- Page 1 HD 1080P Pro Black Box Security Camera User Manual HAI2MPBLBOXP Version:Mar,2016...
- Page 5 Overview The HD 1080P Pro Black Box Security Camera is a super simple design black unit with an integrated smart & powerful 1080P hidden camera. First, it can be easily set to do photo taking (by interval), video & audio recording and motion detection recording by remote control;...
-
Page 6: Product Instruction
Product instruction ON/OFF button Charging indicator light Start button USB port Motion detect recording Micro SD card slot Manual recording Operation indicator light Photo by interval Camera Audio recording... -
Page 7: Getting Started
Getting started Step 1: Insert micro SD card into card slot TIPS: * Use micro SD card speed>=Class 4 & HC marked; * Better format card by PC before inserting. Step 2: Turn on device and connect power Open right side cover, turn on ON/OFF button, close the cover and plug it into AC power using the included adapter. - Page 8 a, Press , to turn on the device; Blue light always on, it is in standby status. b, Press , blue light blinking 4 times and off, it is in motion detect video recording; Press again to save& stop, blue light always on. c, Press , blue light blinking 3 times and off, it is in manual video recording;...
-
Page 9: Camera Setting
e, Press , blue light blinking 5 times and off, it is in audio recording; Press again to save & stop, blue light always on. f, Press again, to turn off the device; Blue light off. TIPS: The functions of 5 buttons on the back of device are the same as remote control buttons. -
Page 10: Function Introduction
Function introduction 1. VERSION = 2015090101 # DO NOT CHANGE (Device version No.) 2. RESOLUTICON # (0=1080p@30fps,1= 720p@60fps) (Selection of resolution) 3. VIDEO_TIME # (0=1mins, 1=2mins, 2=3mins,3=5mins, 4=10mins,5=15mins) recording interval time (Selection of record video length） 4. QUALITY # (0=fine, 1=good, 2=normal) (Selection of video quality.0=Good 1=Medium 2=Poor) 5. -
Page 11: Other Features
TIPS: 1. When setting up, please observe original format and values in the document to avoid invalid setting. 2. Save after set up, then turn on again to finish setting finally. Other features: 1. U disk mode: Connect device by USB cable to PC any time, then find a movable disk in My Computer. -
Page 12: Specification
Specification Device dimension 100*60*20MM Resolution 5 Mega CMOS Video pixel 1920*1080 @ 30fps,1080*720 @ 60fps Photo pixel 2592*1944 Angle 90 Degree Compressed format H.264 Video format Memory card Micro SD card>=Class 4 & HC marked Support memory Max 64GB USB interface USB1.1/2.0 Operation system 2000/XP/Vista32... - Page 13 FAQ： 1. Q: Can working when charging for long time use? A: Yes, please use included 5V 2A adapter to plug in power for long time use (Left side red led always on). 2. Q: Plug in AC adapter, device turn on? A: Yes.
- Page 14 4. Q: No reaction after pressing remote(Three solutions )? A: 1). Take out the insulating strip of remote, and press in a short distance (3-4meters) to see if it is working; 2). Use the back side buttons to test if the camera works or not; 3).
- Page 15 8. Q: How to play video? A: 1). Use included short reading data USB cable to connect to PC to play when in U disk mode; 2). Please change another 5pin USB cable or PC to try again; 3).Use card reader to ready and play video. 9.
- Page 16 The End!
