency
200 KHz -2.1 GHz
0.5 Hz - 2.94912 GHz
21 March 2025
PRELIMINARY
Ultra-high Performance PLLs
Fully Integrated design with no external components
Sub 70fs Typical RMS integrated jitter (12k-20M)
122.88M Output with excellent close in noise
performance
Fully Flexible Output and Input Mux: High level of
flexibility in output allocation for PLLs
JESD204B/C Support for data converter clocks
External EEPROM Support
Frequency Control DCO: DCO Control on all outputs
(down to 0.001 ppt)
Phase Control DCO: Fine phase adjustment knob for
phase of all outputs from a PLL (adjustment accuracy
< 1ps) in both closed loop and open loop modes
Repeatable input to output delays with output relative
delay adjust
Internal ZDB Mode with < 0.5 ns Input to Output delay
variation. Independently available for each PLL
Outputs can be phase aligned on independent sync
pulse
44 QFN 7 mm x 7 mm Package
RMS Jitter
~ 70 fs typ (QFN)
Packages
44 QFN
www.sitime.com
