Summary of Contents for Beko BDIS15060
- Page 1 Dishwasher User’s Manual BDIS15060 15 7892 0100_AA_45E5_EN/ 11-08-23.(9:08)
- Page 2 Please read this user manual first! Dear Customer, We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use.
-
Page 3: Table Of Contents
CONTENTS 1 INSTRUCTIONS FOR SAFETY 5 OPERATING THE PRODUCT 23 Keys ............24 AND ENVIRONMENT Function keys ........24 General safety ........4 Preparing the machine...... 24 Intended use ..........4 Programme selection ......24 Children’s safety ........5 Auxiliary functions ......26 Disposing of packaging material ..5 Scheduling the washing time ...27 Transportation of the product ....5... -
Page 4: Instructions For Safety And Environment
instructions for safety and environment This section contains safety Never touch the plug with • instructions that will help to get wet hands! Never unplug by protected from risk of personal pulling on the cable, always injury or property damage. Failure pull out by grabbing the plug. -
Page 5: Children's Safety
instructions for safety and environment Children’s safety This appliance is intended • to be used in household and Electrical products are • similar applications such as: dangerous for the children. - Staff kitchen areas in shops, Keep children away from the offices and other working product when it is in use. -
Page 6: Compliance With Weee Directive And Disposing Of The Waste Product
instructions for safety and environment Package information 1. Unplug the product before transporting it. Packaging materials of the 2. Remove water drainage and product are manufactured water supply connections. from recyclable materials in accordance with our National 3. Drain the remaining water in Environment Regulations. -
Page 7: Dishwasher Overview
Dishwasher Overview 1. Upper basket 2. Upper impeller 3. Lower impeller 4. Silverware basket (depends on model) 5. Door 6. Rating Label 7. Control panel 8. Detergent dispenser 9. Lower basket 10. Filters 11. Salt reservoir lid (depends on model) 12. -
Page 8: Fan Drying System
Dishwasher Technical specifications Compliance to standards and test data / EC declaration of conformity This product complies with the following EU directives; Development, production and sales stages of this product comply with the safety rules included in all pertaining European Community regulations. 2014/35/EU, 2014/30/EU, 93/68/EC, IEC 60436/DIN 44990, EN 50242 Power input 220-240 V, 50 Hz (see rating label) -
Page 9: Installation
Installation Appropriate installation Refer to the nearest Authorised Service Agent for installation of your product. To location make the product ready for use, make sure Place the product on a solid and flat • that the electricity, tap water supply and floor that has sufficient load carrying water drainage systems are appropriate capacity! The product must be... -
Page 10: Connection To The Drain
Installation connected to the drain hole or sink’s Permitted water temperature: drainage. The length of this connection up to 25°C ( 60°C for products must be min. 50 cm and max. 100 cm from equipped with Aquasafe+; please the floor. A discharge hose longer than 4 refer toAquasafe+ section ) meters causes dirty washing. -
Page 11: Aquasafe
Installation Aquasafe+ The voltage and allowed fuse or • breaker protection are specified in the (depends on model) “Technical specifications” section. If the The Aquasafe+ system protects against current value of the fuse or breaker in water leaks that may occur at the hose the house is less than 16 Amps, have inlet.Water contact with the valve box of a qualified electrician install a 16 Amp... -
Page 12: Preparation Tips For Energy Saving
Preparation Tips for energy saving Adjusting the water softening system Following information will help you use the product in an ecological and energy- Cleaning, rinsing and drying performance of efficient manner. your dishwasher will increase when water Wipe away any coarse food remnants on softening system is adjusted properly. - Page 13 Preparation Remove the test Turn on the tap and Hold the test strip in Remove the test Wait for 1 minute. The test strip shows strip from the let the water run for the water for about strip from the water you the hardness packet.
-
Page 14: Adding Salt
Preparation If you move your house, it is necessary to readjust water hardness level of your machine by considering the information given above according to the hardness level of the supply water in your new location. Your machine will display the most recently adjusted water hardness level. -
Page 15: Detergent
Preparation Since different salt brands in the market have different particle sizes and since the water hardness may vary, dissolution of the salt in water may take a couple of hours. Therefore, Salt Indicator remains on for a 2. Put suggested amount of powder, while after adding salt into the liquid/gel or tablet detergent in the machine. -
Page 16: Tablet Detergents
Preparation The best washing performance in dishwashers is obtained by using detergent, rinse aid and water softening salt individually. Observe the instructions of the detergent manufacturer on the package when using tablet detergents. Contact the detergent manufacturer if your dishes are wet and/or if you notice Use powder or liquid/gel limescale spots particularly on... -
Page 17: Rinse Aid
Preparation Rinse aid 4. If there are stains on tableware items after washing, level must be increased The rinse aid used in and if there is a blue trace after wiping dishwashers is a special them by hand, it must be decreased. combination that aims to This is set to position 3 as factory increase drying efficiency and... -
Page 18: Placing The Dishes Into The Dishwasher
Preparation Decorative prints of chinaware as well as aluminium and silver items may get discoloured or tarnished after washing in the dishwasher just as it happens in handwashing as well. Some delicate glass types and crystals may become dull in time. We strongly recommend you to check if the tableware you are going to purchase is suitable... - Page 19 Preparation Suggestions for loading the dishwasher Improper Loading Of Dishware Lower basket Upper basket Dishwasher / User’s Manual 19 / 37 EN...
-
Page 20: Cutlery Basket
Preparation Cutlery basket Cutlery basket (depends on model) (depends on model) Cutlery basket is designed to wash your Cutlery basket is designed to wash your dishes such as knife, fork, spoon, etc. in an dishes such as knife, fork, spoon, etc. in an efficient manner. -
Page 21: Collapsible Lower Basket Tines
Preparation Collapsible lower basket Bringing the tines to the tines horizontal position by holding them from the tips may cause (depends on model) them to bend. Therefore, it Foldable tines (A) located at the lower will be appropriate to bring the basket of the machine are designed for tines in the middle to horizontal an easier placement of large pieces such... -
Page 22: Height Setting With Empty Basket
Preparation Height setting with empty Collapsible upper basket basket wires (depends on model) (depends on model) In this model, the height setting of the You can use collapsible wires when you upper basket may be changed using the need a larger space for your dishes in the wheels which are mounted at two different upper basket of your machine. -
Page 23: Operating The Product
Operating the product On/Off key 2. Programme Selection / Programme Cancel (3 seconds) key 3. Function keys Tablet detergent function Half Load function 4. Programme indicator 5. Salt indicator Not in use 7. Start / Cancel indicator 8. Time Delay / Programme Time indicator 9. -
Page 24: Keys
Operating the product Keys Programme selection On/Off key Press the On/Off button to turn on When you press On / Off key, indicator lights your machine. illuminate on the display for ON position. 2. Check the Salt and Rinse Aid indicators The lights turn off in OFF position. - Page 25 Operating the product Dishwasher / User’s Manual 25 / 37 EN...
-
Page 26: Auxiliary Functions
Operating the product Press and hold the tablet function buttons Auxiliary functions on the panel to activate the tablet function for appropriate programmes. Selecting Washing programmes of your dishwasher the tablet function will light the Tablet are designed to obtain the best cleaning Detergent indicator. -
Page 27: Scheduling The Washing Time
Operating the product Changing the settings while Time Floor illumination Delay function is active Warning to show that machine is While the Time Delay function is activated, in washing phase you cannot make changes in the washing (depends on the model) programme, auxiliary functions or the Your machine reflects a light to the floor duration of delay time. -
Page 28: Adjusting The Amount Of Rinse Aid
Operating the product Pay attention not to open the Rinse Aid indicator ( ) door of the machine when it is Please check the rinse aid indicator on the running. There may be a rush of display to see whether there is adequate vapour when you open the door amount of rinse aid in the dishwasher or of your machine;... -
Page 29: Water Cut-Off Warning
Operating the product Overflowing warning End of Programme indicator will light up when the washing programme is over. If the machine intakes too much water or Open the door of the machine. there is leakage at any of the components 2. -
Page 30: Cleaning The Outer Surface Of The Product
Maintenance and cleaning Cleaning the filters Service life of the product extends and frequently faced problems decrease if it is Clean the filters at least once a week in cleaned at regular intervals. order for the machine operates efficiently. Unplug the product and turn off Check if food residues are left on the filters. -
Page 31: Cleaning The Hose Filter
Maintenance and cleaning Cleaning the hose filter Damages on the machine that may be caused by impurities coming from the urban supply water or your own water installation (such as sand, dirt, rust, etc.) can be prevented by means of the filter attached to the water inlet hose. -
Page 32: Cleaning The Impellers
Maintenance and cleaning Cleaning the impellers Upper impeller Clean the impellers at least once a week in Check if the holes on the upper impeller (1) order for the machine operates efficiently. are clogged. If they are clogged, remove and clean the impeller. Turn its nut to left to Lower impeller remove the upper impeller. -
Page 33: Troubleshooting
Troubleshooting Machine does not start. • Power cable is unplugged. >>> Check if the power cable is plugged in. • Fuse is blown. >>> Check the fuses in your house. • Water is cut. >>> Make sure that the water inlet tap is open. •... - Page 34 Troubleshooting • Rinse aid is not sufficient. >>> Check the rinse aid indicator and add rinse aid if necessary. Increase the rinse aid setting if there is enough amount of rinse aid in the machine. • Machine is unloaded right after the programme is over. >>> Do not unload your machine right after washing process is completed.
- Page 35 Troubleshooting the filling process. Run the prewash programme to remove the salt that spilled inside the machine. Since the salt granules that will remain under the lid will dissolve during prewash, causing the lid loosen, check the lid once again at the end of the programme. There is a different odour in the machine A new machine has a peculiar odour.
- Page 36 Troubleshooting Detergent remains in detergent dispenser. • Detergent dispenser was damp when adding detergent. >>> Make sure that the detergent dispenser is dried well prior to filling it with detergent. • Detergent is added long before the washing process. >>> Pay attention to add detergent shortly before start-up of the washing.
- Page 37 Troubleshooting A smear remains on glasses that resembles milk stain which can not be removed when wiped by hand. A bluish / rainbow appearance occurs when the glass is pointed to light. • Excessive rinse aid is used. >>>Lower rinse aid setting. Clean the spilled rinse aid when adding rinse aid.
