HERO+ S11198 User Manual

User Manual
Hero Medical Toilet Surround
SKU
Overall Width
Overall Depth
Width Between Arms
Armrest Height
Weight
Safe Work Load (SWL)
Independent Living Specialists
S11198 S13165
67cm 72cm
52cm 52cm
54cm 60cm
66-79cm 66-79cm
2kg 3.7kg
205kg 205kg
Safety & Precautions
User Safety: It is recommended that the below safety checks are completed
prior to each use:
• All locking pins must be fully protruding.
• Adjusted to appropriate height for user.
• Legs are in a secure position with anti-slip rubber tips attached.
• Weight on chair does not exceed safe work load.
Weight Capacity: the maximum safety weight limit for the product is 205kg.
If the maximum safety weight limit is exceeded, this can increase the risk of
damage to the product and/or risk of serious injury to the user and others.
Instructions for Use
Product Assembly
1. Remove contents from packaging.
2. Attach side frame component (front legs) by sliding into the rear frame
component until the locking pin is secured and protruding.
3. Attach the arm rest components by sliding onto the frame until the
locking pin is secured and protruding.
Adjusting the Height
1. Push locking pin in and slide internal leg up or down to the appropriate
height. Ensure all locking pins are fully protruding prior to use
2. Please note that one leg has additional holes, to assist with stabilising
product on uneven floors.
1
Independent Living Specialists
Hero Medical Toilet Surround Manual
