Jehnert Phoenix Maxi-Liner Installation Overview

Integrated motorhomes
Maxi-Liner
Phoenix Maxi-Liner (Concorde / Morelo / Phoenix)
Sound packages 1 and 2
Model/year of manufacture: Integrated motorhomes, Maxi Liner
Packing list:
2x 26 mm neodymium soft dome tweeter „XE26"
2x 80 mm „XE80" midrange drivers
2x 165 mm JEHNERT Power Woofer „XM165"
1x mounting set mid/high module: 8x Spax 4 x 30
1x woofer mounting set: 8x 3.9 x 16 countersunk head screw
2x crossovers
1x 5-channel DSP ampli er incl. 5m ISO cable
1x subwoofer of your choice incl. mounting kit and 4.8m subwoofer cable
Sound package 2 also includes 2 living room speakers of your choice.
Attention: these are not installation instructions! This document only serves as an overview guide for your installation!
Warranty:
As the manufacturer, we guarantee these sound systems for 2 years from the date of purchase from the specialist dealer.
Within this warranty period, we will, at our discretion, repair or replace free of charge all defects caused by material or manufacturing faults.
manufacturing defects. The warranty does not cover damage caused by improper use or installation, wear and tear or tampering by third parties.
or tampering by third parties. The guarantee does not cover any consequential damage or defects that a ect the value or usability of the sounds.
or the usability of the sound systems only insigni cantly. A warranty obligation is not triggered in the event of damage
caused by external in uences.
These are damages to the components that cannot be repaired.
Jehnert Sound Design I Im Michelreis 14 I 72124 Pliezhausen I Tel.: 07127-93457-0 I sounddesign@jehnert.de I www.jehnert.de
Installation overview
Stand: 13.03.2025
Art. No. 60501-86/ Art. No. 60502-86
Systems with additional or incorrect mounting holes are excluded from exchange.
