Item # 1001 582 203
Model # HDMV36WD
Item # 1001 582 204
Model # HDMV36WN
ASSEMBLY GUIDE
36 in. VANITY WITH CERAMIC TOP
Questions, Problems, Missing Parts? Before Returning To The Store,
Call Glacier Bay Customer Service
8 A.M. - 7 P.M., EST, Monday-friday, 9 A.M. To 6 P.M. EST, Saturday
1-855-HD-GLACIER
HOMEDEPOT.COM/GLACIERBAY
THANK YOU
We appreciate the trust and confidence you have placed in Glacier Bay through the purchase of this laundry cabinet. We strive to
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Glacier Bay !
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Glacier bay HDMV36WD
Summary of Contents for Glacier bay HDMV36WD
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Glacier Bay through the purchase of this laundry cabinet. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home...
-
Page 2: Table Of Contents
Table of Contents ..Table of Contents ............2 Cabinet Dimensions ............3 Safety Information ............2 Tools Required .................3 Warranty ................. 2 Hardware Included ..............3 Care and Cleaning ............2 Package Contents ..............4 Pre-Assembly ..............3 ................. Assembly Planning Assembly ..............3 Safety Information Please read and understand all instructions before assembly and... -
Page 3: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY Check the cabinet for damage before installation. If any part of the cabinet is missing or damaged, contact the Customer Service Team at 1- 855-HD-GLACIER. Ensure that the cabinet location is accessible to water supply and drain lines. It is suggested that you rough-in the water lines and drain before installing the cabinet. -
Page 4: Package Contents
Pre-Assembly (continued) PACKAGE CONTENTS Part Part Description Quantity Vanity top Vanity base Support bar Left leg Right leg... -
Page 5: Assembly
Assembly Assembling the leg Installing the leg Assemble the left leg (D) and right legs (E) to the support Install the leg combo to the vanity with wood dowel A (BB). bar (C) with wood dowel B (CC). Installing the leg Installing the vanity Decide exactly where you wish to install your vanity and Use the allen key (EE) to fasten the leg combo with the... - Page 6 Assembly Installing the vanity Installing the vanity Remove the vanity and drill holes at each marked position. Fasten the vanity with phillips flat head screws (GG). Insert the wall plugs (FF) into the wall using a hammer. Installing the vanity top Apply a small bead of silicone on the vanity base (B), then put the vanity top (A) on the vanity body carefully and press it down to set in place.
- Page 7 Questions, problems, missing parts? Before returning to the store, call Glacier Bay Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m. Saturday 1-855-HD-GLACIER HOMEDEPOT.COM/GLACIERBAY Retain this manual for future use.
-
Page 8: Guide D'assemblage
ARMOIRE DE 91,4 CM AVEC PLATEAU EN CÉRAMIQUE Des questions, des problèmes ou des pièces manquantes? Avant de retourner au magasin, appelez le service clientèle Glacier Bay entre 8 et 19 h (heure de l’Est), du lundi au vendredi, et 9 et 18 h, le samedi 1-855-HD-GLACIER HOMEDEPOT.COM/GLACIERBAY... -
Page 9: Consignes De Sécurité
Table des matières Dimensions de l'armoire ............... 3 Table des matières ............2 Outils requis ................3 Consignes de sécurité ..........2 Garantie ................2 Visserie fournie ................ 3 Entretien et nettoyage ..........2 Contenu du paquet ..............4 Avant l'assemblage ............ -
Page 10: Avant L'assemblage
Avant l'assemblage PLANIFICATION DE L'ASSEMBLAGE Vérifiez l'état de l'armoire avant installation. Si une quelconque pièce de l'armoire manque ou est endommagée, contactez le service clientèle au 1-855-HD-GLACIER. Assurez-vous que l'emplacement de l'armoire est accessible aux conduites d'arrivée d'eau et de vidange. Nous vous suggérons de préparer les conduites d'arrivée d'eau et de vidange avant d'installer l'armoire. -
Page 11: Contenu Du Paquet
Avant l'assemblage (suite) CONTENU DU PAQUET Pièce Part Description Quantité Comptoir de meuble-lavabo Base de meuble-lavabo Barre de support Jambe gauche Jambe droite HOMEDEPOT.COM/GLACIERBAY Pour obtenir de l’aide, appeler le 1-855-HD-GLACIER. - Page 12 Assemblage Assemblage de la jambe Installation de la jambe Assemblez la jambe gauche (D) et la jambe droite (E) au Installez le combo de pieds sur la armoire avec la support barre (C) avec cheville en bois B (CC). cheville en bois A (BB). Installation du meuble-lavabo Installation de la jambe (suite) Utilisez la clé...
- Page 13 Assemblage Installation du meuble-lavabo Installation du meuble-lavabo Retirez la meuble-lavabo et percez des trous à chaque Fixez la meuble-lavabo à l’aide de la vis à tête plate Phillips (GG). position marquée. Insérez les chevilles (FF) dans le mur avec un marteau. Installation de la comptoir de meuble-lavabo Appliquez un petit cordon de silicone sur la base de meuble-lavabo (B), puis placez le comptoir de meuble-lavabo (A) sur le base de meuble-lavabo avec soin et appuyez dessus pour le mettre en place.
