Summary of Contents for Kleenmaid Ultratap5
- Page 1 To register your warranty or make a warranty claim, scan this QR code: kitchen collection Instructions for use and warranty details Integrated Water Dispenser Model No: HCSUB511...
- Page 2 Once installation is complete, please read this instruction manual carefully and get to know the controls and the features of your new Kleenmaid appliance. These simple instructions will enable you to achieve excellent results from the very first time you use it.
-
Page 3: Table Of Contents
CONTENTS SAFETY INSTRUCTIONS SPECIFICATIONS PRODUCT OVERVIEW PRODUCT INSTALLATION OPERATING INSTRUCTIONS AVAILABLE CONTROL PANEL SETTINGS MAINTENANCE TROUBLESHOOTING DISPOSAL AND RECYCLING KLEENMAID WARRANTY... -
Page 4: Safety Instructions
Refer to the current online manual on the Kleenmaid website for the latest installation instructions (see back cover for details). - Page 5 Safety Instructions This appliance is not intended for use by persons (including children with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
-
Page 6: Usage Precautions
User Manual, which is available on the Kleenmaid website (see back cover for details). Pay particular attention to sections marked with warning, precaution, attention, caution etc. and to the order or sequence in which instructions are prescribed. -
Page 7: Installation Checklist
When the appliance is first turned on ensure that it is not connected to CO gas to prevent the sparkling water function from being unavailable due to premature release of the CO from the cylinder. Do not place multiple power boards or portable power supplies on the back of the product. -
Page 8: Specifications
315mm (W) x 392mm (H) x 510mm (D with Product size connected piping) Compass Capital Services Pty Ltd T/As Address of manufacturer Kleenmaid. 204 Botany Rd, Alexandria, NSW, Australia 2015 * Use the supplied brass in-line water pressure reducers for mains hot/cold water connections. -
Page 9: Control Unit Connections
Control Unit Connections Contents of Carton Below is a list of parts and components included in/with the carton. DO NOT dispose of any of the contents of the carton (including packaging) before the installation/commissioning process is complete. DO NOT discard the paper vent location template. Model Parts and components HCSUB511... -
Page 10: Product Installation
PRODUCT INSTALLATION Before making preparations for or commencing installation, the installer should refer to the current online version of the User Manual, which is available on the Kleenmaid website (see back cover for details) and take particular note of the Installation... - Page 11 1. The maximum allowable distance between the Control Unit and the tap is 500mm. It is recommended that the tap installation surface is at least 450mm higher than the Control Unit. 2. The maximum allowable distance between the Control Unit and the hot/ cold water inlets is 500mm.
-
Page 12: Tap Installation
Tap Installation Connect the chilled water hose in Remove the fastening nut from the product package to the tap. the packet with washers. Install circular rubber gasket. Chilled water outlet connection pipe Remove and replace Blue locking clips. Ensure that they are correctly inserted. Thread all tubes into the hole after adding the circular rubber gasket. - Page 13 Assemble the lower parts of the tap assembly in the sequence shown below and use supplied tool to secure the fastening nut on the threaded rod. Semi- circular rubber pad The holes in the rubber Semi-circular pads and metal fasteners metal gasket need to be threaded onto the rod...
- Page 14 base The front of the template should align with the front of the cabinet base. Allow X +5mm from the internal side wall of the cabinet to the nearest edge of the template. φ Note must unit or the replacement of the CO 2 cylinder See warning page 17.
- Page 15 4. Install the vent positioning seat into the circular vent cutout and fasten it with supplied screw. Note that the screw in position 2 in the diagram below must be positioned as close as possible to the front of the cabinet. Push the Control Unit into the cabinet and make sure the ventilation hole at the bottom is aligned with the positioning seat hole.
- Page 16 Water Control Unit Connection Chilled water outlet connection inlet connection Boiling water outlet connection Mains water inlet connection Tap connections Chilled water Mains hot connection pipe water inlet pipe Mains cold (Red surface water inlet pipe marking) (Blue surface marking) Mains cold water inlet pipe Boiling water (Blue surface marking)
-
Page 17: Electrical Connection
Electrical Connection This appliance should be connected to the mains power supply via the supplied plug & cord, and a standard 10A GPO. 10A GPO The plug and socket have a correct alignment - do not force. CO 2 Gas Cylinder Mounting Warning: It is strictly prohibited to install gas cylinders close to the Control Unit. - Page 18 Note: When connecting the CO hose safely to the regulator ensure the end of the pipe is cleanly cut and be careful not to damage the connector that joins it to the regulator. Press firmly to ensure it is fully inserted then pull it slightly back to ensure it is fully sealed.
-
Page 19: Operating Instructions
OPERATING INSTRUCTIONS Tap Function Introduction Control knob and mode indicator : Filtered boiling water Dispense button : Filtered chilled water Single lever mixer tap : Filtered sparkling water Water Dispensing Note: Throughout these Operating Instructions "Long press" means to touch and hold the key/button for 3 seconds or longer. -
Page 20: Control Panel Display
Note 1. When dispensing chilled water, if the output is not actively turned off, it will continue to dispense water for 3 minutes and then automatically stop. 2.When no mode is selected ie. mode indicator is not illuminated, short press the dispense button to dispense chilled water. - Page 21 1. Turn the product on and off: Short press Power - on/off key 2. To restore factory settings: Long press Restore key - the temperature of boiling water is set to 98°C, and the temperature of chilled water is set to 5°C. 3.
- Page 22 5. Set ECO mode: NOTE: Use of ECO mode saves money, however it will not satisfy your needs if you prefer boiling water at 98° C and chilled water at 5°C. Short Press Eco mode key to set the ECO function and the ECO mode key will illuminate.
-
Page 23: Maintenance
MAINTENANCE Your Kleenmaid appliance has been engineered and constructed to provide you with years of reliable service by way of its sophisticated components and quality finishes. In return, regular maintenance, in accordance with the following instructions, is required in order to allow it to continue serving you with its appearance and performance, as well as it did on the day it was first installed. - Page 24 NOTE: To purchase replacement Water Filter Part No: KMHCSF, visit the UltraTap 5 Product page on the Kleenmaid website or email sales@kleenmaid.com.au Replace CO 2 Gas Cylinder Replacing your CO gas cylinder: Replacement cylinders can be purchased from many supermarkets and petrol stations.
-
Page 25: Troubleshooting
TROUBLESHOOTING Condition Cause Description Solutions Boiling water temperature sensor Contact a technician for repair. short circuit/open circuit Chilled water temperature sensor short Contact a technician for repair. circuit/open circuit Aspiration/exhaust/environment Contact a technician for repair. sensor shortcircuit/open circuit Turn the power off then turn it back on. -
Page 26: Kleenmaid Warranty
Kleenmaid Warranty, however, if repair is needed because of Product failure during normal Domestic Use, Kleenmaid has the option to repair or replace the defective Product or part of the Product with a product or part of like kind and quality. - Page 27 15. Kleenmaid accepts no liability for items that are lost, damaged, or stolen as a result of freight, transport or storage. If you are required to transport the Product to an authorised service centre, you must ensure that it is securely packed and insured.
- Page 28 Other products available in the Kleenmaid range of appliances Washing machines Clothes dryers Dishwashers Ovens Cooktops Steam ovens Microwave ovens Built in espresso coffee machines Rangehoods Freestanding ovens Refrigerators & Freezers Beverage Serving Cabinets Water Dispensers Vacuum Cleaners Compass Capital Services Pty Limited...
