OWNER'S MANUAL
MICROWAVE OVEN
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
MGBZ2593** MG7Z2593**
MFL72143809
Rev.00_040325
Copyright © 2025 LG Electronics. All Rights Reserved
Scan the QR code to see the manual.
www.lg.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for LG MGBZ2593 Series
Summary of Contents for LG MGBZ2593 Series
- Page 1 This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. ENGLISH MGBZ2593** MG7Z2593** www.lg.com MFL72143809 Rev.00_040325 Copyright © 2025 LG Electronics. All Rights Reserved...
-
Page 2: Table Of Contents
TABLE OF CONTENTS This manual may contain images or content that may be different from the model you purchased. This manual is subject to revision by the manufacturer. IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE.........3 WARNING ......................3 CAUTION ......................9 INSTALLATION Product Overview.....................13... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. - Page 4 • Only qualified service person from LG Electronics service centre should disassemble, repair, or modify the appliance. • It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy.
- Page 5 IMPORTANT SAFETY INSTRUCTIONS food before cooking or defrosting. Note though that in some cases food should be covered with plastic film, for heating or cooking. • Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface, which may result in shattering of the glass.
- Page 6 IMPORTANT SAFETY INSTRUCTIONS sponges, damp cloth and similar may lead to risk of injury, ignition or fire. • If smoke is observed (or emitted), switch off or unplug the appliance and keep the door closed in order to stifle any flame. •...
-
Page 7: Installation
IMPORTANT SAFETY INSTRUCTIONS • Only allow children to use the oven without supervision when adequate instructions have been given so that the child is able to use the oven in a safe way and understands the hazards of improper use. Installation •... -
Page 8: Operation
IMPORTANT SAFETY INSTRUCTIONS • Connection of this appliance must comply with national and local safety regulations. • Connection to a switched socket is recommended as this provides easier access in the case of a service call. • For extra safety, it is advisable to protect the appliance with a suitable residual current device (RCD) with a trip current of 30 mA. -
Page 9: Caution
IMPORTANT SAFETY INSTRUCTIONS CAUTION CAUTION • To reduce the risk of injury to persons, malfunction, or damage to the product or property when using the appliance, follow basic safety precautions, including the following: Installation • Install the appliance according to the installation requirements that are in this manual. - Page 10 IMPORTANT SAFETY INSTRUCTIONS • Do not place an object(a book, a box, water bottle, vase etc.) on the appliance. The appliance may overheat or catch fire or the object may fall, causing injury to persons. • Do not operate the appliance with the door open. It could result in harmful exposure to excessive microwave energy.
-
Page 11: Maintenance
IMPORTANT SAFETY INSTRUCTIONS • The power connection may be achieved by having the plug accessible or by incorporating a switch in the fixed wiring in accordance with the wiring rules. Using improper plug or switch can cause an electric shock or a fire. •... - Page 12 IMPORTANT SAFETY INSTRUCTIONS • Wipe spatters immediately with a wet paper towel, especially after cooking chicken or bacon. • If steam accumulates inside or outside of the oven door, wipe the panels with a soft cloth. Cleaning the Exterior Clean the outside of the oven with soap and water. Rinse with clean water and dry with a soft cloth or paper towel.
-
Page 13: Installation Product Overview
INSTALLATION INSTALLATION Product Overview Accessories The appearance or components of the appliance may differ from model to model. Front View Glass Tray Rotating Ring Shaft Rack CAUTION • Do not use the microwave oven without the Control Panel glass tray and rotating ring. Mica Sheet Safety Door Lock System Window... -
Page 14: Installation Requirements
INSTALLATION in the form of electromagnetic radiation, - Failure to do so could result in fire or electrical inductive and /or capacitive coupling, for the shock, causing properly damage, personal treatment of material or inspection/analysis injury or death. purposes. • The power must be shut off while the electrical Class B equipment is equipment suitable for use connections are being made. - Page 15 INSTALLATION - Installation engineer: please retain these instructions for local inspector's reference, then leave them with the consumer. - Consumer: please read and keep these instructions for future reference and be sure to read the entire OWNER'S MANUAL prior to use.
-
Page 16: Dimensions And Clearances
• Make sure the base is level and the front of the cabinet is square. • Kitchen cabinets in contact with the oven must be heat resistant up to 90 ℃, and fronts of nearby units to at least 70 ℃. Installation Drawings If installed with LG 24” single built-in oven MGBZ2593** MGBZ2593** Dimension/Clearance... -
Page 17: Electrical Connection
INSTALLATION Remove the back wall of the installation cabinet. If it is difficult to remove the back wall, make a hole at least 100 mm in diameter. Ventilation in compliance with local regulations. Make sure the voltage shown on the rating label is the same as For correct ventilation, a ventilation opening of 50 the power supply voltage in your home. -
Page 18: Preparing The Cabinet
INSTALLATION Preparing the Cabinet Installing the Appliance Determine the wall thickness of the unit. Secure the spacers to the appliance in assigned to the wall thickness. accordance with the wall thickness. 19 mm-20 mm 140 mm 17.5mm-18.5 mm 147 mm 16mm-17 mm 154 mm NOTE... - Page 19 INSTALLATION Screw the appliance in until the appliance is centrally aligned. Check the clearance to the adjacent appliances. The clearance to the adjacent appliances must beat least 5 mm. Remove any packaging material and adhesive film from the cooking compartment and the door.
-
Page 20: Operation
OPERATION OPERATION Control Panel Press the button to select preprogrammed cook for popular food items. Control Panel Features Kitchen Timer/Clock • Press the button once to set timer. • Press the button twice to set clock. More/Less Set cooking time, power level, quantity, or weight. -
Page 21: Before Use
OPERATION Icon Indication Power Level Select an Weight 450 W • Cooking egg, milk and cheese (50%) dishes. NOTE • Cooking cakes and breads. • A beep sounds each time you press a key. A • Cooking veal. melody signals the end of a timer or a cooking •... -
Page 22: Quick Start
OPERATION Quick Start Kitchen Timer The Timer function serves as an extra kitchen Quick Start Feature timer. It chimes when the set time runs out. It does not start or stop cooking. This feature allows you to set 30-second intervals of High power cooking with each press of the Press Kitchen Timer/Clock once, until START/Select button. -
Page 23: Cooking Mode
OPERATION Select a desired microwave power level by NOTE using More/Less, and press START/Select. • If a power level is not selected, the oven defaults • Microwave power level to High power. - Co-1: 495 W (55%), Co-2: 324 W (36%) Select a desired time by using More/Less, and Grill Cooking press START/Select. -
Page 24: Defrosting Mode
OPERATION Auto Cooking Menu Press Defrost. Refer to the below to set the desired code and weight. Select a desired weight by using More/Less, 1 Pizza and press START/Select. • Weight: 0.2 kg, 0.4 kg • The countdown appears in the display. •... - Page 25 OPERATION Microwave-Unsafe Utensils all brands of oven tempered glass utensils. However, do not use delicate glassware, such as tumblers or wine glasses, as these might shatter • Metal Containers and Metal Decoration as the food warms. - Never use metal or metal-rimmed utensils in the microwave oven.
-
Page 26: Cooking Guide
OPERATION Cooking Guide • Density: Light, porous food such as cakes and breads are cooked more quickly than heavy, dense foods such as roasts and casseroles. Cooking Tips • Bones and Fat: Bones conduct heat and fat Carefully monitor the food in the microwave oven cooks more quickly than meat. -
Page 27: Troubleshooting Faqs
TROUBLESHOOTING TROUBLESHOOTING FAQs Frequently Asked Questions Q: What’s wrong when the oven light will not glow? A: There may be several reasons why the oven light will not glow. Either the light bulb has blown or the electric circuit has failed. Q: Does microwave energy pass through the viewing screen in the door? A: No. - Page 28 TROUBLESHOOTING Symptoms Possible Cause & Solution Microwave oven does A fuse in your home may be blown or the circuit breaker tripped. Or the not start appliance is connected to a GFCI (Ground Fault Circuit Interrupter) outlet, and the outlet's circuit breaker has tripped. •...
