- Page 1 FA02211-EN Radio sun/wind weather station 809XG-0110 INSTALLATION MANUAL English...
-
Page 2: Table Of Contents
TABLE OF CONTENTS GENERAL PRECAUTIONS FOR USERS ..........................3 Legislative references ............................... 3 DISMANTLING AND DISPOSAL ............................3 PRODUCT DATA AND INFORMATION ..........................4 Key ....................................4 Description ..................................4 Technical data .................................. 4 Description of parts ................................5 Size ....................................6 Cable types and minimum thicknesses .......................... -
Page 3: General Precautions For Users
Legislative references This product complies with the applicable standards in force at the time of manufacturing. CAME S.p.A. declares that the product described in this manual complies with Directive 2014/53/EU and the Radio Equipment Regulations 2017. The full EC declaration of conformity and UK Conformity Assessed (UKCA) marking information can be found at www.came.com. -
Page 4: Product Data And Information
This symbol shows which parts describe safety issues. Description 809XG-0110 STRAUSS KLT 2.0 is a radio weather station that controls motors and accessories with a radio receiver to automatically manage mobile equipment (box awnings, blinds, shutters and blackout systems) according to wind and sun conditions. -
Page 5: Description Of Parts
Description of parts UP button Sun sensor Programming button P2 Product data label Display Reset button Power supply terminal board Button M for sun function Anemometer Button A for wind function UP P2 Sun alarm activated Sun brightness unit of measurement Wind alarm activated Wind speed unit of measurement Radio transmission signal... -
Page 6: Size
Size Cable types and minimum thicknesses Cable length (m) up to 10 from 20 to 30 from 20 to 30 Power supply 120/230 V AC 2G x 0.75 mm² 2G x 1 mm² 2G x 1.5 mm² When operating at 120/230 V and outdoors, use H05RN-F cables that are IEC 60245 (IEC 57) compliant; when indoors, use H05VV-F cables that are IEC 60227 (IEC 53) compliant;... -
Page 7: Installation
INSTALLATION The device must be installed by qualified expert technicians in full compliance with applicable laws and regulations. Preliminary operations Ensure that the place where the weather station will be fixed is protected from knocks, but exposed to sunlight and air circulation. Secure it to a flat, solid surface using suitable fasteners (screws, plugs, etc.). -
Page 10: Programming
PROGRAMMING To take full advantage of the STRAUSS KLT 2.0 radio weather station functions, activate the same transmitter on the weather station as is used to control the motor. Activating the weather station To activate the weather station: - configure the motor transmitter (not required if the transmitter is already associated with the motor); - configure the transmitter on the weather station. -
Page 11: Configuring The Transmitter On The Weather Station
Configuring the transmitter on the weather station Ensure the weather station has the same frequency as the transmitter. Proceed as follows: - power the weather station; - within 30 seconds, press the UP and P2 buttons on the weather station together (the station will beep once), then press the UP and STOP buttons on the associated transmitter together (the station will beep 5 times to indicate the setting has been saved). -
Page 12: Operation And Settings
Warning! Pre-2022 transmitters cannot be used to control the sun function. To activate the sun function: press button P2 on the transmitter twice within 10 seconds, then press button P2 on the weather station. 10” OPERATION AND SETTINGS The radio weather station sends alarm commands to the motor. These commands are: - wind alarm: awning closing command;... -
Page 13: Setting The Wind Level
Setting the wind level Press and hold button A (for approx. 3 seconds) until you hear a short beep. The symbol and set threshold flash on the display. Briefly press button A to set the level cyclically: 1 = 5 km/h (predefined) 2 = 10 km/h 3 = 20 km/h 4 = 30 km/h... -
Page 14: Sun Alarm Operation
Sun alarm operation When the brightness exceeds the set threshold, after 5 minutes the weather station enters sun alarm state, as shown by the symbol . The weather station controls the awning opening. When the brightness falls to below this level, after 15 minutes the weather station closes the awning and exits alarm state. If the brightness fades rapidly to below 15 Klux, after 3 minutes the weather station closes the awning and exits alarm state. -
Page 15: Setting The Sun Level
Setting the sun level Press and hold button M (for approx. 3 seconds) until you hear a short beep. The symbol and set threshold flash on the display. Briefly press button M to set the level cyclically: 1 = 5 klux 2 = 10 klux (predefined) 3 = 15 klux 4 = 30 klux... - Page 16 Press the reset button on the weather station and hold for 5 seconds. The station will beep 3 times consecutively to indicate that the factory settings have been restored. The reset button restores the weather station to factory settings and deletes the transmitter associated with it. CAME S.p.A. Via Martiri della Libertà, 15 31030 Dosson di Casier Treviso - Italy Tel.
