Assembly I nstructions
Solar p anel i nstallations
*Make s ure t o m ount t he s olar p anel n o m ore t han 1 5 F eet o r 5 M eters
from t he H anging S olar S hed L ight ( the l ength o f t he w ire p rovided)*
(There a re t wo w ays t o a ssemble t he S olar P anel.)
Pillar M ounted
1) Carefully r emove a ll t he f ittings f rom t he b ox
2) Setting the "L" Shape Screw (1) to solar panel (8) with PA3*15 Screw (4).
(shown i n f igure 1 )
3) Connect " L" S hape S crew a nd B racket f or s olar p anel ( 6) a nd " U" S hape S crew ( 5). ( AS s hown i n f igure 2 )
4) Tumble i n t he " L" S hape S crew t o P illar a nd t wist t he " U" S hape S crew t ightly. ( AS s hown i n f igure 3 )
Wall o r D eck M ounted
1) Choose t he w all o r d eck w hich y ou w ant t o m ounted t he s olar p anel. U se t he 4 h oles o f t he b racket t o a ling t he i nflatable
capsules. ( 7) ( as s hown i n f igure 4 ).
2) Fit t he B racket w ith t he S olar p anel w ith p rovided P A3*15 S crew. ( As s hown i n f igure 5 )
3) Set t he B racket o n t he w all o r d eck w ith 4 Pcs p rovided P A4*35 S crews ( 9). ( As s hown i n f igure 6 )
4) Adjust t he a ngle o f S olar P anel t o m ake s ure i t r eceives o ptimal s unlight d uring t he d ay.
Lamp i nstallations
Use t he 2 P re-­‐drill h oles o n t he c eiling b racket, a nd m ark t he l ocation. T hen i nstall t he
2 i nflatable s crews. i nto t he h oles a nd a ttach t he c eiling b racket w ith t he 2 s crews.
Connection o f t he S olar P anel a nd L amp
Insert t he p lug o f t he W ires i nto t he s ocket a t t he s ide o f t he c eiling b racket.
Hanging S olar S hed L ight
With R emote C ontrol
21030
Instruction M anual
9.6 feet or 2.9 meters
