- Page 1 LM192160BCW-2 LCD Module User Manual Prepared by: Checked by: Approved by: Dong Date: 2017-2-13 Date: Date: Rev. Descriptions Release Date Preliminary release 2017-2-13 URL: www.topwaydisplay.com Document Name: LM192160BCW-2-Manual-Rev0.1.DOC www.topwaysz.com Page: 1 of 11...
-
Page 2: Table Of Contents
Function Specifications ......................9 Adjusting the Display Contrast ..........................9 Resetting the LCD module ............................. 9 Display Memory Map ............................. 9 Command Table..............................10 Design and Handling Precaution ..................11 URL: www.topwaydisplay.com Document Name: LM192160BCW-2-Manual-Rev0.1.DOC www.topwaysz.com Page: 2 of 11... -
Page 3: Basic Specifications
: 85.4 x 84.6 x 11.5 MAX (See attached Outline Drawing for details) Block Diagram LCD Panel 192 x 160 pixels UC1611S DB0 ~ DB7 /CS, /RST, A0, /WR, /RD equivalent Back Light Circuit LEDEN URL: www.topwaydisplay.com Document Name: LM192160BCW-2-Manual-Rev0.1.DOC www.topwaysz.com Page: 3 of 11... -
Page 4: Terminal Functions
CLOSE CLOSE OPEN OPEN CLOSE CLOSE OPEN CLOSE CLOSE OPEN OPEN CLOSE JP10 OPEN OPEN CLOSE Note: *1. In I C Interface setting, R2 and R3 should be setup (10kΩ). URL: www.topwaydisplay.com Document Name: LM192160BCW-2-Manual-Rev0.1.DOC www.topwaysz.com Page: 4 of 11... -
Page 5: Absolute Maximum Ratings
Operating Voltage Input High Voltage 0.8xV /RST, /CS, RS, /WR, /RD, DB0~DB7 Input Low Voltage 0.2xV Operating Current 1 VDD (Backlight OFF ) Operating Current 2 76.5 VDD (Backlight ON ) URL: www.topwaydisplay.com Document Name: LM192160BCW-2-Manual-Rev0.1.DOC www.topwaysz.com Page: 5 of 11... -
Page 6: Ac Characteristics
Data setup time tds8 Data hold time tdh8 /RD access time (*2) tacc8 Output disable time (*2) tch8 Note: *1. Input signal rise/fall time should be less than 12ns *2. CL=100pF URL: www.topwaydisplay.com Document Name: LM192160BCW-2-Manual-Rev0.1.DOC www.topwaysz.com Page: 6 of 11... - Page 7 SCL “L” pulse width tslw Data setup time tsds Data hold time tsdh CS-SCL time tcss CS-SCL time tcsh Note: *1. Input signal rise/fall time should be less than 12ns URL: www.topwaydisplay.com Document Name: LM192160BCW-2-Manual-Rev0.1.DOC www.topwaysz.com Page: 7 of 11...
-
Page 8: Reset Timing
Reset Timing =0V, V =3.3V, T =25C Item Symbol MIN. TYP. MAX. Unit Reset time Reset LOW pulse width μs Note: *1. Input signal rise/fall time should be less than 12ns URL: www.topwaydisplay.com Document Name: LM192160BCW-2-Manual-Rev0.1.DOC www.topwaysz.com Page: 8 of 11... -
Page 9: Function Specifications
*2. The above is memory map based on: DC[5:3]=100 (1bpp) On/Off mode setting, ,the Page value range:0～19 LC[0]=MSF=0 LC[1]=MX=1 LC[2]=MY=0 SL=0 *3. For 4,8 and 16 Gray-shade operation please refer to UC1611 datasheet. URL: www.topwaydisplay.com Document Name: LM192160BCW-2-Manual-Rev0.1.DOC www.topwaysz.com Page: 9 of 11... -
Page 10: Command Table
Please refer to UC1611 data sheet for details R/W=0 means it is a write function, R/W=1 means it is a read function RS=0 means it is a control data, RS=1 means it is a display data URL: www.topwaydisplay.com Document Name: LM192160BCW-2-Manual-Rev0.1.DOC www.topwaysz.com Page: 10 of 11... -
Page 11: Design And Handling Precaution
LCD module reliability may be reduced by temperature shock. When storing the LCD module, avoid exposure to the direct sunlight, high humidity, high temperature or low temperature. They may damage or degrade the LCD module URL: www.topwaydisplay.com Document Name: LM192160BCW-2-Manual-Rev0.1.DOC www.topwaysz.com Page: 11 of 11...
