- Page 1 MSJET3 ENGLISH USER MANUAL ORIGINAL INSTRUCTIONS CAUTION: READ THE INSTRUCTIONS BEFORE USING THE MACHINE...
-
Page 2: Table Of Contents
Know Your Equipment 8 - 9 Brush Holder & Brushes/Pads Quick Start Guide 10 - 11 Changing JET3 Brushes 12 - 13 Where To Use JET3 Brushes/Pads and Applications Storing and Transporting Brush/Pad Cleaning Your JET3 14 - 15 32 - 33... - Page 3 EVERY BUILDING NEEDS A JET3. THIS IS YOURS. We hope you experience exceptional results with your JET3 machine. If you have any feedback, or need additional support, you can contact the MotorScrubber team at motorscrubberclean.com/support. ABOUT THIS MANUAL This manual contains all the information you need to get started with JET3.
-
Page 4: Technical Information
Technical Information Boasting all the features of the M3, with added spray function. The JET3 completely removes the need for a bucket with chemical. Designed to deep clean and polish any area, achieving like new results. JET3 is intended for commercial use only. For example in hotels, schools, hospitals, factories, offices, shops and rental businesses. -
Page 5: Warning Symbols
WARNING SYMBOLS DANGER: Indicates an imminent dangerous situation that, unless avoided, will result in death or serious injuries WARNING: Indicates a potentially dangerous situation that, unless avoided, could cause death or serious injury CAUTION: Indicates a potentially dangerous situation that, unless avoided, could cause slight or moderate injuries Information: Indicates additional information for the operator, to improve the use of the device... -
Page 6: Safety Basics
Safety Basics JET3 is incredibly safe and easy to use. However, as it is an electrical product we need to make you aware of some important safety information. By following the advice on this page, you can reduce any risk of electric shock and personal injury. - Page 7 Keep product cords and wires away from heat, oil and sharp edges Ensure you adopt the correct posture when using JET3. Adjust the position of the handle (see page 18) so your arm is straight, allowing you to maintain a straight back...
-
Page 8: Know Your Equipment
Know Your Equipment JET3 Control Handle Brush Switch Pump Switch 4. Water Pipe and Connector Handle Length Adjustment Motorhead Complete Spray Nozzle Hub Dark Grey Locking Knob 10. Acorn Nut 11. Thumb Screws 12. Aluminium Tube... - Page 9 White Buffing Pad Microfibre Pad Red Polishing Pad Medium Dry Brush 10. Charger WARNING: Always inspect JET3 for damage before use WARNING: JET3’s backpack contains magnets. Do not wear or operate the battery backpack if you have a medically implanted device.
-
Page 10: Quick Start Guide
Quick Start Guide Charge battery (page 22-23) Put on the backpack Adjust straps Fill bottle (page 25) Attach/remove Brush Holder and add/ Connect electrics (page 24) change JET3 pad (page 30-31) - Page 11 Prime the pump (page 26-27) Connect water (page 24) Adjust handle length (page 18) Clean with JET3 (page 32-33)
-
Page 12: Where To Use Jet3
Where to use JET3 Kitchen Cleaning Walls Stairs... - Page 13 Floor Cleaning Swimming Pools Textured Surfaces...
-
Page 14: Storing And Transporting Your Jet3
Storing and Transporting Your JET3 JET3 has been designed to be safe and easy to transport when following the below safety advice. MACHINE TRANSPORTATION Disconnect the power connection between the battery and the JET3 (see page 22-24) CAUTION: Secure the machine when transporting in a vehicle to prevent damage to the machine... -
Page 15: Machine Storage
JET3’s compact design means that it is easy to store. We recommend using a wall dock or M-CASE for proper storage. However you choose to store your JET3, you should follow the below guidance. MACHINE STORAGE W A L L D O C K... -
Page 16: Maintaining Correct Posture
Maintaining Correct Posture... - Page 17 We’ve designed our GEN3 Battery machine Backpack and JET3 to be ergonomic and easy to use, reducing the risk of strains • Each time you wear the backpack you and injury.
-
Page 18: Adjusting The Handle
However, if you do wish to change the handle position it can be done by following these simple steps. 1. Turn the JET3 over so the back of the handle is facing you. 2. Using a Phillips screwdriver, remove the two screws and take off the handle base. -
Page 19: Ppe When Using Jet3
JET3 GENERAL USAGE When operating JET3 you should always wear safety footwear, which is well gripped. If you’re cleaning with water only, no additional PPE is required. However, if you’re using disinfectant or chemical, you should always follow the manufacturer’s PPE advice. -
Page 20: Battery Safety And Information
JET3 is powered by either a 12-volt sealed lead acid battery OR a 12 volt Lithium Ion Battery. More information on the battery run time and charging can be found on page 22-23. Only use the battery charger provided with your JET3 to ensure it is charged safely. BATTERY CHARGER... -
Page 21: Battery Handling
FUSE PROTECTION: JET3 is equipped with a 15 AMP replaceable fuse to protect against short circuit. This fuse can be found inside the battery compartment... -
Page 22: Charging Your Jet3 Battery
Important Information CHARGING YOUR JET3 BATTERY Your JET3 battery (12V7ADC) is a rechargeable sealed lead-acid battery (VRLA). It can be charged two ways: In-backpack As a spare battery Connect your battery (12V7ADC) to your Connect your battery (12V7ADC) to your... - Page 23 WARNING: Only use the supply unit (MS1580, MLF-012W1201000) provided with this appliance to charge the battery (12V7ADC) WARNING: Do not charge VRLA Batteries above + 50 ºC, discharge or store above + 60 ºC For best results, do not charge a battery when the battery or air temperature is below 40°F (5°C) or above 105°F (40°C).
- Page 24 Important Information CHARGING YOUR JET3 LITHIUM BATTERY 12V18ADC Your JET3 battery 12V18ADC is a rechargeable Lithium Ion Battery. It can be charged two ways: In-backpack As a spare battery Connect your battery (12V18ADC) to your Connect your battery (12V18ADC) charger MSCHARGLITH (6AMP) whilst fitted...
-
Page 25: Battery Performance
BATTERY PERFORMANCE Batteries should be charged before using your JET3, after each use and if unused for four months. Battery Type A full charge from flat Run Time (full charge) Lead Acid Battery (12V7ADC) Approx 4 hours Approx 3.5 hours... -
Page 26: Electrical Connection
Important Information ELECTRICAL CONNECTION The machine connects to the backpack using a quick fit stainless steel electrical connection. Simply line up the red dots and push until you hear a click. To release the connection, grip the textured areas and pull apart. CAUTION: Before you connect the power cable, check the machine is not on. -
Page 27: Pump Switch
OSCILLATING FLOOR PAD PREPARING CLEANING SOLUTION JET3’s powerful agitation and latest pad technology will clean floors using just water. Some cleaning challenges may require chemical. For example use a degreaser for removing grease or oil, and use a descaler for removing scale build up in bathrooms and pool areas. -
Page 28: How To Prime The Pump
Important Information HOW TO PRIME THE PUMP Every MotorScrubber machine is thoroughly tested in our factory before dispatch. It is possible during storage and transportation for an airlock to develop in the pumping system. To release any airlocks present, you can follow the priming steps below before use. - Page 29 HOW TO PRIME THE PUMP If you’re still not sure how to complete this process, scan this code to watch an instructional video.
-
Page 30: Brush Holder & Brushes/Pads
Brush Holder or cleaning brushes & pads WARNING: Ensure fingers are kept clear of JET3’s rotating mechanism WARNING: Only use cleaning pads which have been specifically designed and recommended for the JET3. We cannot guarantee the safety of any other cleaning brushes or pads... -
Page 31: Changing Jet3 Brushes
CHANGING JET3 BRUSHES 1. Turn the 3. Hold the hub firmly MotorScrubber upside to prevent rotation. down and support the Press down while handle with the inside turning the disc of your foot. clockwise until it locks in place. 2. Line-up the tabs on the disc with 4. -
Page 32: Brushes/Pads And Applications
Brushes/Pads and Applications JET3 is supplied with five pads/brushes, each with specific features and applications. MEDIUM DUTY BRUSH Non scratch fibres provide a brilliant deep clean to all smooth and textured floors and tiles Application: Versatile pad suitable for cleaning all floor types. -
Page 33: Brush/Pad Cleaning
Application: For daily maintenance on most floor types between deep cleans Reusable: Wash up to 300 times CAUTION: Only use cleaning brushes & pads which have been specifically designed and recommended for JET3. We cannot guarantee the safety of any other cleaning brushes & pads... -
Page 34: Cleaning With Jet3
SLIP HAZARD: JET3 applies water and/or cleaning solution to the floor, creating a potential slip hazard. Ensure appropriate PPE footwear is worn (See page 19) SLIP HAZARD: JET3 is intended for commercial use. Ensure others are alerted to the potential slip hazard by using appropriate signage... - Page 35 BUTTON REMINDER The blue switch operates the pump which powers the spray. This is a demand switch and needs to be held down to operate the pump. When the button is released, the pump will switch off and the spray will stop.
-
Page 36: Targeted Spray Scrub Technology
3.5 - 8 hour runtime allows the user to clean anywhere. Fully adjustable and lightweight, the padded backpack fits any user. The JET3 comes with a 1 Litre / 0.21 gal bottle for your solution, which can be easily removed for quick refilling. -
Page 37: Underwater Use
Underwater • Because its motor WE RECOMMEND Fully submerged Use NOT USING THE head can be fully- for 2 minutes then take out MOTORSCRUBBER FULLY immersed in water, the to cool for 5 minutes. SUBMERGED IN WATER MotorScrubber is ideal FOR MORE THAN 2 for many underwater Submerge... -
Page 38: Product Faults
JET3 as part of a larger cleaning team. If the JET3 battery level indicator has all of its display lights flashing continuously - this could mean that there is an error with the machine. Examples of errors include electronic faults and overheating. -
Page 39: Your Remote Support Team
YOUR REMOTE SUPPORT TEAM JET3 is manufactured and assembled at our headquarters in Sheffield, UK, by a team of skilled assembly technicians. Working closely with our design and engineering team, they know each one of our machines inside out, which means they are best placed to assist you in the rare instance you experience a product fault. -
Page 40: Jet3 & Backpack Assembly
JET3 Assembly MS3003R ALUMINIUM TUBE 2. MS3004C GRAB HANDLE 3. MSS103 RUBBER GRIP 4. J2SUB2E - 3PIN JET SWITCH HOUSING 5. MS1041 MEDIUM DUTY BRUSH 6. MSS172B THUMB SCREW MSGREY12V MOTORHEAD WITH YOKE 8. MSJ40 JET ARM BRACKET 9. 011 0016 JET NOZZLE CHECK VALVE 10. - Page 41 Backpack Assembly MSS02-B BACKPACK 2. MSJ09B WATER/SOLUTION BOTTLE 3. MSJ11 IN LINE CHECK VALVE 4. J1SUB2 JET PUMP ASSEMBLY 5. 12V7ADC/12V18ADC BATTERY 6. MSJ08E COILED WATER PIPE MSJ02C 2 CORE COILED PUMP CABLE 8. MSJ07B WATER PIPE 9. MSJ01D-3PIN 3 CORE COILED CABLE (CHARGING 3-PIN CHARGER) 10.
-
Page 42: Declaration Of Conformity
Declaration of Conformity 07/08/2023 The following products have been reviewed by MotorScrubber Ltd and external testing partners to ensure compliance with the applicable directives & standards. Applicant: MOTORSCRUBBER Limited Address: 8 Orgreave Road, Sheffield, S13 9LQ, United Kingdom Product: MotorScrubber Battery Operated Cleaning Machine. Model no(s): M3S, M3M, M3L, MSJET, MSPROWASH, MSSHOCK, MSSTORM Rated Input: AC 100 –... -
Page 43: Your Warranty
LIMITED THREE-YEAR WARRANTY Warranty MotorScrubber JET3 ONE YEAR COMMERCIAL WARRANTY AS STANDARD. THREE YEAR COMMERCIAL WARRANTY AFTER REGISTERING YOUR JET3. JET3 is built to withstand the challenges If the fault cannot be rectified remotely of commercial cleaning, using high quality then follow the instructions in this booklet components that are tested to their limits. - Page 44 YOU MUST REGISTER YOUR MACHINE TO ACTIVATE YOUR 3 YEAR WARRANTY Register your warranty at: motorscrubberclean.com/warranty HEAD OFFICE INTERNATIONAL USA and Canada - Chicago 8 Orgreave Rd, Sheffield, +1 630 326 3107 S13 9LQ, England usaorders@motorscrubberclean.com +44 (0)114 478 8710 orders@motorscrubberclean.com AUSTRALIA - Melbourne +61 459 269 988...
