About this Guide
Purpose
Scope
Audience
How to Use this Document
Organization
Related Product Information
Conventions Used in this Guide
Table of Contents
Section 1: Unpacking and Inventory
Unpacking Your AP 9215 Printer
Opening the Shipping Carton
Removing the Accessories and Paper Tray Boxes
Accessories Box
Removing the Printer from the Carton
Removing the Printer from the Bag
Inventory
Toner Cartridge
Opc Cartridge
Paper Trays
Section 2: Setting up Your Printer
Setting up Your Work Area
Installing the Paper Trays
Installing the Lower Paper Tray
Becoming Familiar with Your Printer
Installing the Upper Paper Tray
Front View of the Printer
Rear View of the Printer
Indicator Panel
Description of Indicator Panel Indicators and Controls
Installing the Toner Cartridge
Installing the Toner Cartridge
Peeling the Toner Cartridge Seal
Pulling the Seal
Installing the DPC Cartridge
Peeling off the Tab
Packing of the OPC Cartridge
Handling the OPC Cartridge
Protective Sheet
Inserting the OPC Cartridge
Loading Paper
Loading Paper into the Lower Paper Tray
Loading Paper into the Upper Paper Tray
Setting the DIP Switches
DIP Switches
DIP Switch Settings and Functions (Serial Mode)
Switch Position
DIP Switch Settings and Functions (Parallel Mode)
Description of Switch Functions
Switch 1 - Serial/Parallel
Switch 2 (Serial) - Half Duplex/Full Duplex
Switch 2 (Parallel) - Command Set 630
Switch 3 - Auto Line Feed On/Off
Switch 4 (Serial) - Stop Bits
Switch 4 (Parallel) - Line Spacing
Switch 5 (Serial) - Data Bits
Switch 5 (Parallel) - ACK in Busy/Ack out Busy
Switches 6 and 7 (Serial) - Protocol
Switch 7 (Parallel) - Portrait/Landscape
Switches 8 and 9 (Serial) - Parity
Switches 10, 11, and 12 (Serial) - Baud Rate
Switches 11 and 12 (Parallel) - Character Spacing
Connecting the AC Power Cord
Connecting the AC Power Cord
Checking the Quenching Lamp, Toner Collection Bottle, Transfer Corona Unit, Charge Corona Unit, and Shield Lens
Section 3: Operating Your Printer
Operator Safety
Powering on the Printer
Location of the Power Switch
Producing a Test Summary Sheet
Location of the Test Button
Sample Test Summary Sheet
Selecting the Paper Tray
Location of Shift and Tray Select Buttons, Paper Tray Indicators, and Display Panel
Invoking the Job Stacking Function
Choosing the Font
Location of Font Select Button and Display Panel
Using Multiple Fonts in a Single Document
Example
Selecting the Page Orientation
Location of Portrait/Landscape and Shift Buttons
Section 4: Maintaining Your Printer
C!Eaning Your Printer
Maintenance Schedule
Cleaning Your Printer
Opening the Exit Cover
Adding Paper
Cleaning the Exit Rollers
Adding Paper to the Upper Paper Tray
Adding Paper to the Lower Paper Tray
Adding Paper in Endless Feed Mode
Replacing the Toner Collection Bottle
Removing the Toner Collection Bottle
Cleaning Unit
Replacing the Toner Cartridge
Removing the Toner Cartridge
Peeling the Toner Cartridge Seal
Replacing the Cleaning Pad
Peeling off the Tab
Unlocking the Exit Cover
Unlocking the Fusing Unit
Opening the Fusing Unit
Removing the Cleaning Pad
Replacing the OPC Cartridge
Opening the Development Drawer
Removing the Old OPC Cartridge
Packing of the OPC Cartridge
Handling the OPC Cartridge
Replacing the Shield Lens
Inserting the OPC Cartridge
Replacing the Charge Corona Unit
Replacing the Shield Lens
Replacing the Charge Corona Unit
Replacing the Transfer Corona Unit
Removing the Toner Collection Bottle
Cleaning the Quenching Lamp
Replacing the Transfer Corona Unit
Removing the Quenching Lamp
Cleaning the Separation Pawls
Cleaning the Quenching Lamp
Unlocking the Exit Cover
Cleaning the Separation Pawls
Replacing the Separation and Feed Rollers
Reinserting the Separation Pawls
Removing the Development Drawer
Removing the Paper Trays
Location of the Shield Covers
Location of the Separation and Feed Rollers
Separation Roller Assembly
Reinserting the Development Drawer
Moving Your Printer
Sealing the Development Tank Opening
Sealing the Cleaning Unit Spigot
Section 5: Troubleshooting
Reading the Indicator Panel
Error Messages
Clearing Paper Jams
Clearing Misted Paper from the Upper Paper Tray
Opening the Upper Paper Tray Cover
Clearing Misted Paper from the Lower Paper Tray
Clearing Misled Paper from the Transfer Section
Clearing Misted Paper from the Lower Paper Tray
Unlocking the Exit Cover
Unlocking the Fusing Unit
Clearing Misted Paper from the Exit Section
Removing Misfed Paper from the Transfer Section
Unlocking the Exit Cover
Unlocking the Fusing Unit
Correcting Printing Problems
Troubleshooting
Correcting Other Problems
General Troubleshooting Chart
Replacing the Fuse
Removing the Fuse Holder
Removing the Fuse from the Holder
Reinserting the Fuse Holder
Correcting Radio or Television Interference
Appendix A: Printer Specifications
Printer Dimensions
Development Process
Print Speed
Electrical Environment
Power Requirements
Power Consumption
Operating Environment
Paper
Paper Tray Capacity
Paper Stacker Capacity
Page Dimensions
Maximum Effective Printing Areas
Appendix B: Default Parameter Values
Default Parameter Values
Appendix C: Supplies
Packing Arrangement of Kit a
Upper Cover
Toner Collection Bottle
Cleaning Pad
Shield Lens
Resident Fonts
Appendix E: Using Font Cartridges
Inserting and Removing a Font Cartridge
Inserting the Font Cartridge
Caring for Font Cartridges
Reading the Font Cartridge Label
Printing Signatures and Logos
Printing 3 of 9 Bar Codes
Appendix F: Installing the AP 9215 Printer with B 20 and et Series Systems
Determining the Current DIP Switch Settings
Configuring the Printer for B 20 Series Systems
Parallel Mode
Parallel Mode DIP Switch Settings
Serial Mode
B 20/25 System Parallel Printer Configuration
Serial Mode DIP Switch Settings (B 20 Series
B 20/25 System Serial Printer Configuration
Configuring the Printer for et Series Systems
File Parameters
Serial Mode DIP Switch Settings (et Series
File Parameters
Appendix G: Function Control Commands
AP 9215 Commands
Index
