About This Document This document introduces the specifications of BaicellsEG7035L-M11 CPE and guides users to install and configure it. Copyright Notice Baicells copyrights this specification. No part of this specification may be reproduced in any form or means, without the prior written consent of Baicells. Disclaimer This specification is preliminary and is subject to change at any time without notice.
1. Product Overview Introduction Baicells is a high-tech company dedicated in wireless broadband access solutions and service operation. With the advent of the Internet+ era, the development of WBB is imminent. Through continuous innovation, Baicells launches the world first mobile broadband system based on the Internet architecture and unlicensed spectrum.
Figure 1-1EG7035L-M11 Appearance The EG7035L-M11 interfaces and buttons are shown in Figure 1-2. Figure 1-2Interface and Button of EG7035L-M11 The EG7035L-M11 interface and button description is given in Table 1-1. Table 1-1 Description of EG7035L-M11 Interface and Button Interface & Button Description Connected to the PoEpower adapter Support SD card...
Figure 1-3 LED Indicators of EG7035L-M11 The description of LED indicators are given in Table 1-2. Table 1-2 LED Indicator Description Identity Description Color Status Description Yellow Reserved. Steady On Reserved. Blanking Reserved. Network state LTE disconnected. Blue Indicator Steady On LTE connected.
Page 10
Identity Description Color Status Description connection state Steady On According to signal strength in and signal turn light up strength Blanking Scanning the LTE network The CPE is authenticating. CPE is getting IP address from the LTE network.
2. Technical Specifications Basic Specification Table 2-1 Basic Specification Item Description LTE Standard 3GPP Release 9 Ethernet LAN Port One RJ-45 port 10/100 auto-sensing, auto-MDX, LED Indicators Power/LET Signal/LAN Indicator USIM Support 1.8V/3V 2FF Restore Button Tact Button Long press over 10s to restore the factory settings Power Supply Input: Universal range 100V~240V AC Dimension...
Item Description SIM Lock Network Connection setup Create, delete, and edit APNs Set up dial-up connection automatically Set up dial-up connection manual LTE Scan Mode Full Band Cell Lock Band / Frequency Preferred ...
Item Description Operating Temperature -40℃ ~ 55℃ Storage Temperature -40℃ ~ 70℃ Operating Humidity 5% ~ 95% Regulatory Compliance FCC Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
3. Installation Guide Support Materials Before installation, prepare the following support materialsaccordingly, asgiven in Table 3-1. Table 3-1Support Materials for Installing Item Description Ethernet cable Outdoor Shield CAT5E Shorter than 330 feet Ground wire 16mm² yellow-green wire Install USIM Card and Cables Screw the screw on the waterproof cover, and open the waterproof cover.
Page 15
Close the waterproof cover and fasten the screw on the cover. Connected Ethernet cable to the power adapter. Pay attention to the power adapter interface directions. Power on, the LED indicator will light up.
Install on Wall Slipping the bracket from the CPE. Fit the CPE on the wall, and mark the drilling locations. Drill four 10mm diameter and 70mm depth holes in the wall by following the marked locations. Check the up/down direction of the bracket, and then fix it on wall using M5tapping screws.
Install onPole Round an anti-slip rubber on the pole. Fix the bracket using the hoop. 3. Install the CPE to the bracket and fasten the screw. Grounding The EG7035L-M11 must begrounding, please contact professional person to operation. Using grounding cable, connect the grounding cable to the ground row.
4. Configuration Guide Log in The EG7035L-M11 manages, configures, and maintains the device by web management page.The steps to log in are as follows: In the address column of browser, type in http://192.168.150.1, then press “Enter”, login in page is shown in Figure 4-1. Figure 4-1 Login Page Enter the user name and password, click "LOGIN".
Figure 4-2 View Status Basic Configuration 4.3.1 LTE Setting To set the LTE Network, perform the following steps: 1. Choose LTE. 2. In the LTE Setting area, configure the LTE network. 4.3.2 Set Connection Method To set the LTE network connection method, perform the following steps: 1.
2. In the connection Method area, set the connection method 3. There are two methods to connect the LTE network, it is needed to choose a method between Auto and Manual, if you want to auto connect to the LET network you should choose the Auto, otherwise you should choose Manual.
Figure 4-5 Lock Frequency Click “SAVE & APPLY”. 4.3.5 LockPCI To lock the PCI, perform the following steps: Choose “LTE>Scan Method”. In the LTE Scan Method area, click PCI Lock to lock the PCI. Click ADD LIST you can choose a band, frequency and PCI, then click Add to add the frequency and PCI to the list, as shown in Figure 4-6.
Figure 4-6 Lock Frequency Click “SAVE & APPLY”. 4.3.6 SAS Settings...
Page 23
Appendix A FAQs The POWER indicator does not turn on. Make sure that the power cable is connected properly and the CPE is powered on. Make sure that the power adapter is compatible with the CPE. Fails to Login to the web management page. ...
Appendix B Shipping List The product outward appearance, the color take the material object as, the picture only supply reference. Index Content Picture Amount EG7035L-M11 CPE with Simple Mounting bracket Power cord PoEadapter User Manual...
