To Lower the Stand
7-2
D
3
1
Loosen the T handle to unlock the riser, extend the stand a bit and press the
safety lock (D), and turn the ratched handle counter-clockwise.
* Always loosen the T handle when extending or lowering the stand.
!
* Always tighten the T handle when reaching the desired height.
* To change the turning direction of the ratched handle, flick the switch toggle.
* Best practice to swing the handle to extend / lower the stand instead of turning
a full circle.
To Close the Stand
8
2
2
1
Loosen the T handle
and lift the spider handle.
4
7
D
5
2
9
When the stand is closed, tighten the
T handle to secure the stand.
4
6
756M
KS706112
744M
KS706412
721M
KS706312
Advertisement
Summary of Contents for Kupo 756M
- Page 1 To Lower the Stand Loosen the T handle to unlock the riser, extend the stand a bit and press the safety lock (D), and turn the ratched handle counter-clockwise. 756M * Always loosen the T handle when extending or lowering the stand. KS706112 * Always tighten the T handle when reaching the desired height.
- Page 2 To Open the Stand To Lock the Casters Press A to lock, Press B to unlock. Press the spider Loosen the handle to open T handle. the stand. To Extend the Stand Press button C to take out or store the handle. Tighten the T handle to secure the stand.
