LIFESAVER
MODEL SL240
REMOTE VISUAL SIGNALLING DEVICE
(STROBE LIGHT)
IMPORTANT !
READ ALL INSTRUCTIONS BEFORE INSTALLATION AND LEAVE THIS
MANUAL FOR THE OWNER FOR FUTURE REFERENCE.
WARNING !
THIS VISUAL SIGNALLING DEVICE HAS NO DETECTION MEANS AND MUST
BE USED IN CONJUNCTION WITH COMPATIBLE AND APPROVED SMOKE
ALARMS. THIS IS NOT A STAND ALONE DEVICE.
WARNING !
DISCONNECTING OR LOSS OF AC POWER WILL RENDER THIS STROBE
LIGHT INOPERATIVE.
CONTENTS OF THIS MANUAL
1...SPECIFICATIONS
2...APPLICATIONS
3...RECOMMENDED LOCATIONS OF VISUAL SIGNALLING DEVICES
4...LOCATIONS TO AVOID
5...INSTALLATION INSTRUCTIONS
6...TAMPER RESIST LOCKING PIN
7...TESTING AND OPERATION
8...MAINTENANCE
9...LIMITATIONS OF ALARM CONTROLLED VISUAL SIGNALLING DEVICE
10...GOOD SAFETY HABITS
11...WARNING - INSULATION TEST
12...WARRANTY AND LIABILITY
WARNING: Do not try to repair Strobe Light yourself.
No User Replacement Parts Inside.
Refer to instructions in Section 8 for maintenance.
WARNING!
THIS STROBE LIGHT IS EXTREMELY BRIGHT, DO NOT LOOK DIRECTLY AT
THE LIGHT OR TOUCH THE LENS WHEN THE LIGHT IS FLASHING.
1. SPECIFICATIONS
MODEL NUMBER
ELECTRICAL RATING
Multiple station (24) interconnect unit interfaces directly with Smoke Alarm Models
Lifesaver 1255, 3800, 3800R, 4800, 4800R, SMOTEC 3786,
COMPLIANCE
FLASH RATE
TEMPERATURE LIMITS
MOUNTING
APPLICATIONS
LIGHT OUTPUT
The following diagram shows that the light intensity gradually decreases as the viewing angle is increased. Use
this information to determine the best location for the strobe light.
SL240 (3 WIRE INTERCONNECT UNIT)
240Vac, 50Hz, 80mA Standby 4.3 A inrush, 2.2 A
peak, 580 mA when operating.
Underwriters Laboratories (UL1971) and
American With Disabilities Act (ADA)
1 flash per second nominal
0°C to 49°C
Wall or Ceiling
Primary Direct or Indirect and Supplementary
177 Candela minimum (on axis measurement)
USER MANUAL
AUSTRALIAN ELECTRICAL
AUTHORITY CS96313V
1
Advertisement
Summary of Contents for Lifesaver SL240
- Page 1 240Vac, 50Hz, 80mA Standby 4.3 A inrush, 2.2 A peak, 580 mA when operating. Multiple station (24) interconnect unit interfaces directly with Smoke Alarm Models Lifesaver 1255, 3800, 3800R, 4800, 4800R, SMOTEC 3786, COMPLIANCE Underwriters Laboratories (UL1971) and American With Disabilities Act (ADA)
-
Page 2: Installation Instructions
The Strobe Light may be located less than 2m above the floor. VISIBLE SIGNAL ATTENTION ! The model SL240 Strobe Light is designed to notify hearing impaired individuals of impending danger. They MUST be used in conjunction with operating Smoke or Heat Alarms. - Page 3 5.2.13 Make certain that all devices in the interconnect system are wired to a continuous (non-switched) final sub circuit. FIGURE 1 INTERCONNECT WIRING DIAGRAM FOR SL240 WIRE ON STROBE LIGHT HARNESS..CONNECTED TO BLACK......N (Neutral) WHITE......SW (Interconnect Wire) RED......
-
Page 4: Testing And Operation
To make your Strobe Light tamper resistant, a locking pin has been provided with your Strobe Light. Using this pin will deter individuals from removing the Strobe Light from the trim ring. To use the pin, insert it into the hole in the side of the Strobe Light after the Strobe Light has been installed on the trim ring (see fig.6.). - Page 5 9. LIMITATIONS OF ALARM CONTROLLED VISUAL SIGNALLING DEVICES Visual signalling devices can provide early warning to hearing impaired individuals. However, in order for the visual signalling device to function, it must be activated by an operating alarm. Alarms cannot provide an activation signal to the visual signalling device if smoke, heat or carbon monoxide do not reach the specific alarm.
- Page 6 12.1 PSA Products Pty Ltd warrants that for three years from the date of purchase of the Visual Alarm, it will repair or replace the Visual Alarm (at the option of PSA Products Pty Ltd.) due to any manufacturing defect, at the cost of PSA Products Pty Ltd. (excluding any labour costs relating to removal or re-installation of product, and transport costs).
