Summary of Contents for amphis Ki
- Page 1 Quick Start Guide...
- Page 2 PRODUCT DRAWING – FRONT 5. Push Button PIR Motion Sensor 2. Light Sensor 6. LED Indicator 3. 166˚ HD Camera Speakers 4. Microphone...
- Page 3 PRODUCT DRAWING – BACK 11. SD Card Slot 8. DC14V~24V Power Interface 12. Battery Compartment Cover 9. Reset Button 10. Micro USB Port (Battery Charging)
- Page 4 PRODUCT DRAWING – MOUNTING BRACKET 13. Screw Holes x 4 14. Wire Terminals 15. Mounting Hooks x 6...
- Page 5 PRODUCT DRAWING – BRACKET INSTALL Push in and slide down Tighten to secure Tighten screw at base, use provided Allen Key...
-
Page 6: Power Supply
POWER SUPPLY Hard wire power source Powered by battery Micro USB port for battery charging (DC5V) DC 14V-24V Rechargeable Bell Transformer 18650 Battery APP DOWNLOAD – SMART LIFE Download from App Store or Google Play, run the app on your smart phone and set up the smart video doorbell, following the in-app instructions. - Page 7 SMART WIFI VIDEO DOORBELL PARAMETERS Smart WiFi Video Doorbell security solution provides the following functions: wireless connection, ultra-low power consumption, remote active wake-up and quick start.
-
Page 8: App Guide
APP GUIDE Download Smart Life app on mobile phone. Open the app and you will see the following guide page . USER REGISTRATION Register a new account. If you already have an account, simply log in. -
Page 9: Add Device
ADD DEVICE Select the following options “Add Device > Camera and Lock > Smart Doorbell... -
Page 10: General Connection
GENERAL CONNECTION Remove “PULL” tags from back of the device (if not done so already). You should now hear a voice and the LED indicator should now be flashing red. In the app, select “Make sure the indicator is flashing quickly or a prompt tone is heard”. - Page 11 QR CODE CONNECTION Hold the QR code up to the camera of the Ki device. You should hear a chime. Select “I heard a prompt”. Wait for the device to be added. If the connection fails, ensure you have entered the correct password (the app won’t specifically tell you that the password is incorrect).
- Page 12 QR CODE CONNECTION DEVICE CONNECTION STATUS DESCRIPTION 1. The red light is always blinking. Ready to connect to network mode, after a few seconds of waiting, with tone reminder. 2. Flashing red, light blinks at one second intervals. The device has entered the network connection mode. If the device successfully receives the broadcast or detects QR Code, there will be prompt tone reminder.
-
Page 13: Device Management
DEVICE MANAGEMENT Click “...” on live view page to enter device management. MODIFY DEVICE NAME Click “Modify Device Name” on setting page to rename device . -
Page 14: Device Sharing
DEVICE SHARING To share your Ki device with another user, navigate to the home screen and follow the following prompts highlighted in the images below:... -
Page 15: Device Info
DEVICE INFO CIick “Device Info” to check device information. POWER MANAGEMENT SET TING Click “Power Manage” to check power working status. - Page 16 BASIC FUNCTION SET TING Click “Basic Function Settings” to set below functions: lndicator status; image reverse; time watermark; wide dynamic mode; IR night vision. 20. MOTION DETECTION SET TING Select ”PIR” to set the sensitivity of the camera.
- Page 17 DOORBELL CALL PUSH MESSAGE Press doorbell and it rings. Device makes call to smartphone, select “Accept” to check the monitoring image or “Refuse” to end call. PIR MOTION DETECTION PUSH MESSAGE Select push message to be notified if people stay in front of the device or move.
-
Page 18: Message Center
23. MESSAGE CENTER Click “Message Center” to check the history of push messages. - Page 19 Quick Start Guide...
- Page 20 Q U I C K S TA R T G U I D E FEATURES 1. Easy to install and use 2. 5 level volume control. Max volume: 110 decibels 3. 55 ringtones with LED indicator 4. 1000ft/300m wireless working range in open area 5.
- Page 21 Q U I C K S TA R T G U I D E FIRST TIME USING 1. Plug the chime to AC outlet. Device will play the default ringtone once at the maximum volume. 2. Short press on volume button to adjust the volume of speaker.
-
Page 22: Troubleshooting Guide
Trouble Shooting Guide... - Page 23 MY KĪ IS NOT PAIRING Completion of step A above is required. Refer to sections 8 to 12 in t he instruction manual (available on the Amphis website) when following step B. B. STEP-BY-STEP CHECKLIST 1. Ensure the correct app is do wnloaded. If Q R code does not work, check in the App Store/Play Store for ‘Smart Life’.
- Page 24 The unit may have been paired by trade to check that it is in working order and the device was not removed from the app prior to handover. C. CONTACT AMPHIS TO SPEAK TO A TEAM MEMBER Please email warranty@amphis.com.au with the following details 1.
- Page 25 T R O U B L E S H O O T I N G G U I D E FO OTN OTE S FOOTNOTES CL ARIFICATION The hardwiring component will ‘trickle charge’ the unit, ie. regularly top up power. An additional 15W DC transformer (not included) will need to be wired from the unit to the main power supply.
- Page 26 T R O U B L E S H O O T I N G G U I D E FOOTNOTES CL ARIFICATION One admin will need to set up the device using the Smart Life app. Pairing secondary devices is only possible by sharing/invitation from the admin device.
- Page 28 Telephone 1300 LIGHTS Email sales@amphis.com.au amphis.com.au...
