- Page 1 E01-2G4M13S User Manual NRF24L01P 2.4GHz SMD Wireless Module...
-
Page 2: Table Of Contents
Chengdu Ebyte Electronic Technology Co., Ltd. E01-2G4M13S User Manual Contents 1 Overview .........................................2 1.1 Introduction ...................................... 2 1.2 Features ......................................2 1.3 Application ......................................2 2 Specification and parameter................................... 3 2.1 Limit parameter ....................................3 2.2 Operating parameter ..................................3 3 Size and pin definition ....................................4 4 Basic operation ......................................5... -
Page 3: Overview
Industrial grade high precision 16MHz crystal is used. Since the E01-2G4M13S is a SPI RF transceiver module, you need to use the MCU driver or a dedicated SPI debugging tool. -
Page 4: Specification And Parameter
Chengdu Ebyte Electronic Technology Co., Ltd. E01-2G4M13S User Manual 2 Specification and parameter 2.1 Limit parameter Performance Main parameter Remark Min. Max. Voltage over 3.6V will cause permanent Power supply（V） damage to module Chances of burn is slim when modules Blocking power（dBm）... -
Page 5: Size And Pin Definition
Chengdu Ebyte Electronic Technology Co., Ltd. E01-2G4M13S User Manual 3 Size and pin definition Name Direction Function Power supply Power supply ：2.0~ 3.6V DC Input Chip enable SPI Chip select Input SPI Clock Input MOSI Input SPI master output slave input... -
Page 6: Basic Operation
Chengdu Ebyte Electronic Technology Co., Ltd. E01-2G4M13S User Manual 4 Basic operation 4.1 Hardware design It is recommended to use a DC stabilized power supply. The power supply ripple factor is as small as possible, and the module needs to be reliably grounded.；... -
Page 7: Software Editing
Chengdu Ebyte Electronic Technology Co., Ltd. E01-2G4M13S User Manual 4.2 Software editing Insert the module on the user's circuit board, use the microcontroller to communicate with the module via SPI or serial port, and operate the control register and the transceiver buffer through the SPI command to complete the wireless data transmitting and receiving function. -
Page 8: Module Is Easy To Damage
Chengdu Ebyte Electronic Technology Co., Ltd. E01-2G4M13S User Manual 6.2 Module is easy to damage Please check the power supply source, ensure it is 2.0V~3.6V, voltage higher than 3.6V will damage the module. Please check the stability of power source, the voltage cannot fluctuate too much. -
Page 9: Reflow Soldering Curve
Chengdu Ebyte Electronic Technology Co., Ltd. E01-2G4M13S User Manual 7.2 Reflow soldering curve 8 E01 Series Frequency TX power Distance Model No. RFIC Package Antenna E01-ML01S nRF24L01P 2.4G E01-ML01D nRF24L01P 2.4G E01-ML01IPX nRF24L01P 2.4G IPEX E01-2G4M13S nRF24L01P 2.4G E01-ML01DP4 nRF24L01P 2.4G... -
Page 10: Packing Method For Batch Order
Chengdu Ebyte Electronic Technology Co., Ltd. E01-2G4M13S User Manual 9 Packing method for batch order Copyright ©2012–2024，Chengdu Ebyte Electronic Technology Co.,Ltd... -
Page 11: Revision History
About us Technical support: support@cdebyte.com Documents and RF Setting download link: https://www.cdebyte.com Thank you for using Ebyte products! Please contact us with any questions or suggestions: info@cdebyte.com ------------------------------------------------------------------------------------------------- Web: https://www.cdebyte.com Address: B5 Mould Park, 199# Xiqu Ave, High-tech District, Sichuan, China...
