Please use this manual together with the service manual for
Model No.DMC-FS7P/PC/PR/PU/EB/EE/EF/EG/EP/GC/GD/GJ/GK/GN/GT Vol.1 Order No.DSC0902005CE
DMC-FS12P
Model No.
DMC-FS12PC
DMC-FS12PR
DMC-FS12PU
DMC-FS12EB
DMC-FS12EE
DMC-FS12EG
DMC-FS12EP
DMC-FS12GC
DMC-FS12GJ
DMC-FS12GK
DMC-FS12GN
DMC-FS12GT
Vol.1
Colour
(S)-------Silver Type (except GT)
(K)-------Black Type (except GT)
(P)-------Pink Type (except EG/GN)
(A)-------Blue Type (only P/PC/PU/EP/GC/GN)
(G)-------Green Type (only P/PC/PU)
© Panasonic Corporation 2009 Unauthorized copy-
ing and distribution is a violation of law.
https://manual-hub.com/
ORDER NO. DSC0906054AE
B26
Digital Camera

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LUMIX DMC-FS12P and is the answer not in the manual?

Questions and answers

Related Manuals for Panasonic LUMIX DMC-FS12P

Summary of Contents for Panasonic LUMIX DMC-FS12P

  • Page 1 (P)-------Pink Type (except EG/GN) (A)-------Blue Type (only P/PC/PU/EP/GC/GN) (G)-------Green Type (only P/PC/PU) Please use this manual together with the service manual for Model No.DMC-FS7P/PC/PR/PU/EB/EE/EF/EG/EP/GC/GD/GJ/GK/GN/GT Vol.1 Order No.DSC0902005CE © Panasonic Corporation 2009 Unauthorized copy- ing and distribution is a violation of law. https://manual-hub.com/...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PAGE PAGE 1 SERVICE NAVIGATION ------------------------------------------3 5.3. Packing Parts and Accessories Section (1) ------ 20 1.1. INTRODUCTION -------------------------------------------3 5.4. Packing and Accessories Section (2) -------------- 22 1.2. Important Notice 1:(Other than U.S.A. and Canadian Market) ------------------------------------------3 1.3. About the Lens Unit ---------------------------------------3 2 INITIAL SETTINGS ------------------------------------------------4 3 Disassembly and Assembly Instructions -----------------7 3.1.

  • Page 3: Service Navigation

    1 SERVICE NAVIGATION 1.1. INTRODUCTION This Service Manual contains technical information which will help service personnel to understand and service the Digital Camera Digital Camera; DMC-FS12 series The Digital Camera DMC-FS12 series have been developed based on DMC-FS7 series. Since this Service Manual does not cover the same part which is already described in the Service Manual for DMC-FS7 series, when servicing, refer to the descriptions in the Service Manual for ;...

  • Page 4: Initial Settings

    2 INITIAL SETTINGS After replacing the MAIN PCB, be sure to perform the initial settings after achieving the adjustment by ordering the following procedure in accordance with model suffix of the unit. 1. IMPORTANT NOTICE: Before proceeding Initial settings, be sure to read the following CAUTIONS. 2.
  • Page 5 [CASE 1. After replacing MAIN P.C.B.] When MAIN P.C.B. has just been replaced, all of the model suffix is displayed as follows. (Four pages in total) [CASE 2. Other than “After replacing MAIN P.C.B.”] • Step 5. Chose the model suffix in “INITIAL SETTINGS”: (Refer to “CAUTION 1”) [Caution: After replacing MAIN P.C.B.] The model suffix can been chosen, JUST ONE TIME.
  • Page 6 • Step 7. CONFIRMATION: Confirm the display of “PLEASE SET THE CLOCK” in concernd language when the unit is turned on again. When the unit is connected to PC with USB cable, it is detected as removable media. 1) As for your reference, major default setting condition is as shown in the following table. •...

  • Page 7: Disassembly And Assembly Instructions

    3 Disassembly and Assembly Instructions 3.1. Disassembly Assembly Instructions NOTE: When Disassembling and Assembling for the Lens 1. To minimize the possibility of the CCD being dirt, perform disassemble and/or assemble under the condition of the CCD is being mounted. Disassembling procedures for the CCD unit, refer to item 3.3.
  • Page 8 3.1.2. Removal of the Master Flange Unit 3.1.3. Removal of the 1st Lens Frame/2nd Lens Frame Move Unit 3.1.4. Removal of the 2nd Lens Frame Move Unit https://manual-hub.com/...

  • Page 9: Assembly Procedure For The Lens

    3.2. Assembly Procedure for the 3.1.5. Removal of the Drive/Direct Frame Unit Lens 3.2.1. Phase alignment of the Direct Frame and Drive Frame Unit 3.2.2. Phase alignment of the Drive/Direct Unit and Fixed Frame Unit https://manual-hub.com/...
  • Page 10 3.2.3. Assembly for the 1st Lens Frame 3.2.4. Assembly for the 2nd Lens Frame Unit and Fixed/Drive/Direct Frame Move Unit and Fixed/Drive/Direct Unit Frame/1st Lens Frame Unit https://manual-hub.com/...

  • Page 11: Removal Of The Ccd Unit

    3.3. Removal of the CCD Unit 3.2.5. Assembly for the Master Flange Unit and Fixed/Drive/Direct Frame/ To prevent the CCD unit from catching the dust and dirt, 1st Lens Frame/2nd Lens Frame do not remove the CCD unit except for replacing. Move Unit https://manual-hub.com/...

  • Page 12: Removal Of The Focus Motor Unit

    3.4. Removal of the Focus Motor 3.5. Applyment Grease Unit Method The grease apply point of lens unit are as follows. Apply grease additionally in the specified position if necessary. When the grease is applied, use a toothpick and apply thinly. •...

  • Page 13: Diagrams

    4 DIAGRAMS 4.1. Overall Block Diagram OVERALL BLOCK DIAGRAM (33mm ~ 132mm) IC3001 CCD SIGNAL PROCESSOR X6001 (24MHz) 1/2.33" 12 MEGA PIX CDS, AGC, A/D, TG, CCD DRIVER ZOOM OIS UNIT IRIS SHUTTER FOCUS IC3002 CARD REGLATOR IC9101 SYSTEM IC MOTOR DRIVE, OIS DRIVE&...

  • Page 14: Flash Top Schematic Diagram

    4.2. Flash Top Schematic Diagram É É Variation Category DMC-FS6/FS7/FS15 DMC-FS25 FS8/FS62/FS12 P8002 K4ZZ04000051 K4ZZ04000052 c i t https://manual-hub.com/...

  • Page 15: Ccd Flex Schematic Diagram

    4.3. CCD Flex Schematic Diagram https://manual-hub.com/...

  • Page 16: Ccd Flex P.c.b

    4.4. CCD Flex P.C.B. https://manual-hub.com/...

  • Page 17: Replacement Parts List

    5 REPLACEMENT PARTS LIST 5.1. Electrical Parts Section COMPARISON CHART: The following table shows difference between DMC-FS7 series and DMC-FS12 series. Ref No. Original Part No. New Part No. Part Name & Description Remarks DMC-FS7 series DMC-FS12 series C3101 ----- F1H1C105A097 C.CAPACITOR CH 16V [SPC]...

  • Page 18: Frame And Casing Section

    5.2. Frame and Casing Section COMPARISON CHART: The following table shows difference between DMC-FS7 series and DMC-FS12 series. Ref No. Original Part No. New Part No. Part Name & Description Remarks DMC-FS7 series DMC-FS12 series VEP56074B VEP56074F MAIN P.C.B. (RTL) E.S.D. VYK2Y41 VYK3J43 FRONT CASE UNIT...
  • Page 19 Frame and Casing Section https://manual-hub.com/...

  • Page 20: Packing Parts And Accessories Section (1)

    5.3. Packing Parts and Accessories Section (1) Ref.No. Part No. Part Name & Description Remarks VPF1302 CAMERA BAG P,PC,PU DE-A59BA/SX BATTERY CHARGER P,PC,PU ----- BATTERY P,PC,PU K1HA08AD0001 USB CABLE W/PLUG P,PC,PU K1HA08CD0027 AV CABLE W/PLUG VFC4297-B HAND STRAP P,PC,PU VFF0512-S CD-ROM (SOFTWARE/INSTRUCTION BOOK) [SPC] P,PC,PU See “Notes”...
  • Page 21 Packing Parts and Accessories Section (1) https://manual-hub.com/...

  • Page 22: Packing And Accessories Section (2)

    5.4. Packing and Accessories Section (2) Ref.No. Part No. Part Name & Description Remarks VPF1302 CAMERA BAG EXCEPT P,PC,PU DE-A60AA/SX BATTERY CHARGER EG,EP,EB,GN DE-A60BB/SX BATTERY CHARGER EE,GC,GJ,GK DE-A60DA/SX BATTERY CHARGER DE-A60CA/SX BATTERY CHARGER ----- BATTERY EXCEPT P,PC,PU K1HA08AD0001 USB CABLE W/PLUG EXCEPT P,PC,PU K1HA08CD0027 AV CABLE W/PLUG PR,GC,GJ,GT,GK...
  • Page 23 Packing Parts and Accessories Section (2) https://manual-hub.com/...
