RKC INSTRUMENT REX-C100 Series Instruction Manual

Hide thumbs Also See for REX-C100 Series:

Advertisement

Quick Links

REX-C100
Notes:
Make sure that this Instruction Manual is always readily available to personnel who use the REX-C100 series.
The contents of the Instruction Manual are subject to change without notice. If you have any questions regarding the manual,
contact one of our sales people, our nearest sales office, or the place where you have purchased the controller.
1.
PRODUCT CHECK
Check whether the delivered product is as specified by referring to the following model code list.
O O
Model code
Î
Control action
F : PID action [Reverse action]
D : PID action [ Direct action]
Ï
Input type
See input range table "Model code" page 9
Ð
Input range
See input range table "Model code" page 9
Ñ
Control output [OUT]
M : Relay contact
V : Voltage pulse
8 : Current 4 to 20mA DC
G : Trigger (for triac driving) *1
Ò
First alarm [ALM1]
N : No first alarm
A : Deviation high alarm *2
B : Deviation low alarm *2
C : Deviation high / low alarm *2
D : Band alarm
E : Deviation high alarm *3
F : Deviation low alarm *3
G : Deviation high / low alarm *3
H : Process high alarm *2
J : Process low alarm *2
K : Process high alarm *3
L : Process low alarm *3
R : Control loop break alarm *4
SERIES
C100 QQQ - Q~ QQ
Î Ï Ð
-1-
INSTRUCTION
MANUAL
Ñ
Ò Ó
Ó
Second alarm [ALM2]
N : No second alarm
A : Deviation high alarm *2
B : Deviation low alarm *2
C : Deviation high / low alarm *2
D : Band alarm
E : Deviation high alarm *3
F : Deviation low alarm *3
G : Deviation high / low alarm *3
H : Process high alarm *2
J : Process low alarm *2
K : Process high alarm *3
L : Process low alarm *3
P : Heater break alarm (CTL-6)
S : Heater break alarm (CTL-12)
R : Control loop break alarm *4
*1
When control output is trigger output
for triac driving, only the first alarm
is
available.
*2
Without hold action.
*3
With hold action
*4
As control loop break alarm, only
either
the first alarm or second alarm is
selected.
C
Confirm that power supply voltage is also
the same as that specified when
ordering.
Accessories
C
Mounting brackets
C
Instruction manual
(2 pcs.)
(1 copy)
