- Page 1 For the following equipment: DCM (WM800) WPM (WM600 & WM500) SmartWall & Filterbank Circuit breaker (RCD) tripping Version 20230711...
- Page 2 Circuit breaker (RCD) tripping If you find that the circuit breaker (RCD) consistently trips whenever you turn on the equipment, it is probablycaused by the earth leakage from the equipment to the RCD. Given the industrial nature of the hardware, it is crucial to use an RCD that can withstand a maximum earth leakage of 0.3 amps. By upgrading to an RCD with the appropriate specifications, capable of accommodating the higher threshold for earth leakage, you can effectively solve the tripping issue.
- Page 3 Circuit breaker (RCD) tripping Remember, electrical work should be approached with caution and expertise. If you are uncertain about any aspect of the RCD replacement process, it is always best to consult a professional electrician or seek guidance from qualified individuals to ensure the safety and integrity of the electrical system. In case that it is not possible to replace the circuit breaker (RCD), due to regulations or location, the euipment can be modified by the below listed steps, and hereby decrease the earth leakage, but it will increase the eletrical noise within the components and surounding components.
- Page 4 Circuit breaker (RCD) tripping 4. Remove the top plastic cover and the small plastic clip as shown on the picture below 5. Place the servo drives back inside the machine, reconnect all the wires the same way as before disassembling. 6.
- Page 5 Circuit breaker (RCD) tripping Smartwall & Filterbak – SM2000 & SM3000 1. Turn off the equipment for minmium 5 minutes, and leave it unplugged from the socket 2. Remove the 4 screws on the top of the machine, that holds the cover to the electrical panel 3.
- Page 6 Circuit breaker (RCD) tripping 4. Remove the top plastic cover, and the small plastic clip as shown on the picture below 5. Place the servo drives back inside the machine, reconnect all the wires the same way as before disassembling. 6.
- Page 7 Circuit breaker (RCD) tripping DCM (Diamond Cut Machine) – WM800 1. Turn off the equipment for minmium 5 minutes, and leave it unplugged from the socket 2. Remove the 4 screws in the back of the machine, that holds the cover to the electrical panel 3.
- Page 8 Circuit breaker (RCD) tripping Maintenance English Rev. 20221003 Page 8 of 10...
- Page 9 Circuit breaker (RCD) tripping 4. On the left side of each of the drives, remove the screw (Please note that the X axis and Z axis drive need to be dismounted from the electric panel, before you can access the screw on these) Maintenance English Rev.
- Page 10 7. Plug in the machine and run a test. If previously mentiond solutions does not solve the tripping of the RCD, please consult with a local authorized eletrican and Wheel Restore Company ApS. Maintenance English Rev. 20221003 Page 10 of 10...
