Wesco Aluminum Professiona 272048 Assembly And Operation Instructions

Description
The Wesco Aluminum Telefolding Truck is designed
specifically for transporting loads of up to 330 lbs. This multi-
functional truck features
conversions/storage, moldon rubber wheels, Anti-impact,
non-skid polypropylene and aluminum deck and a rubber
coated handle. The deck extends from 21" to 29.5". It is UPS
shippable.
This product is distributed by:
Wesco Industrial Products, LLC
1250 Welsh Road
North Wales, PA 19454
Tel: 215-699-7031 Fax: 215-699-3836
Contact the factory for parts information and ordering.
Visit us on the web at www.wescomfg.com
Unpacking
When unpacking the Wesco Product, check carefully for
shipping damage and missing parts. If damage has occurred
or any parts are missing, file a claim with the delivering carrier
within 24 hours and notify the dealer from whom the unit was
purchased.
PUSH
BUTTON
Figure 1
1) Press down push button
and push front of truck in
direction of arrow.
© Copyright 2018 WESCO Industrial Products, LLC. Specifications subject to change. Not responsible for errors or omissions.
Aluminum Professional Series Telefolding Truck
Assembly and Operation Instructions
ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR WESCO TELEFOLDING
a push button for
Figure 2
2) Step on bar at base of
handle, then push
handle down to set truck
in the "tow position".
(Part # 272048)
TRUCK, READ THESE INSTRUCTIONS BEFORE USING.
If the unit does not work properly, contact your dealer or the
factory (215-699-7031) for units less than 90 days old.
quick
If units are older than 90 days, repairs can be made easily on
site with factory supplied parts.
NOTE: Do not send units to the factory for service without
first obtaining a "Return Merchandise Authorization" (RMA)
number from the customer service department. We will not
be responsible for merchandise returned without proper
authorization.
Item Part No.
1 272049
2 272050
3 272051
4 272111
Operation
Figure 3
3) Step on bar at base of
handle and fold handle
forward to set truck in
"compact position".
Warranty Repairs
Non-Warranty Service
Replacement Parts
Description
Hardware Kit
Swivel Caster
Rigid Caster
Spring
Figure 4
4) Truck is compact and
easily stored.
Qty.
1
2
2
1
