Tentacle SYNC E Quick Start Manual
Hide thumbs
Also See for SYNC E:
- Operating manual (15 pages) ,
- Operating manual (27 pages) ,
- Operating manual (20 pages)
Advertisement
Quick Links
POWER ON
Short Hold: Status LED flashes red and
SYNC E is ready to be synchronized via
app or external timecode
Long Hold: Status LED flashes green
and SYNC E generates timecode with
Time of Day (RTC)
POWER OFF
Long Hold: SYNC E turns off
MICROPHONE
When SYNC E is connected to stereo mic
input of camera, SYNC E's internal scratch
mic and the timecode will be recorded
USB-C Port
Charging & Firmware Update
3,5 mm Jack
Timecode
In/Out
Battery Status LED
Charging
Full
Microphone
Power Switch
SLIDE
CLICK
Locking Clamp
Slide over connector
along recess
Status LED
Waiting to be
synchronized
Generating
Timecode
Battery empty
Bluetooth
Connection
